Configuring PPPoFR

PPP over frame relay (PPPoFR) enables routers to establish end-to-end PPP sessions on a frame
relay network, allowing frame relay stations to use PPP features such as LCP, NCP, authentication,
and MP fragmentation.

Configuration procedure

To configure PPPoFR:
Step
Enter system view.
1.
Create a virtual template
2.
interface and the virtual
template interface view.
Assign IP address.
3.
Return to system view.
4.
Enter the frame relay
5.
interface view.
Enable frame relay on the
6.
interface.
Configure a frame relay
7.
DLCI.
Return to frame relay
8.
interface view.
Map frame relay DLCI to
9.
PPP.
When you configure a static route on a virtual-template interface, specify only the next hop. If you
want to specify the outbound interface as well, make sure the physical interface bound to the
virtual-template interface works correctly.

Displaying and maintaining PPPoFR

Task
Display PPPoFR MAP and status.
Command
system-view
interface virtual-template
interface-number
ip address ip-address
{ mask-length | mask }
quit
interface interface-type
interface-number
link-protocol fr [ ietf |
nonstandard ]
fr dlci dlci-number
quit
fr map ppp dlci-number
interface virtual-template
interface-number
Command
display fr map-info pppofr
[ interface interface-type
interface-number ] [ | { begin |
exclude | include }
regular-expression ]
118
Remarks
N/A
N/A
N/A
N/A
N/A
N/A
Optional for DTE side.
N/A
N/A
Remarks
Available in any view.
