2.7.3. DVI inputs and outputs

29 pole DVI-I connectors, however internally connected pins vary by interface types. This
way, user can plug in any DVI connector, but keep in mind that analog signals (such as
VGA or RGBHV) are currently not processed – planned for future developments.
Always use high quality DVI cable for connecting sources and displays. Pay attention to
the DVI cable, if dual link signal is to be sent, use only dual link capable DVI cables.
Pin
1
2
3
4
5
6
7
8
C1
C4

2.7.4. DisplayPort input and output

Pin
1
2
3
4
5
6
7
1
These pins are connected only in MODEX-AV-DVIDL-IM and MODEX-AV-DVIDL-OM modules.
Section 2. Controls and connections
1
9 10 11
17 18 19
Signal
TMDS Data2-
TMDS Data2+
TMDS Data2/4 Shield
TMDS Data4- 1
1
TMDS Data4+
DDC Clock
DDC Data
n.c.
n.c.
n.c.
Table 2-2. DVI-I connector pin assignments
Figure 2-2. DisplayPort connector
Signal
ML_Lane 0 (p)
GND
ML_Lane 0 (n)
ML_Lane 1 (p)
GND
ML_Lane 1 (n)
ML_Lane 2 (p)
Table 2-3. DisplayPort connector pin assignments
2 3 4 5 6 7 8
12 13 14 15 16
20 21 22 23 24
Pin Signal
9 TMDS Data1-
10 TMDS Data1+
11 TMDS Data1/3 Shield
12 TMDS Data3-
13 TMDS Data3+
14 +5V Power
15
GND (for +5V)
16 Hot Plug Detect
C2
n.c.
C5
GND
Pin Signal
8 GND
9 ML_Lane 2 (n)
10 ML_Lane 3 (p)
11 GND
12 ML_Lane 3 (n)
13 Config1
14 Config2
MODEX-OPTS, MODEX-OPTM
User's Manual
C1 C2
C3 C4
C5
Pin Signal
17 TMDS Data0-
18 TMDS Data0+
19 TMDS Data0/5
1 20 TMDS Data5-
1
21 TMDS Data5+
22 TMDS Clock Shield
23
TMDS Clock+
24 TMDS Clock-
C3
n.c.
Pin Signal
15 AUX CH (p)
16 GND
17 AUX CH (n)
18 Hot Plug
19 Return
20 DP_PWR
