6.7. "THE EQUIPMENT IS BLOCKED" MESSAGE ON THE
DISPLAY
This error message can be caused by:
• loss of communication between the lower and upper assemblies;
• the brake board has detected an error condition, causing it to generate an alarm and store the
error code in memory.
Carry out the "Error
detected by brake
board" troubleshooting
procedure
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
(1) Use the serial communications test described in paragraph 6.1.1.3 "Serial Ports Test".
(2) To reinstate communications between the lower and upper assemblies:
• check that cable CB-4 is correct;
• try replacing the brake board and the digital plan board in turn, and check whether the
communication works.
(3) Check whether the brake interface board is in an error condition, by accessing the "Low kit
fault code" parameter in the "Low kit menu" described in paragraph 9.3.6.2 "Low Kit fault
code".
If the displayed parameter value is "0", there is no error condition.
"THE EQUIPMENT IS BLOCKED"
MESSAGE ON THE DISPLAY
3
Is the serial
YES
communication between
display and lower
electronic correct?
1
Reinstate the
NO
communication link
between the upper and
lower assemblies
2
Page 6.23
