15 Arrival of FDT set frequency2 Arrive at frequency 2 FDT set
Inspection Level Of FDT
16
Frequency
Arrival of preset counting
17
value
Arrival of counting value
18
upper limitation
Program ruuning one period
19
completion
20 Inspection in speed trick mode
21 No command running state
22 REW command of inverter
23 Deceleration running
Acceleration running
24
celerate running
25 Arrival of high pressure
26 Arrival of low pressure
27 Arrival of inverter rate current
28 Arrival of motor rate current
Arrival of input frequency
29
lower limitation
Arrival of current upper
30
limitation
Arrival of current lower
31
limitation
32 Time to reach limit time 1
33 Time to reach limit time 2
34 Inverter ready to run
o25 Output signal delay 1
o26 Output signal delay 2
o27 Output signal delay 3
o28 Output signal delay 4
o25~o28 defines o21~o24 output signal reaction delay time, unit is S.
Output signal cut off action without delay.
o29 FDT set frequency 1
o30 FDT set frequency 2
o31 FDT inspection range
Frequency detection range as 0， the output signal terminal movement is as below ：
Section V Parameter Function Table
FDT frequency levels to meet the inspection
conditions,o29~ o31
Present counting value arrives at preset counting
value
Present counting value arrives at upper
limitation of counting value.
Program runs one period to complete.
Inverter is under speed trick state, the valid time
is A11
Inverter is under N command running state
Inverter is under reverse running command
Inverter is under deceleration running
Inverter is under acceleration running
Arrival at hight pressure
Arrival at low pressure
Arrival at inverter rate current
Arrival at motor rate current
Present set frequency is less than frequency
lower limitation
Arrive at current of upper limitation
Arrive at current of lower limitation
Timing action mode refer to o65 configuration
Timing action mode refer to o66 configuration
The end of initialization when the drive power
on , running command is acceptable.
0~32.000
0~32.000
0~32.000
8000
-
o30~
Max frequency
0~o29
0.00~5.00
87
s 0 Y
s 0 Y
s 0 Y
s 0 Y
Hz 0.00 Y
Hz 0.00 Y
Hz 0.00 Y
