Use InARP or IND to dynamically create mappings between peer IP addresses and local DLCIs.
Use this method in complicated networks and make sure the peer device also supports InARP
or IND.
Configuration guidelines
•
Do not configure DLCIs for PVCs if IPv4 or IPv6 static address mappings are configured.
•
Do not configure IPv4 or IPv6 static address mappings on a P2P subinterface. A P2P
subinterface carries only one PVC.
•
IPv6 does not support nonstandard mappings.
Configuring IPv4 frame relay address mappings
To c onfigure IPv4 static frame relay address mappings:
Step
Enter system view.
1.
Enter interface view.
2.
Create an IPv4 static frame
3.
relay address mapping.
To configure IPv4 dynamic frame relay address mappings:
Step
Enter system view.
1.
Enter interface view.
2.
Enable InARP for IPv4
3.
dynamic frame relay
address mappings.
Configuring IPv6 frame relay address mappings
To c onfigure IPv6 static frame relay address mappings:
Step
Enter system view.
1.
Enter interface view.
2.
Create an IPv6 static frame
3.
relay address mapping.
To configure IPv6 dynamic frame relay address mappings:
Step
Enter system view.
1.
Command
system-view
interface interface-type
interface-number
fr map ip { ip-address [ mask ] |
default } dlci-number [ broadcast
| [ ietf | nonstandard ] ] *
[ compression { frf9 | iphc
connections number } ]
Command
system-view
interface interface-type
interface-number
fr inarp [ ip [ dlci-number ] ]
Command
system-view
interface interface-type
interface-number
fr map ipv6 { ipv6-address |
default } dlci-number
[ broadcast ] [ {compression
frf9} ]
Command
system-view
90
Remarks
N/A
N/A
By default, no IPv4 static frame
relay address mappings are
configured.
Remarks
N/A
N/A
Optional.
By default, InARP is enabled for
IPv4 dynamic frame relay
address mappings.
Remarks
N/A
N/A
By default, no IPv6 static frame
relay address mappings are
configured.
Remarks
N/A
