Figure 38. UFQFPN28 recommended footprint

4.30

1. Dimensions are in millimeters

2. All leads/pads should also be soldered to the PCB to improve the lead/pad solder joint life.

90/98

0.30

0.55

Doc ID 023079 Rev 3

3.30

3.20

0.50

STM32F050xx

0.50

3.30

0.50

A0B0_ME_FP
