The server powers down completely.
"Use the Oracle ILOM CLI for Immediate Shutdown" on page 139
See Also ■
"Use the Oracle ILOM Web Interface for Immediate Shutdown" on page 139
■

Use the Oracle ILOM CLI for Immediate Shutdown

1. Log in to the Oracle ILOM command-line interface (CLI) using an Administrator
account.
Oracle ILOM displays the default command prompt (->), indicating that you have successfully
logged in to Oracle ILOM.
2. From the CLI prompt, type the following command:
->
stop -f /System
The server immediately powers down to standby power mode.
3. To completely power off the server from standby power mode, disconnect the
power cables from the server.
The server powers down completely.
"Use the Power Button for Immediate Shutdown" on page 138
See Also ■
"Use the Oracle ILOM Web Interface for Immediate Shutdown" on page 139
■
Use the Oracle ILOM Web Interface for Immediate
Shutdown
Log in to the Oracle ILOM web interface using an Administrator account.
1.
The Oracle ILOM web interface System Information > Summary page appears.
In the left pane, click Host Management > Power Control, and select Immediate
2.
Power Off from the Select Action list box.
3. Click Save, and then click OK.
The server immediately powers down to standby power mode.
4. To completely power off the server from standby power mode, disconnect the
power cables from the server.
Use the Oracle ILOM CLI for Immediate Shutdown
Controlling System Power and Viewing BIOS Messages 139
