Install Cable Management Arm
6.
Insert the left CMA slide-rail connector into the left slide-rail assembly until the
connector locks into place with an audible click.
Callout
1
2
7.
Install and route cables to your server, as required.
Note -
Server" on page
8.
If required, attach the cable hook and loop straps to the CMA, and press them
into place to secure the cables.
46
Sun Server X4-4 Installation Guide • October 2015
Description
CMA slide-rail connector
Left slide-rail
Instructions for installing the server cables are provided in
49.
"Cabling the
