STM32F050xx

Figure 31. LQFP48 - 7 x 7 mm, 48-pin low-profile quad flat package outline

36
37
b
48
Pin 1
identification
1
1. Drawing is not to scale.
Table 61. LQFP48 – 7 x 7 mm, 48-pin low-profile quad flat package mechanical data
Symbol
Min
A
A1 0.050
A2 1.350
b 0.170
c 0.090
D 8.800
D1 6.800
D3
E 8.800
E1 6.800
E3
e
L 0.450
L1
k 0°
ccc
1. Values in inches are converted from mm and rounded to 4 decimal digits.
D
D1
D3
25
24
E3 E1 E
13
12
millimeters
Typ Max
1.600
0.150
1.400 1.450
0.220 0.270
0.200
9.000 9.200
7.000 7.200
5.500
9.000 9.200
7.000 7.200
5.500
0.500
0.600 0.750
1.000
3.5° 7°
0.080
Doc ID 023079 Rev 3
ccc C
A
A2
A1
c
Min
0.0020
0.0531
0.0067
0.0035
0.3465
0.2677
0.3465
0.2677
0.0177
0°
Package characteristics
L1
L
K
5B_ME
(1)
inches
Typ Max
0.0630
0.0059
0.0551 0.0571
0.0087 0.0106
0.0079
0.3543 0.3622
0.2756 0.2835
0.2165
0.3543 0.3622
0.2756 0.2835
0.2165
0.0197
0.0236 0.0295
0.0394
3.5° 7°
0.0031
83/98
