Configuring RAID Using the BIOS With the Sun
Storage 6 Gb SAS PCIe RAID Internal HBA
The BIOS RAID configuration utilities support configuring RAID with the server set to UEFI
BIOS Boot Mode and Legacy BIOS Boot Mode. A separate utility is provided for each boot
mode.
Note -
Boot Mode. For a list of operating systems and virtual machine software that do not support
UEFI BIOS Boot Mode, see
"Configure RAID in UEFI BIOS Boot Mode" on page 96
■
"Configure RAID in Legacy BIOS Boot Mode" on page 101
■
Configure RAID in UEFI BIOS Boot Mode
1. Power on or reset the server.
For example, to reset the server:
From the local server, press the Power button (approximately 1 second) on the front panel
■
of the server to power off the server, then press the Power button again to power on the
server.
From the Oracle ILOM web interface, select Host Management > Power Control, then
■
select Reset from the Select Action list box.
From the Oracle ILOM CLI, type:
■
The BIOS screen appears.
When prompted in the BIOS screen, press F2 to access the BIOS Setup Utility.
2.
After a few moments, the BIOS Setup Utility appears.
3. Use the right arrow key to navigate to the Advanced menu.
96 Sun Server X4-4 Installation Guide • October 2015
Some operating systems and virtual machine software only support the Legacy BIOS
"UEFI BIOS" on page 24.
reset /System
