6.6.3. Advanced EDID Management

Select the EDID button from the main menu.
The window contains two panels: left panel contains the EDIDs that can be used as a
source; right panel contains the target places where the EDIDs can be emulated. The list
can be scrolled by mouse wheel or by grabbing the list.
Control buttons

6.6.4. Changing emulated EDID

Step 1. Select desired EDID list from one of the three sources by pressing its button above
Step 2. Select an EDID from the left panel that has to be emulated; the EDID will be
Step 3. Press Emulated button above right panel; currently emulated EDID is shown.
Step 4. Select desired port where the EDID has to be emulated (more ports can also be
Step 5. Press Transfer button to change emulated EDID.
Section 6. Web control – Using the built-in website
Exporting an EDID (save to
Save
1
a file)
Importing an EDID (load
Load
from a file)
Opening EDID Summary
Info
window with selected EDID
Opening Advanced EDID
Edit
Editor with selected EDID
Opening Easy EDID
Create
Creator
left panel.
highlighted with yellow cursor.
selected); the EDID will be highlighted with yellow cursor.
Figure 6-9. EDID management
Clear selected
Select All
Unselect All
MODEX-OPTS, MODEX-OPTM
User's Manual
Executing EDID
emulation/learning
(Transfer button)
Deleting EDID (from
user memory)
Selecting all memory
places in the right
panel
Selecting none of the
memory places in the
right panel
