Thank you for choosing Powtran Technology PI160 series high
performance frequency inverter. This product made by POWTRAN based on
years of experience in professional production and sale, and designed for
variety of industrial machinery, fan and water pump drive unit and IF heavy-
dury grinding unit.
This manual provides user the relevant precautions on
installation,operational parameter setting, abnormal diagnosis, routine
maintenance and safe use. In order to ensure correct installation and operation
of the frequency converter, please carefully read this manual before installing it.
For any problem when using this product, please contact your local dealer
authorized by this company or directly contact this company, our professionals
are happy to serve you.
The end-users should hold this manual,and keep it well for future
maintenance & care,and other application occasions. For any problem within
the warranty period,please fill out the warranty card and fax it to the our
authorized dealer.
The contents of this manual are subject to change without prior notice. To
obtain the latest information, please visit our website.
For more product information, please visit: Http://www.powtran.com.
Foreword
Powtran
May,2016
