Configuring Pppoeoa - HPE FlexNetwork MSR Series Comware 5 Layer 2 - Wan Access Configuration Manual

The following configurations enable the PVC to carry PPP and configure a PPP mapping for the
PVC.
To configure PPPoA:
Step
Enter system view.
1.
Create a VT interface.
2.
Set the PPP authentication
3.
mode and IP address; with
the PPPoE server, an
address pool should be
configured to allocate an IP
address for the remote end;
with the PPPoE client,
address negotiation should
be configured to accept the
IP address allocated by the
server end.
Return to system view.
4.
Enter ATM interface view.
5.
Create a PVC and enter the
6.
PVC view.
Configure a PPPoA mapping
7.
for the PVC.

Configuring PPPoEoA

PPPoE adopts the Client/Server model. It encapsulates PPP packets into Ethernet frames and
provides point-to-point connection on Ethernet. The following configurations enable the PVC to carry
PPPoE and configure a PPPoE mapping for the PVC.
When you configure PPPoEoA, follow these guidelines:
•
When you configure a static route for a virtual-template interface, specify the next hop rather
than the outgoing interface. If you want to specify the outgoing interface, make sure the physical
interface bound to the virtual-template is valid to ensure correct transmission.
•
When multiple Layer 3 virtual Ethernet interfaces are connected through PVCs to a DHCP
server that assigns IP addresses to the interfaces through static address binding, you must
configure different MAC addresses for the interfaces with the mac-address command.
To configure PPPoEoA:
Step
Enter system view.
1.
Create a VT interface.
2.
Command
system-view
interface virtual-template
vt-number
See "Configuring PPP and MP."
quit
interface atm { interface-number
| interface-number.subnumber }
pvc { pvc-name [ vpi/vci ] |
vpi/vci }
map ppp virtual-template
vt-number
Command
system-view
interface virtual-template
vt-number
203
Remarks
N/A
Configure PPP authentication and
IP address on the VT interface
(the IP address is invalid if
configured on the ATM interface).
N/A
N/A
N/A
N/A
N/A
Remarks
N/A
Configure PPP authentication
and an IP address on the VT
interface (the IP address is invalid
if configured on the ATM
interface).
