Section V Parameter Function Table
The main mode of the frequency running frequency:
0 : keyboard setting frequency or RS485 change F01 keyboard setting frequency
Multi-digital voltage terminal effective exchange, change F01keyboard setting value
1 : AI1 the external analog setting
Given the external analog0~10V,-10V~+10V,0~20mA.For detail please read the o group
parameter.
2 : AI2 the external analog setting
3 : AI3 the external analog setting
Given the external analog 0~10V, 0~20mA. For detail please read the o group parameter.
4 : Keyboard potentiometer setting
Keyboard potentiometer setting, keyboard potentiometer for a given start and end values of
the corresponding values can be positive role and negative effects. For detail please read the
A group parameter.
5 : Multi-segment digital voltage setting
o36~o46 IO input terminal function set to 11, 12, 13, switch H47~H54 Multi-digital voltage
setting, 100% Corresponding to the maximum frequency .
6 : Digital pulse setting
Digital pulse input frequency Corresponding to the setting frequency, For detail please read
the o52 group parameter.
Pulse input terminal and DI8 terminal reset , after using the digital pulse input,o43 set to
0 ,Otherwise, the function settings will take effect, the pulse input on status of o58 can be
checked, be limited to low-speed pulse.
Through o36~o46 IO input teminal set to 14, 15, 16 be configured to switch the source
Auxiliary setting mode of
F03
frequency
Auxiliary setting mode of frequency set:
0 : Keyboard frequency setting frequency or RS485, change F01 kayboard setting frequency
Multi-segment digital
voltage setting
Digital Pulse Setting
Keyboard setting
frequency or RS485
AI1 the external analog
8000
setting
AI2 the external analog
setting
AI3 the external analog
8000
setting
Keyboard potentiometer
setting
Multi-segment digital
voltage setting
Digital Pulse Set
PID regulation mode
54
5
6
0
1
2
3
- 0
4
5
6
7
Y
