Configuring RAID Using the BIOS RAID Configuration
Utilities
If Oracle System Assistant is not available, you can use the BIOS RAID configuration utilities
that reside in the HBA firmware. The procedures for configuring RAID differ depending on the
type of HBA installed the server.
For instructions on how to use these utilities, see the following sections:
"Configuring RAID Using the BIOS With the Sun Storage 6 Gb SAS PCIe Internal
■
HBA" on page 93
"Configuring RAID Using the BIOS With the Sun Storage 6 Gb SAS PCIe RAID Internal
■
HBA" on page 96
See Also
"Drive Configuration Options" on page 79
■
"Configuring RAID Using Oracle System Assistant" on page 81
■
Configuring RAID Using the BIOS With the Sun
Storage 6 Gb SAS PCIe Internal HBA
The BIOS RAID configuration utilities support configuring RAID with the server set to UEFI
BIOS Boot Mode or Legacy BIOS Boot Mode. A separate utility is provided for each boot
mode.
Note -
Boot Mode. For a list of operating systems that support UEFI BIOS Boot Mode, see
BIOS" on page
"Configure RAID in UEFI BIOS Boot Mode" on page 93
■
"Configure RAID in Legacy BIOS Boot Mode" on page 95
■
Configure RAID in UEFI BIOS Boot Mode
1. Power on or reset the server.
For example, to reset the server:
Some operating systems and virtual machine software only support the Legacy BIOS
24.

Configuring RAID Using the BIOS RAID Configuration Utilities

Configure Server Drives for OS Installation
"UEFI
93
