Table 25. Typical Current Consumption In Run Mode, Code With Data Processing; Running From Flash - STMicroelectronics STM32F050G6 Manual

STM32F050xx
Typical current consumption
The MCU is placed under the following conditions:
●
V
DD
●
All I/O pins are in analog input configuration
●
The Flash access time is adjusted to f
1 wait state above)
●
Prefetch is ON when the peripherals are enabled, otherwise it is OFF
●
When the peripherals are enabled, f
●
PLL is used for frequencies greater than 8 MHz
●
AHB prescaler of 2, 4, 8 and 16 is used for the frequencies 4 MHz, 2 MHz, 1 MHz and
500 kHz respectively
●
A development tool is connected to the board and the parasitic pull-up current is around
30 µA
Table 25.
Symbol
I
DD
I
DDA
=V =3.3 V
DDA
Typical current consumption in Run mode, code with data processing

running from Flash

Parameter
Supply current in Run
mode from V
DD
supply
Supply current in Run
mode from V
DDA
supply
Doc ID 023079 Rev 3
frequency (0 wait states from 0 to 24 MHz,
HCLK
= f
PCLK HCLK
Conditions f
HCLK
48 MHz
36 MHz
32 MHz
24 MHz
16 MHz
8 MHz
4 MHz
2 MHz
Running from
1 MHz
HSE crystal
500 kHz
clock 8 MHz,
code
48 MHz
executing
36 MHz
from Flash
32 MHz
24 MHz
16 MHz
8 MHz
4 MHz
2 MHz
1 MHz
500 kHz
Electrical characteristics
Typ
Peripherals Peripherals
enabled disabled
23.3 11.5
17.6 9.0
15.9 8.0
12.4 7.5
8.5 5.2
4.5 3.0
2.8 1.9
1.7 1.3
1.3 1.0
1.0 0.9
158 158
120 120
108 108
83 83
60 60
2.43 2.43
2.43 2.43
2.43 2.43
2.43 2.43
2.43 2.43
Unit
mA
µA
47/98
