Example2:
Explanation2: The memory place U2 contains valid EDID.

7.9.4. Emulating an EDID to an input port

Command format: CALL●/EDID:switch(<source>:<destination>)
Response format: mO●/EDID:switch
Example:
Legend:

7.9.5. Copy an EDID to user memory

Command format: CALL●/EDID:copy(<source>:<destination>)
Response format: mO●/EDID:copy
Example:
Legend:
Explanation: The EDID of the last connected sink (Dynamic EDID, D1) has been copied
to the user memory (U1).

7.9.6. Deleting an EDID from user memory

Command format: CALL●/EDID:delete(<user_edid_memory>)
Response format: mO●/EDID:delete
Example:

7.9.7. Resetting emulated EDIDs

Command format: CALL●/EDID:reset(1)
Response format: mO●/EDID:reset
Example:
Explanation: Calling this method switches all emulated EDIDs to factory default one. See
the table in section
Section 7. Programmer's reference
> GET●/EDID/U/U2.Header
< pr●/EDID/U/U2.Header=LWR;640x480@60.0Hz;D640x480p60
> CALL●/EDID:switch(F49:E2)
< mO●/EDID:switch
<source>: Source EDID memory places that can be Factory, User or
Dynamic EDID memory.
<destination>: The emulated EDID memory of the desired input port.
> CALL●/EDID:copy(D1:U1)
< mO●/EDID:copy
<source>: Source EDID memory places that can be Factory, User or
Dynamic EDID memory.
<destination>: User EDID memory place (U1...U31).
> CALL●/EDID:delete(U1)
< mO●/EDID:delete
> CALL●/EDID:reset(1)
< mO●/EDID:reset
11.2 on page 111.
MODEX-OPTS, MODEX-OPTM
User's Manual
Page 85 / 113
