Figure 33. LQFP32 - 7 x 7 mm, 32-pin low-profile quad flat package outline

24
25
b
32
Pin 1
1
identification
1. Drawing is not to scale.
Table 62. LQFP32 – 7 x 7 mm, 32-pin low-profile quad flat package mechanical data
Symbol
A
A1
A2
b
c
D
D1
D3
E
E1
E3
e
L
L1
k
ccc
1. Values in inches are converted from mm and rounded to 4 decimal digits.
D
D1
D3
17
16
E3 E1 E
9
8
millimeters
Min
0.050
1.350 1.400
0.300 0.370
0.090
8.800 9.000
6.800 7.000
5.600
8.800 9.000
6.800 7.000
5.600
0.800
0.450 0.600
1.000
0.0°
Doc ID 023079 Rev 3
ccc C
A
A2
A1
c
Typ Max
1.600
0.150
1.450
0.450
0.200
9.200
7.200
9.200
7.200
0.750
3.5° 7.0°
0.100
Package characteristics
L1
L
K
(1)
inches
Min Typ
0.0020
0.0531 0.0551
0.0118 0.0146
0.0035
0.3465 0.3543
0.2677 0.2756
0.2205
0.3465 0.3543
0.2677 0.2756
0.2205
0.0315
0.0177 0.0236
0.0394
0.0° 3.5°
5V_ME
Max
0.0630
0.0059
0.0571
0.0177
0.0079
0.3622
0.2835
0.3622
0.2835
0.0295
7.0°
0.0039
85/98
