2.3. Rear view

MODEX can be supplied with many kind of interface modules, thus the rear view of the
extenders are different. Following example shows the structure of the installed modules.
Media connector

2.4. Media connectors

MODEX-CON-NT-OPTS
Part nr. 9161 0227
MODEX-CON-OPTM-ODVA
Part nr. 9161 0230
MODEX-CON-OPTS-ST
Part nr. 9161 0235
MODEX-CON-OPTM-SC
Part nr. 9161 0238
Section 2. Controls and connections
1 2
Interface module (D)
MODEX-CON-NT-OPTM
MODEX-CON-OPTS-NT-PCN
MODEX-CON-OPTM-ST
Interface module (E)
3
Part nr. 9161 0228
Part nr. 9161 0231
Part nr. 9161 0236
MODEX-OPTS, MODEX-OPTM
User's Manual
Video & Audio module (B)
4
MODEX-CON-OPTS-ODVA
Part nr. 9161 0229
MODEX-CON-OPTM-NT-PCN
Part nr. 9161 0232
MODEX-CON-OPTS-SC
Part nr. 9161 0237
Page 15 / 113
