Step
13. Map the frame relay
DLCI to the PPPoFR
virtual template.
14. Return to system view.

MPoFR configuration example

Network requirements

As shown in
support transmitting traffic of multiple services. A single virtual circuit of an FR link can transport
multiple kinds of service data.
The bandwidth of Router A Serial2/0 is 64 kbps. Host A sends data traffic stream 1 to Host C, Host B
sends data traffic stream 2 to Host D, and a voice service stream exists between Router A and
Telephone A.
The bandwidth of Router B Serial2/0 is 64 kbps. Host C sends data traffic stream 3 to Host A, Host D
sends data traffic stream 4 to Host B, and a voice service stream exists between Router B and
Telephone B.
To ensure voice quality, fragment the data packets to reduce voice jitter caused by transmission
delay. MPoFR is used here, and MP is used to fragment data packets.
Figure 37 Network diagram
Telephone A

Configuration procedure

This example only covers MPoFR configuration. Routing and other features are beyond the scope of
this example.
Command
fr map ppp dlci-number interface
virtual-template interface-number
quit
Figure 37, the ATM backbone network uses FR network as the access network to
FR
Router A
S 2/0
1.1.6.1/ 24
Eth1/2 Eth1/1
1.1.1.2/ 24 10.1.1.2/ 24
Host A
Host B
1.1.1.1/ 24
10.1.1.1/ 24
ATM
FR
S2/0
1.1.6.2/ 24
Eth1/2
1.1.4.2/ 24
Host C
1.1.4.1/24
121
Remarks
N/A
In system view, repeat steps 6 to
13 to configure multiple PPPoFR
virtual templates.
Telephone B
Router B
Eth1/1
10.1.4.2/ 24
Host D
10.1.4.1/24
