Server Specifications

Physical Specifications

lists the physical specifications for the Sun Fire X4170 M2 and X4270 M2
TABLE 1-4
Servers.
Servers Physical Specifications
TABLE 1-4
Parameter Sun Fire X4170 M2 Server
Height 1.7 inches/43.4 mm
Width 16.85 inches/425.4 mm
Depth 27.0 inches/685.8 mm
Weight 36 lbs/16.3 kg

Electrical Specifications

lists the electrical specifications for the Sun Fire X4170 M2 and X4270 M2
TABLE 1-5
Servers.
Note – The power dissipation numbers listed in the following table are the
maximum rated power numbers for the power supply used in these servers. The
numbers are not a rating of the actual power consumption of the system. For up-to-
date information on power consumption, go to the following web sites and navigate
to the appropriate pages:
http://www.oracle.com/goto/x4270m2.
Servers Electrical Specifications
TABLE 1-5
Parameter
Sun Fire X4170 M2 Server
Input
Nominal frequencies
Nominal voltage range
Chapter 1
http://www.oracle.com/goto/x4170m2
Value
50/60 Hz
100-120/200-240 VAC
Preparing to Install the Sun Fire X4170 M2 and X4270 M2 Servers
Sun Fire X4270 M2 Server
3.4 inches/87.1 mm
16.8 inches/425.4 mm
30.0 inches/762.0 mm
65 lbs/29.5 kg
and
13
