7.4.2. Query the status of source ports

Command format:
Response format:
Example:
Legend
Mute / lock
state
Audio / HDCP
state
Signal /
connection
state
Explanation: (P2:T00AF) Video signal is connected and present on Port#2, the signal
does not contain audio and not HDCP-encrypted. The port is unlocked, unmuted.
Section 7. Programmer's reference
GET●/MEDIA/VIDEO/XP1.SourcePortStatus
pr●/MEDIA/VIDEO/XP1.SourcePortStatus=[<port#1>:<status>;
<port#2>:<status>;...;<port#n>:<status>]
> GET●/MEDIA/VIDEO/XP1.SourcePortStatus
< pr●/MEDIA/VIDEO/XP1.SourcePortStatus=P2:T000B
P2:T00AF
T: unlocked, unmuted
L: locked, unmuted
M: unlocked, muted
U: locked, muted
0: audio unknown, HDCP state unknown
1: audio signal unknown
2: audio unknown, not HDCP-encrypted
3: audio unknown, HDCP-encrypted
4: HDCP state unknown
5: <reserved>
6: signal is not HDCP-encrypted
7: signal is HDCP-encrypted
8: embedded audio not present, HDCP state unknown
9: embedded audio not present
A: embedded audio not present, signal is not HDCP-encrypted
B: embedded audio not present, signal is HDCP-encrypted
C: embedded audio is present, HDCP state unknown
D: embedded audio is present
E: embedded audio is present, signal is not HDCP-encrypted
F: embedded audio is present, signal is HDCP-encrypted
0: Signal and connection states unknown
1: Signal state unknown
2: Signal state unknown, no connection
3: Signal state unknown, connection established
4: Connection state unknown
5: <reserved>
6: No connection
7: Connection is established
8: Signal not present, connection state unknown
9: Signal not present
A: Signal not present, no connection
B: Signal not present, connection established
C: Signal present, connection state unknown
D: Signal present
E: Signal present, no connection
F: Signal present, connection established
MODEX-OPTS, MODEX-OPTM
Signal / Connection state
Audio / HDCP state
<reserved>
<reserved>
Mute / lock state
Port number
