7.8.1. Set the source node (condition)

Command format:
Response format:
Example:
Explanation: This node contains the path of the property that will fire the E1 event (the
path of the P1 video input port).
Info: Node path must be started with "/".

7.8.2. Set the source property (condition)

Command format:
Response format:
Example:
Explanation: This node contains the property that will fire the E1 event (signal present
state of P1 port).

7.8.3. Set the value of the source property (condition)

Command format:
Response format:
Example:
Explanation: The E1 event will be fired, if this property is changed to the set value (signal
is present on input port P1).

7.8.4. Set the target node (action)

Command format:
Response format:
Example:
Explanation: This node contains the path of the property that will be changed after the E1
event is fired.
Info: Node path must be started with "/".
Section 7. Programmer's reference
SET●/EVENTS/E<event_nr>.SourceNode=
<node_path>"/"<node_name>
pw●/EVENTS/E<event_nr>.SourceNode=
<node_path>"/"<node_name>
> SET●/EVENTS/E1.SourceNode=/MEDIA/VIDEO/P1
< pw●/EVENTS/E1.SourceNode=/MEDIA/VIDEO/P1
SET●/EVENTS/E<event_nr>.SourceProperty=<property>
pw●/EVENTS/E<event_nr>.SourceProperty=<property>
> SET●/EVENTS/E1.SourceProperty=SignalPresent
< pw●/EVENTS/E1.SourceProperty=SignalPresent
SET●/EVENTS/E<event_nr>.SourcePropertyValue=<value>
pw●/EVENTS/E<event_nr>.SourcePropertyValue=<value>
> SET●/EVENTS/E1.SourcePropertyValue=1
< pw●/EVENTS/E1.SourcePropertyValue=1
SET●/EVENTS/E<event_nr>.TargetNode=
<node_path>"/"<node_name>
pw●/EVENTS/E<event_nr>.TargetNode=
<node_path>"/"<node_name>
> SET●/EVENTS/E1.TargetNode=/MEDIA/UART/P1
< pw●/EVENTS/E1.TargetNode=/MEDIA/UART/P1
MODEX-OPTS, MODEX-OPTM
User's Manual
Page 83 / 113
