Oracle Sun Server X4-4 Installation Manual page 90

Configure RAID With a Sun Storage 6 Gb SAS PCIe RAID Internal HBA
7. In the Details/Action column of the Created Volumes table, click the Details
button.
The Volume Details dialog box appears.
In the Volume Details dialog box:
8.
a. Review the volume details.
b. (Optional) In the Volume Name field, enter a volume name or modify it.
If you did not enter a volume name earlier, the Volume Details dialog box gives you a
second chance to do so. If you entered a volume name earlier, you can modify it here;
however, you cannot delete the name entirely.
Note -
creates a volume without a name. Additionally, if at any time you want to change the volume
name, you can do so by clicking on the Details button in the Created Volumes table; however,
once a volume name is assigned, you cannot delete it.
c. Check the Set As Bootable box.
d. Click Save & Close.
90 Sun Server X4-4 Installation Guide • October 2015
Naming the volume is optional. If you do not name the volume, Oracle System Assistant
