pauses the execution of subsequent sequence commands for x
number of seconds. Terminate this command with a].
Entering a 0 in wait x causes the instrument to wait for prior
sequence command activities to finish before allowing the
next command to begin. The wait 0 command only affects
the command immediately following it, and does not affect
commands later in the sequence.
selects the display warning annotation for color modification.
brings up the color dell&ion menu. The warning annotation
default color is black.
defines the standard (and the offset) as rectangular waveguide.
This causes the analyzer to assume a dispersive delay (see
applies a non-linear phase shift for use with electrical delay
which follows the standard dispersive phase equation for
the active function becomes the WAVEGUIDE CUTOFF
frequency, which is used in the phase equation. Choosing a
Start frequency less than the Cutoff frequency results in phase
errors.
is used to set the amplitude parameter (for example 3 dB) that
defines the start and stop points for a bandwidth search. The
bandwidth search feature analyzes a bandpass or band reject
trace and calculates the center point, bandwidth, and Q (quality
factor) for the specified bandwidth. Bandwidth units are the
units of the current format.
turns on the bandwidth search feature and calculates the
center stimulus value, bandwidth, and Q of a bandpass or band
reject shape on the trace. The amplitude value that defines the
Four markers are turned on, and each has a dedicated use.
Marker 1 is a starting point from which the search is begun.
Marker 2 goes to the bandwidth center point. Marker 3 goes to
the bandwidth cutoff point on the left, and Marker 4 to the
cutoff point on the right.
If a delta marker or fixed marker is on, it is used as the
reference point from which the bandwidth amplitude is
measured. For example, if marker 1 is the delta marker and is
set at the passband maximum, and the width value is set to
-3 dl3, the bandwidth search 0nds the bandwidth cutoff points
3 dB below the maximum and calculates the 3 dB bandwidth
and Q.
If marker 2 (the dedicated bandwidth center point marker) is
the delta reference marker, the search finds the points 3 dB
down from the center.
If no delta reference marker is set, the bandwidth values are
absolute values.
