Clear all events
All events can be cleared at the same time with the loading
factory default values. All the values will be cleared: names,
conditions, actions. Click on the Load factory defaults button. A
warning message appears; confirm it by clicking on the OK button.

6.9. Settings menu

Reboot
When Settings menu is selected, Reboot button is displayed in the right top corner; the
extender can be rebooted after confirmation.

6.9.1. Core tab

The submenu displays information about MODEX frame. Device label can be also changed
which is visible on the front panel LCD.

6.9.2. Network tab

When the extender is connected to a network or directly to a computer, the necessary
settings can be set in this submenu. If a fixed IP address is planned to use, fill Static IP
address, Static subnet mask and Static gateway fields. If dynamic IP address is planned to
use, set DHCP to Enabled from the drop-down list; other settings are made automatically.
Click on Apply changes button to save settings.
Section 6. Web control – Using the built-in website
Figure 6-14. Core tab
Figure 6-15. Network tab
MODEX-OPTS, MODEX-OPTM
User's Manual
Load factory defaults
