Symptom
Extenders are
not linked or
remote device
cannot be
reached
Crosspoint
setting cannot
be changed
Module
property cannot
be changed
Section 10. Troubleshooting
Root cause
Optical module
Fiber cable is Check the connectors: from TX
connected to (Channel A) to RX (Channel B).
the not used
channel
Optical cable Use special fiber optical cable
became cleaning equipment or a soft cloth to
contaminated carefully clean it.
Different Check the firmware in TX and RX;
firmware is the versions have to match. If
installed necessary do firmware upgrade.
Miscellaneous
Core module is Unlock the core module via the built-
locked in website.
The module is Unlock the module via the built-in
locked website.
MODEX-OPTS, MODEX-OPTM
Action
User's Manual
Refer to
Section 4.1
Section 6.9.3
and Chapter 8
Section 6.9.6
Section 6.9.6
Page 109 / 113
