Qvis I-ZEUS-HYBRID1 User Manual

16 channel analogue / ip hybrid dvr

page of 207

/ 207
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

i-ZEUS HYBRID

I-ZEUS-HYBRID16

16 CHANNEL ANALOGUE / IP HYBRID DVR

User's Manual

V1.0 09 / 2013

Table of Contents

Need help?

Do you have a question about the I-ZEUS-HYBRID1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Qvis I-ZEUS-HYBRID1

Page 1 i-ZEUS HYBRID I-ZEUS-HYBRID16 16 CHANNEL ANALOGUE / IP HYBRID DVR User’s Manual V1.0 09 / 2013...
Page 3: Table Of Contents
3.6 Alarm Input and Output Connection ................... 15 3.6.1 Alarm Input and Output Details ....................16 3.6.2 Alarm Input Port ........................17 3.6.3 Alarm Output Port ........................17 3.7 RS485 ............................. 18 OVERVIEW OF NAVIGATION AND CONTROLS ..........19 © Copyright Qvis ®. All documentation rights reserved.
Page 4 4.9 PTZ Control and Color Setup ....................... 52 4.9.1 Cable Connection ........................52 4.9.2 PTZ Setup ..........................52 4.9.3 3D Intelligent Positioning Key ....................54 4.10 Preset/ Patrol/Pattern/Scan ......................55 4.10.1 Preset Setup .......................... 56 © Copyright Qvis ®. All documentation rights reserved.
Page 5 5.10 Advanced ........................... 100 5.10.1 HDD Management ....................... 100 5.10.2 Abnormity ..........................105 5.10.3 Alarm Output ........................106 5.10.4 Manual Record ........................107 5.10.5 Account ..........................107 5.10.6 Auto Maintain ........................110 © Copyright Qvis ®. All documentation rights reserved.
Page 6 7.6.3 Multiple-channel preview ....................... 129 7.7 WAN Login ........................... 130 7.8 Setup ............................132 7.8.1 Channel..........................132 7.8.2 Video and Audio ........................133 7.8.3 Network ..........................138 WIFI ............................140 PPPoE ............................ 142 © Copyright Qvis ®. All documentation rights reserved.
Page 7 7.8.6 System ........................... 164 7.8.7 Advanced ..........................178 7.8.8 Information ..........................180 7.9 Search ............................182 7.10 Alarm ............................185 7.11 Log out ............................186 7.12 Un-install Web Control ......................186 FAQ ........................ 187 © Copyright Qvis ®. All documentation rights reserved.
Page 8 Here you can find information about the corresponding DVR’s features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully! © Copyright Qvis ®. All documentation rights reserved.
Page 9: Important Safeguards And Warnings
Contact your local retailer ASAP if something is broken in your package. 7. Lithium battery  Improper battery use may result in fire, explosion, or personal injury!  When replace the battery, please make sure you are using the same model! © Copyright Qvis ®. All documentation rights reserved. viii...
Page 10: Features And Specifications
Record playback function: Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc.Support various playback modes: slow play, fast play, backward play and frame by frame © Copyright Qvis ®. All documentation rights reserved.
Page 11: Specifications
Copy/paste operation, USB mouse right-key shortcut menu, double Function click USB mouse to switch screen. Compression Video H.264 Standard Compression Audio G.711A Compression 75Ω) 16-CH composite video input: (NTSC/PAL) BNC (1.0VB Video Input P - P, © Copyright Qvis ®. All documentation rights reserved.
Page 12 There is a special series has 4-channel 200-2000mV 10KΩ (BNC). 1-ch audio output 200-3000mv 5KΩ(BNC) Audio Output Bidirectional 1-ch audio input 200-3000mv 10KΩ(BNC) Audio 1-ch audio output 200-3000mv 5KΩ(BNC) 8 built-in SATA port. Support 8 HDD. Hard Disk © Copyright Qvis ®. All documentation rights reserved.
Page 13 Alarm can activate record, external alarm or screen message prompt. Alarm Video Loss Alarm can activate external alarm or screen message prompt. External Alarm Supports record activation function or activate external alarm or screen message in specified period. © Copyright Qvis ®. All documentation rights reserved.
Page 14 Power General Consumption 25W (Exclude HDD) Parameter Working 0℃－＋55℃ Temperature Working 10%－90% Humidity Air Pressure 86kpa－106kpa 2U standard industrial case. 440(W) x460(D) x89(H)mm Dimension Weight 6.5－7.5KG (Exclude HDD) Installation Desktop/rack installation Mode © Copyright Qvis ®. All documentation rights reserved.
Page 15: Overview And Controls
 Right When playback, click these buttons to control playback bar. Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. ENTER Confirm current operation © Copyright Qvis ®. All documentation rights reserved.
Page 16 Up/down direction key. Playback mode, turn the inner dial to realized frame by frame Jog(inner dial) playback. (Only applies to some special versions.) USB port To connect USB storage device, USB mouse. © Copyright Qvis ®. All documentation rights reserved.
Page 17 When the light flashes fast, it means the corresponding channel of 17-32 channel is recording now. When the light becomes on, It means the corresponding 2-channel is recoding now. IR Receiver It is to receive the signal from the remote control. © Copyright Qvis ®. All documentation rights reserved.
Page 18: Rear Panel
USB port Network port Video matrix output When connect the Ethernet port, please use crossover cable to connect the PC and use the straight cable to connect to the switcher or router. © Copyright Qvis ®. All documentation rights reserved.
Page 20: Mouse Control
Implement special control operation such as double click one item in the file list click mouse to playback the video. In multiple-window mode, double left click one channel to view in full-window. Double left click current video again to go back to previous multiple-window mode. © Copyright Qvis ®. All documentation rights reserved.
Page 21: Virtual Keyboard & Front Panel
< to shift between small character and capitalized character. 2.5.2 Front Panel Move the cursor to the text column. Click Fn key and use direction keys to select number you wanted. Please click enter button to input. © Copyright Qvis ®. All documentation rights reserved.
Page 22: Installation And Connections
The input video signal should have a high SNR, low distortion; low interference, natural color and suitable lightness. GUARANTEE THE STABILITY AND RELIABILITY OF THE CAMERA SIGNAL The camera should be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. © Copyright Qvis ®. All documentation rights reserved.
Page 23: Connecting Video Output
(see Figure 3-1). Audio transmission is similar to video transmission. Try to avoid interference, dry joint, loose contact and it shoul be kept away from high tension current. © Copyright Qvis ®. All documentation rights reserved.
Page 24: Audio Output
The voltage between of A,B lines of the decoder should be less than 5V. 4. Please make sure the front-end device has been soundly earthed. Improper grounding may result in circuit damage. © Copyright Qvis ®. All documentation rights reserved.
Page 25: Alarm Input And Output Details
+12V It is external power input. Need the peripheral equipment to provide +12V power (below 1A). Earth cable. 485 A/B 485 communication port. They are used to control devices such as PTZ. © Copyright Qvis ®. All documentation rights reserved.
Page 26: Alarm Input Port
To avoid overloading, please read the following relay parameters sheet carefully.  RS485 A/B cable is for the A/B cable of the PTZ decoder.  T+,T-,R+,R- are four-wire double duplex RS485 port. T+ T-: output wire R+ R-: input wire © Copyright Qvis ®. All documentation rights reserved.
Page 27: Rs485
2. Connect the other end of the cable to the proper pins in the connector on the camera. 3. Please follow the instructions to configure a camera to enable each PTZ device on the DVR. Figure 3-5 485 Port © Copyright Qvis ®. All documentation rights reserved.
Page 28: Overview Of Navigation And Controls
Note: For security reason, please modify password after you first login. Failure to login in after three attempts will result in the system alarm being triggered and after five failed logins the account will be locked! Figure 4-1 © Copyright Qvis ®. All documentation rights reserved.
Page 29: Main Menu
The other ways is to press power button on the front panel for at least 3 seconds, system will stop all operations. Then you can click the power button in the rear panel to turn off the DVR. © Copyright Qvis ®. All documentation rights reserved.
Page 30: Auto Resume After Power Failure
Support drag and play function. You can use your mouse to select any playback start time.  Support playback, pause and exit function.  Right now, system does not support slow playback and backward playback function.  Support digital zoom function.  Support real-time backup function. © Copyright Qvis ®. All documentation rights reserved.
Page 31 USB device. System can not backup the video of multiple-channel at the same time.  Current selected backup channel has an icon as and the free channel is shown as an icon as © Copyright Qvis ®. All documentation rights reserved.
Page 32 Select one device in the list first and then click Add button, you can add current front-end device to the digital channel. You can double click one device in the list to add too. Or you can click Manual add button and input remote device information to add. © Copyright Qvis ®. All documentation rights reserved.
Page 34: Manual Record
 Stop: All channels stop recording. Figure 4-9 4.3.3 Enable/disable record Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. © Copyright Qvis ®. All documentation rights reserved.
Page 35: Enable All Channel Recording
 All channel manual record Please highlight “ALL” after “Manual.” See Figure 4-5. When system is in manual recording, all scheduled set up you have set in will be null (Main menu->Setting->Schedule). © Copyright Qvis ®. All documentation rights reserved.
Page 36: Stop All Channel Recording
4.3.5 Stop all channel recording Please highlight “ALL” after “Stop”. See Figure 4-6. System stops all channel recording no matter what mode you have set in the menu (Main menu- >Setting->Schedule) Figure 4-6 © Copyright Qvis ®. All documentation rights reserved.
Page 37: Search & Playback
Important: Redundancy HDD does not support picture backup function, but it does support the picture playback function. You can select to play © Copyright Qvis ®. All documentation rights reserved.
Page 38  Return: Click button , system goes back to the calendar and channel setup interface. Please note: For the file that is writing or overwriting, it can not be locked. © Copyright Qvis ®. All documentation rights reserved.
Page 39 System supports custom snap picture saved path. Please connect the peripheral device first, click snap button on the full-screen mode, you can select or create path. Click Start button, the snapshot picture can be saved to the specified path. © Copyright Qvis ®. All documentation rights reserved.
Page 40 Please note: System supports a maximum of 1024 backup files. You cannot perform clip operation if there any of the files have been checked in the file list. © Copyright Qvis ®. All documentation rights reserved.
Page 41 During the file playback process, you can switch to other channel via switch the dropdown list or rolling the mouse. channel This function is null if there is no record file or system is in smart when search process. playback © Copyright Qvis ®. All documentation rights reserved.
Page 42: Smart Search
06:00.00 and then click Search button, you can view all the record files after 06:00.00 (The records includes current time.). Click the ‘Play’ button and you will see the system begins playing from 06:00.00. See Figure 4-9. © Copyright Qvis ®. All documentation rights reserved.
Page 43: Mark Playback
It is very easy for you to get the important video information.  Add Mark: When system is in playback mode, click the Mark button , you will be able to go to the following interface. See Figure 4-10. © Copyright Qvis ®. All documentation rights reserved.
Page 44 You can only change mark name here.  Delete: Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item. . © Copyright Qvis ®. All documentation rights reserved.
Page 45: Schedule
The white means the MD and alarm record is valid. Once you have set to record when the MD and alarm occurs, system will not record neither motion detect occurs nor the alarm occurs. © Copyright Qvis ®. All documentation rights reserved.
Page 47 See Figure 4-22. System needs to reboot to get setup activated. Now you can search or playback file in redundant disk.  Dismantle the disk and play it in another PC. © Copyright Qvis ®. All documentation rights reserved.
Page 48: Snapshot
In Detect interface please enable snapshot function for specified channels. Or in alarm interface please enable snapshot function for specified channels. Please refer to the following figure for detailed information. See Figure 4-24. © Copyright Qvis ®. All documentation rights reserved.
Page 49: Image Ftp
In Network interface, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-25. Please boot up corresponding FTP server. Please enable schedule snapshot or activation snapshot first, now system can upload the image file to the FTP server. © Copyright Qvis ®. All documentation rights reserved.
Page 50: Detect
Fn button to switch between the arm mode and disarm mode. In arm mode, you can click the direction buttons to move the green rectangle to set the motion detection zone. After you © Copyright Qvis ®. All documentation rights reserved.
Page 51 Please set sensitivity and click Test button, you can see system only displays the motion detect status of the blue area(s). The red flashing area is the current motion detect. See Figure 4-14. © Copyright Qvis ®. All documentation rights reserved.
Page 52 , you can left click mouse and then drag it to set a region for motion detection. Click Fn to switch between arm/withdraw motion detection. After setting, click enter button to exit. Figure 4-26 Figure 4-27 Figure 4-28 © Copyright Qvis ®. All documentation rights reserved.
Page 54: Video Loss
It is null for other detect types.  System only enables camera masking function during the period you set here. It is set as null for motion detection or video loss type. © Copyright Qvis ®. All documentation rights reserved.
Page 55: Alarm Setup And Alarm Activation
After one successful connection, all disconnection events will be regarded as IPC offline event.  When IPC offline alarm occurs, the record and snapshot function of digital channel is null. © Copyright Qvis ®. All documentation rights reserved.
Page 56 Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule d snapshot. © Copyright Qvis ®. All documentation rights reserved.
Page 57 For snapshot operation, please refer to chapter 4.4.2. Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. Figure 4-34 © Copyright Qvis ®. All documentation rights reserved.
Page 59: Backup
Click backup button, you can see an interface is shown as in Figure 4-39. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes USB burner, flash disk, SD card, portable HDD and eSATA. Figure 4-39 © Copyright Qvis ®. All documentation rights reserved.
Page 60: Backup
PIC from the dropdown list. Please click the Add button and then select the pictures. Click the Start button; you can then copy the specified pictures to the selected portable devices, See Figure 4-41. Figure 4-41 © Copyright Qvis ®. All documentation rights reserved.
Page 61: Ptz Control And Color Setup
PTZ and decoder connection is right. Decoder address setup is right.  Decoder A (B) line connects with DVR A (B) line.  Boot up the DVR, input user name and password. © Copyright Qvis ®. All documentation rights reserved.
Page 62 In one window display mode, right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 4-43. Figure 4-43 © Copyright Qvis ®. All documentation rights reserved.
Page 63: Intelligent Positioning Key
Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ automatically. The smaller zone you dragged, the higher the speed. Figure 4-46 © Copyright Qvis ®. All documentation rights reserved.
Page 64: Preset/ Patrol/Pattern/Scan
X 3 2 8 H 3 2 8 H 3 2 8 H Here you can activate the following functions:  Preset  Tour  Pattern  Auto scan  Auto pan  Flip  Reset  Page switch © Copyright Qvis ®. All documentation rights reserved.
Page 65: Preset Setup
In Figure 4-50, click patrol button. The interface is shown as in Figure 4-50. Input preset number and add this preset to a patrol (tour). For each patrol (tour), you can input max 80 presets. © Copyright Qvis ®. All documentation rights reserved.
Page 66: Activate Patrol (Tour)
Then please go to Figure 4-43 and click left limit button. Repeat the above procedures to set right X 3 5 0 H 3 5 0 H 3 5 0 H limit. © Copyright Qvis ®. All documentation rights reserved.
Page 67: Activate Auto Scan
Here you can set auxiliary function. The aux value has relation ship with the Aux button of the decoder. Click page switch button again, system goes back to Figure 4-44. Figure 4-53 © Copyright Qvis ®. All documentation rights reserved.
Page 68: Understanding Of Menu Operations And Controls
Pan/Tilt/Zoom Set communication protocol, baud rate and etc with the PTZ device. Display Menu output, tour monitor parameter setup. © Copyright Qvis ®. All documentation rights reserved.
Page 69 Sniffer, information analysis, text overlay function for special fields. Config Import/export device configuration. backup Backup Backup Detect, backup, erase, and stop operation. detect Shutdown - Logout menu user, shutdown system, restart system, switch user and etc. © Copyright Qvis ®. All documentation rights reserved.
Page 70: Main Menu
Here is for you to view system information. There are total seven items: HDD (hard disk information), BPS (data stream statistics), log, version, online user, remote device information and network info. See Figure 5-. Figure 5-2 © Copyright Qvis ®. All documentation rights reserved.
Page 71: Hdd Information
Tip: Please click Fn button or left click mouse to view HDD record time and HDD type and time. Double click one HDD info; you can view the SMART information. See Figure 5-4. © Copyright Qvis ®. All documentation rights reserved.
Page 72: Bps
This section allows you to view the system log files. System lists the following information. See Figure 5-6. Log types include system operation, configuration operation, data management, alarm event, record operation, log clear, etc. © Copyright Qvis ®. All documentation rights reserved.
Page 73 Click the Details button or double click the log item, you will view the detailed information such as log time, log type, log user, IP address, etc. See Figure 5-5. Figure 5-5 © Copyright Qvis ®. All documentation rights reserved.
Page 74: Version
Start: Please insert the USB device that has the update file to the device and then click the Start button to begin the update. Important: Please make sure the upgrade file name is named ‘update.bin’ or ‘Update.bin’ Figure 5-8 © Copyright Qvis ®. All documentation rights reserved.
Page 75: Online Users
: Front-end does not support. : Front-end supports. There is alarm event from current front-end.  Connection status: : Connection succeeded. : Connection failed.  Refresh: Click this to get the latest front-end channel status. © Copyright Qvis ®. All documentation rights reserved.
Page 76 Click search button, you will be able to view the remote connection log of current channel. You can select another channel (you do not need to click Search button again), and view remote connection log. Figure 5-7 © Copyright Qvis ®. All documentation rights reserved.
Page 77: Network Info
System can save the packets to the specified path. The file is named after “Network adapter name+time”. You can use software such as Wireshark to open the packets on the PC for the professional engineer to solve complicated problems. Figure 5-8 © Copyright Qvis ®. All documentation rights reserved.
Page 78: General
Time format: There are two types: 24-hour mode or 12-hour mode.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional. Slight difference maybe found in various series.) © Copyright Qvis ®. All documentation rights reserved.
Page 79 When you change HDVR time, the front-end time changes too. When system reaches the sync interval, it synchronizes time with the front-end. When you change HDVR setup, system synchronizes time with the front-end. © Copyright Qvis ®. All documentation rights reserved.
Page 80 Before your time modification, please stop the record operation first! After completing all the setups please click save button, system goes back to the previous menu: Figure 5-14 Figure 5-15 Figure 5-16 © Copyright Qvis ®. All documentation rights reserved.
Page 81: Encode
See Figure 5-20. Snapshot mode: There are two modes: Timing (Schedule) and activation. If you set timing mode, you need to set snapshot frequency. If you set activation snapshot, you © Copyright Qvis ®. All documentation rights reserved.
Page 82 Please check the number to select the channel or you can check the box ALL. Please click the OK button in Figure 5-22 and Figure 5-19 respectively to complete the setup. Please highlight icon to select the corresponding function. Figure 5-19 Figure 5-20 © Copyright Qvis ®. All documentation rights reserved.
Page 83: Schedule
 Function: Console  Baud rate:115200  Data bit: 8  Stop bit:1  Parity: None After completing all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 84: Network
LAN. It is read-only.  IP address: Here you can use up/down button () or input the corresponding number to input IP address. Then you can set the corresponding subnet mask the d efault gateway. © Copyright Qvis ®. All documentation rights reserved.
Page 85 LAN download: System can process the downloaded data first if you enable this function. The download speed is 1.5X or 2.0X of the normal speed. After completing all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 86 Network Setting Network setup interface is shown as in Figure 5-26. Please draw a circle to enable corresponding function and then double click current item to go to setup interface. Figure 5-26 © Copyright Qvis ®. All documentation rights reserved.
Page 87 If you enabled trusted sites, only the IP address in the trusted sites list can access the device.  If you enabled blocked sites, the IP address in the blocked sites can not access the device.  System supports add MAC address. © Copyright Qvis ®. All documentation rights reserved.
Page 89 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-30 © Copyright Qvis ®. All documentation rights reserved.
Page 90 Click save button, system prompts for rebooting to get all setup activated. After rebooting, open IE and input as below: http：//(DDNS server IP)/(virtual directory name)/webtest.htm e.g.: http：//10.6.2.85/DVR _DDNS/webtest.htm.) Now you can open DDNSServer web search page. © Copyright Qvis ®. All documentation rights reserved.
Page 91 Add to the list: Click it to add the mapping relationship.  Delete: Click it to remove one mapping item. Double click one item; you can change the corresponding mapping information. See Figure 5-34. © Copyright Qvis ®. All documentation rights reserved.
Page 92  WIFI Setting You can view the WIFI connection status in the Network Setting interface. See Figure 5-35. You can view current connection status and IP address if there is a connection. © Copyright Qvis ®. All documentation rights reserved.
Page 93 Connect: Here you can click it to connect to the hotspot. System needs to turn off current connection and then connect to a new hotspot if there is connection of you selected one. See Figure 5-37. Figure 5-36 © Copyright Qvis ®. All documentation rights reserved.
Page 94 System does not support verification type WPA and WPA2. The display may become abnormal for the verification type and encryption type. After device successfully connected to the WIFI, you can view the hotspot name, IP address, subnet mask, default gateway and etc. See Figure 5-39. © Copyright Qvis ®. All documentation rights reserved.
Page 95 This function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. © Copyright Qvis ®. All documentation rights reserved.
Page 96 Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See F igure 5-42. X 3 7 2 H 3 7 2 H 3 7 2 H © Copyright Qvis ®. All documentation rights reserved.
Page 97 System also supports upload multiple DVRs to one FTP server. You can create multiple folders under this FTP. In Figure 5-35, select FTP and then double click mouse. You can see the following interface. See Figure 5-44. © Copyright Qvis ®. All documentation rights reserved.
Page 98 When interval value is 0, system uploads all corresponding files. After completed channel and weekday setup, you can set two periods for one each channel.  Alarm Centre This interface is reserved for you to develop. © Copyright Qvis ®. All documentation rights reserved.
Page 99 Open the tree list on the MG-SOFT MIB Browser; you can get the device configuration. Here you can see the device has how many video channels, audio channels, application version and etc. Note: Port conflict occurs when SNMP port and Trap port are the same. © Copyright Qvis ®. All documentation rights reserved.
Page 100 Please set proxy server address, port, and sub-device name at the device-end. Please enable the auto register function, the device will be able to auto register to the proxy server. 1) The setup interface is shown as in Figure 5-11. © Copyright Qvis ®. All documentation rights reserved.
Page 101: Alarm
Important: The server IP address can also be domain. But you need to register a domain name before you run proxy device server. 5.7.4 Alarm Please refer to chapter 4.7 Alarm Setup and Activation. 5.7.5 Detect Please refer to Chapter 4.6 Detect. © Copyright Qvis ®. All documentation rights reserved.
Page 102: Pan/Tilt/Zoom
Resolution: There are four options: 1920×1080, 1280×1024(default), 1280×720, 1024× 768. Please note the system needs to reboot to activate any new setup.  Image enhance: Check the box; you will be able to optimise the margins of the preview video. © Copyright Qvis ®. All documentation rights reserved.
Page 103 1 and 4-window mode, it is display channel 1/2/3/4. Save: Click this to save current setup to Favorites folder. Otherwise, you will not find current setup in the Favorites. Figure 5-12 © Copyright Qvis ®. All documentation rights reserved.
Page 104 After you enabled this function, login to the Web and you can select zero-channel encoding mode at the right corner of the interface . Select a mode; you can view the local preview video. Figure 5-14 © Copyright Qvis ®. All documentation rights reserved.
Page 105 System supports a max of 25-digital characters. If you select channel number as remote, all the analog channel names become read-only. The digital channel name is null if system can not get digital channel name. Figure 5-16 © Copyright Qvis ®. All documentation rights reserved.
Page 106: Default
After all the setups please click save button, system goes back to the previous menu. Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after selecting the default operation! © Copyright Qvis ®. All documentation rights reserved.
Page 107: Remote Device
 Manual add: Click it to add the IPC manually. The port number is 37777. The default user name is admin and password is admin. © Copyright Qvis ®. All documentation rights reserved.
Page 108 You can not add two or more devices in the Manual Add interface (Figure 5-19). Click OK button, system connects to the corresponding front-end device of current channel on the interface. Figure 5-19 © Copyright Qvis ®. All documentation rights reserved.
Page 109: Search
HDD operation: You can select a HDD mode from the dropdown list such as read-only or you delete all the data. Please note system needs to reboot to get all the modification activated. © Copyright Qvis ®. All documentation rights reserved.
Page 110 Each channel only corresponds with one HDD Group, while one HDD Group can store records from several channels.  HDD Group is only available for read-write HDD and self-defined disks, other types of hard disks cannot be set as HDD Group. © Copyright Qvis ®. All documentation rights reserved.
Page 111 HDD group 1 and HDD group 2 respectively. You can see the HDD group option has only two options 1 and 2 when you set corresponding HDD group of the channel. © Copyright Qvis ®. All documentation rights reserved.
Page 112 HDD. You can remove the HDD and then check the channel can record or not. You can see the channel does not record and you can not search the previous record now. Figure 5-21 © Copyright Qvis ®. All documentation rights reserved.
Page 113 Click Quota Setup button, you can go to Figure 5-23. Here you can set the each channel storage capacity in each HDD. Figure 5-23 Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 5-24. © Copyright Qvis ®. All documentation rights reserved.
Page 114: Abnormity
 Send email: System can send out email to alert you when alarm occurs.  Buzzer: Highlight the icon to enable this function. The buzzer beeps when alarm occurs. © Copyright Qvis ®. All documentation rights reserved.
Page 115: Alarm Output
These options allow you to set the proper alarm output. Please highlight icon to select the corresponding alarm output. After completing all the setup please click the OK button, system goes back to the previous menu. See Figure 5-69 Figure 5-69 © Copyright Qvis ®. All documentation rights reserved.
Page 116: Manual Record
You can set or change MAC address when you add or modify a user. The MAC address function is also valid for PSS login. Please note current function does not support IPV6. After all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 117 Here you can modify account password. Please select the account from the dropdown list, input the old password and then input the new password twice. Click the Save button to confirm current modification. Figure 5-71 © Copyright Qvis ®. All documentation rights reserved.
Page 118 Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account. © Copyright Qvis ®. All documentation rights reserved.
Page 119: Auto Maintain
This section allows you to adjust TV output setup. See Figure 5-75. Please drag slide bar to adjust each item. After all setup is complete please click OK button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 121: Card Overlay
There are two types: with or without the protocol according to client’s requirements. With the protocol: For ATM/POS protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number as well). © Copyright Qvis ®. All documentation rights reserved.
Page 122 Figure 5-79 Click Data button you can see an interface is shown as in Figure 5-80. Here you can set offset value, length, title according to your communication protocol and data package. . © Copyright Qvis ®. All documentation rights reserved.
Page 123: Config File Backup
 If you go to the configuration backup interface first and then insert the peripheral device, please click Refresh button to view the newly added device. © Copyright Qvis ®. All documentation rights reserved.
Page 124: Shutdown
Restart application: reboot DVR.  Shutdown: system shuts down and turns off power.  Restart system: system begins rebooting.  Switch user: you can use another account to log in. Figure 5-82 © Copyright Qvis ®. All documentation rights reserved.
Page 125: Auxiliary Menu
X 3 9 9 H 3 9 9 H 3 9 9 H X 4 0 0 H 4 0 0 H 4 0 0 H eight direction arrows. (Please note there are only four direction arrows in DVR front panel.) © Copyright Qvis ®. All documentation rights reserved.
Page 126: Intelligent Positioning Key
Figure 6-4 Here is a sheet for you reference. Name Function Function Shortcut Function Function Shortcut  Zoom Near  ► Focus Near │ │   Iris Close Open © Copyright Qvis ®. All documentation rights reserved.
Page 127: Preset /Patrol / Pattern /Border Function
X 4 0 4 H 4 0 4 H 4 0 4 H Here you can activate the following functions:  Preset  Tour(Patrol)  Pattern  Auto scan  Auto pan  Flip  Page Switch Figure 6-6 © Copyright Qvis ®. All documentation rights reserved.
Page 128: Preset Setup
Figure 6-8 6.2.4 Activate Patrol F igure 6-6 , input patrol number in the No. blank and click patrol button X 4 1 4 H 4 1 4 H 4 1 4 H © Copyright Qvis ®. All documentation rights reserved.
Page 129: Pattern Setup
X 4 2 2 H 4 2 2 H 4 2 2 H F igure 6-10 and click left limit button. X 4 2 3 H 4 2 3 H 4 2 3 H Repeat the above procedures to set right limit. Figure 6-10 © Copyright Qvis ®. All documentation rights reserved.
Page 130: Activate Border Function
Here you can set auxiliary function. Click page switch button again, system goes back to F igure 6-2 X 4 2 7 H 4 2 7 H 4 2 7 H Figure 6-11 © Copyright Qvis ®. All documentation rights reserved.
Page 131: Web Operation
10.10.3.16 in IE address column. See Figure 7-1. Input your IP address here. Figure 7-1 System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button. © Copyright Qvis ®. All documentation rights reserved.
Page 132 Please input your user name and password. Default factory name is admin and password is admin. Then you can select the login mode: LAN and WAN. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
Page 133: Lan Mode
Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 7-4. Figure 7-4 Please refer to Figure 7-5 for main stream and extra stream switch information. © Copyright Qvis ®. All documentation rights reserved.
Page 134 See Figure 7-7. Click it again, system restores previous record mode.. Figure 7-7  Section 5: Local play button. The Web can playback the saved (Extension name is ‘.dav’) files in the PC-end. © Copyright Qvis ®. All documentation rights reserved.
Page 135  Section 7: PTZ operation panel. Please refer to chapter 7.5 for detailed information.  Section 8: Image setup and alarm setup. Please refer to chapter 7.6 for detailed information. Figure 7-9 © Copyright Qvis ®. All documentation rights reserved.
Page 136: Real-Time Monitor
There are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key. Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. It can realize PTZ automatically. © Copyright Qvis ®. All documentation rights reserved.
Page 137 You can select one option and then click AUX on or AUX off button. You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 7-12 © Copyright Qvis ®. All documentation rights reserved.
Page 138: Image/Relay-Out
7.6.3 Multiple-channel preview System allows you to preview several channels on one channel. It supports 1/4/8/9-window. See Figure 7-15. Please note only the product of this icon can support current function. Figure 7-15 © Copyright Qvis ®. All documentation rights reserved.
Page 139: Wan Login
In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null. You can select different channel and different monitor mode at the bottom of the interface. See Figure 7-17. © Copyright Qvis ®. All documentation rights reserved.
Page 140 For bandwidth consideration, system can not support monitor and playback at the same time. System auto closes monitor or playback interface when you are searching setup in the configuration interface. It is to enhance search speed. © Copyright Qvis ®. All documentation rights reserved.
Page 141: Setup
Please note the video may become hazy if the value is too high. The value ranges from 0 to 100.The recommended value ranges from 40 to 60. © Copyright Qvis ®. All documentation rights reserved.
Page 143 Watermark enable Here you can select watermark bit stream, watermark mode and watermark character. Default character is DigitalCCTV. The max length is 85-digit. The character can only include number, character and underline. © Copyright Qvis ®. All documentation rights reserved.
Page 144 It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Click it; you can copy current channel setup to other Copy channel(s). © Copyright Qvis ®. All documentation rights reserved.
Page 145: Video Overlay
You can enable this function so that system overlays channel information in video window. You can use the mouse to drag the channel title position. You can view channel title on the live video of the WEB or the playback video. © Copyright Qvis ®. All documentation rights reserved.
Page 146 C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 7-22  Channel Name Here you can set channel name. See Figure 7-23. Figure 7-23 © Copyright Qvis ®. All documentation rights reserved.
Page 147: Network
Please use the keyboard to input the corresponding number to modify the IP address and then set the corresponding subnet mask and the default gateway. Preferred DNS DNS IP address. Alternate DNS Alternate DNS IP address. © Copyright Qvis ®. All documentation rights reserved.
Page 148 The default value is 37778. You can input the actual port UDP port number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. RTSP port The default value is 554. © Copyright Qvis ®. All documentation rights reserved.
Page 149: Wifi
Double click a name to connect to it. Click Refresh button, you can view latest connection status.   3G: CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 7-27. Figure 7-27 © Copyright Qvis ®. All documentation rights reserved.
Page 150 3G: Mobile The mobile setup interface is shown as in Figure 7-29. Here you can activate or turn off the 3G connected phone/mobile phone, or the phone you set to get alarm message. © Copyright Qvis ®. All documentation rights reserved.
Page 151: Pppoe
Note: you need to use previous IP address in the LAN to login the device. Please go to the IP address item to via the device current device information. You can access the client-end via this new address. Figure 7-30 © Copyright Qvis ®. All documentation rights reserved.
Page 152 The password you input to log in the server. Update period Device sends out alive signal to the server regularly. You can set interval value between the device and DDNS server here. © Copyright Qvis ®. All documentation rights reserved.
Page 153: Ip Filter
The IP filter interface is shown as in Figure 7-32. After you enabled trusted sites function, only the IP listed below can access current DVR. If you enable blocked sites function, the following listed IP addresses can not access current DVR. © Copyright Qvis ®. All documentation rights reserved.
Page 155  UPnP It allows you to establish the mapping relationship between the LAN and the public network. Here you can also add, modify or remove UPnP item. See Figure 7-34. © Copyright Qvis ®. All documentation rights reserved.
Page 156  SNMP The SNMP interface is shown as in Figure 7-35. The SNMP allows the communication between the network management work station software and the proxy of the managed device. Figure 7-35 © Copyright Qvis ®. All documentation rights reserved.
Page 157 CPU load. The source host can just send out one data to transit. This function also depends on the relationship of the group member and group of the outer. © Copyright Qvis ®. All documentation rights reserved.
Page 158 Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data. Figure 7-37 © Copyright Qvis ®. All documentation rights reserved.
Page 160 There are six levels. The sixth level has the highest sensitivity. Region: If you select motion detection type, you can click this button to set motion detection zone. The interface is shown as in © Copyright Qvis ®. All documentation rights reserved.
Page 161  Video Dectect: Video Loss The video loss interface is shown as in Figure 7-42. After analysis video, system can generate a video loss alarm when the detected moving signal reached the sensitivity you set here. © Copyright Qvis ®. All documentation rights reserved.
Page 162 After analysis video, system can generate a camera masking alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter motion-detect for detailed information. Figure 7-43 © Copyright Qvis ®. All documentation rights reserved.
Page 163 Before operation, please make sure you have properly connected alarm devices such as buzz er. The input mode includes local alarm and network alarm. The local alarm interface is shown as in Figure 7-44. Figure 7-44 Figure 7-45 © Copyright Qvis ®. All documentation rights reserved.
Page 164 Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs. Alarm upload System can upload the alarm signal to the centre (Including alarm centre. © Copyright Qvis ®. All documentation rights reserved.
Page 165 The network alarm interface is shown as in Figure 7-47. Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type setup. For reset setups, please refer to chapter . Figure 7-47 © Copyright Qvis ®. All documentation rights reserved.
Page 166 Here you can set alarm output channel mode. See Figure 7-48. Figure 7-48  Abnormity It includes six statuses: No disk, disk error, net disconnection, IP conflict and MAC conflict. See Figure 7-49 through Figure 7-54. Figure 7-49 Figure 7-50 © Copyright Qvis ®. All documentation rights reserved.
Page 168: Storage
You can view the current time period setup from the color bar.  Green color stands for the general record/snapshot.  Yellow color stands for the motion detect record/snapshot..  Red color stands for the alarm record/snapshot. © Copyright Qvis ®. All documentation rights reserved.
Page 170 5/6/7. If you wan to save current setup of channel 1 to all channels, you can click the first box “ALL”. Click the OK button to save current copy setup. Click the OK button in the Encode interface, the copy function succeeded. © Copyright Qvis ®. All documentation rights reserved.
Page 171 Here is for you to set HDD group. See Figure 7-60. Figure 7-60  Storage: HDD Channel The HDD channel interface is shown as in Figure 7-61. Here you can set channel group. Figure 7-61 © Copyright Qvis ®. All documentation rights reserved.
Page 172 The FTP function is on if you check the Enable box here. When network is offline or malfunction, system can save record or picture to HDD. Figure 7-62  Record control The record control interface is shown as in Figure 7-63. Figure 7-63 © Copyright Qvis ®. All documentation rights reserved.
Page 173: System
Check the corresponding All button, you can enable or disable all Start all/ channels record. stop all 7.8.6 System  General: General The general interface includes General, date/time and holiday setup. The general interface is shown as in Figure 7-64. Figure 7-64 © Copyright Qvis ®. All documentation rights reserved.
Page 174 Here is for you to specify record duration. The value ranges from 1 Pack to 120 minutes. Default value is 60 minutes. duration  General: Date and time The date and time interface is shown as in Figure 7-65 Figure 7-65 © Copyright Qvis ®. All documentation rights reserved.
Page 175 It is to set the sync periods between the device and the time server. Interval  General: Holiday Setup Holiday setup interface is shown as in Figure 7-66. Here you can check the box here to enable this function and then set. Figure 7-66 © Copyright Qvis ®. All documentation rights reserved.
Page 176 Here you can input the user name and password and then select one group for current user. Please note the user rights shall not exceed the group right setup. For convenient setup, please make sure the general user has the lower rights setup than the admin. © Copyright Qvis ®. All documentation rights reserved.
Page 177 Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit. It shall include the number only. For the user of the account rights, he can modify the password of other users. © Copyright Qvis ®. All documentation rights reserved.
Page 178 Figure 7-69  Account: Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 7-70. Figure 7-70 © Copyright Qvis ®. All documentation rights reserved.
Page 179 PTZ control and etc. Figure 7-71 Modify group Click the modify group button, you can see an interface is shown as in Figure 7-72. Here you can modify group information such as remarks and rights. © Copyright Qvis ®. All documentation rights reserved.
Page 180 Figure 7-72  Display: GUI Display interface includes GUI, TV adjust, Tour and video matrix. Here you can set background color and transparency level. See Figure 7-73. Figure 7-73 © Copyright Qvis ®. All documentation rights reserved.
Page 181 Check the box; you can optimize the margin of the preview video. Image enhance  Display: TV Adjust It is to set TV output region. See Figure 7-74. Figure 7-74 © Copyright Qvis ®. All documentation rights reserved.
Page 182 Here you can set window mode and channel group. System can Split support 1/4/8/9/16/25/36-window according to device channel amount. Here you can set motion detect tour/alarm tour window mode. Motion System supports 1/8-window now. tour/Alarm tour © Copyright Qvis ®. All documentation rights reserved.
Page 183 Figure 7-76  Default The default setup interface is shown as in Figure 7-77. Here you can select Channel/Network/Event/Storage/System. Or you can check the All box to select all items. Figure 7-77 © Copyright Qvis ®. All documentation rights reserved.
Page 184 Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Figure 7-79 © Copyright Qvis ®. All documentation rights reserved.
Page 185 *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device. Important: Improper upgrade program may result in device malfunction! Figure 7-80  RS232 The RS232 interface is shown as in Figure 7-81. Figure 7-81 © Copyright Qvis ®. All documentation rights reserved.
Page 186  Decoder A (B) line connects with DVR A (B) line. Click Save button after you complete setup, you can go back to the monitor interface to control speed dome. Figure 7-82 © Copyright Qvis ®. All documentation rights reserved.
Page 187: Advanced
Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list. © Copyright Qvis ®. All documentation rights reserved.
Page 188 Usually you do not need to set source port and target port. There are total four group IP. The record channel applies to one group (optional) only. Six frame ID groups verification can guarantee information validity and legal. © Copyright Qvis ®. All documentation rights reserved.
Page 189: Information
The version interface is shown as in Figure 7-86. Here you can view system hardware features, software version, release date and etc. Please note the following information is for reference only. Figure 7-86 © Copyright Qvis ®. All documentation rights reserved.
Page 190 You can click this button to delete all displayed log files. Please note system does not support clear by type. You can click this button to backup log files to current PC. Backup © Copyright Qvis ®. All documentation rights reserved.
Page 191: Search
You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files. Figure 7-89 © Copyright Qvis ®. All documentation rights reserved.
Page 192 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in Figure 7-91, then you can specify file name and path to download the file(s) to your local pc. Figure 7-91 © Copyright Qvis ®. All documentation rights reserved.
Page 193 See Figure 7-93. Please select file(s) from the list and then Click Start backup button. Please refer to chapter to set device download path. Figure 7-93 © Copyright Qvis ®. All documentation rights reserved.
Page 194: Alarm
Alarm Play alarm System sends out alarm sound when an alarm Sound sound occurs. You can specify as you wish. Sound path Here you can specify alarm sound file. © Copyright Qvis ®. All documentation rights reserved.
Page 195: Log Out
7.12 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un- installation might result in error. © Copyright Qvis ®. All documentation rights reserved.
Page 196: Faq
Brightness is set to 0. Please restore factory default setup.  There is no video input signal or it is too weak.  Check privacy mask setup or your screen saver.  DVR hardware malfunctions. © Copyright Qvis ®. All documentation rights reserved.
Page 197 9. There is audio when monitor but there is no audio when system playback. These are the possiblilities:  Setup is not correct. Please enable audio function  Corresponding channel has no video input. Playback is not continuous when the screen is blue. © Copyright Qvis ®. All documentation rights reserved.
Page 198 No dx8.1 or higher. Please upgrade display card driver.  Network connection error.  Network setup error.  Password or user name is invalid.  Client-end is not compatible with DVR program. © Copyright Qvis ®. All documentation rights reserved.
Page 199 Alarm setup is not correct.  Alarm output has been opened manually.  Input device error or connection is not correct.  Some program versions may have this problem. Please upgrade your system. © Copyright Qvis ®. All documentation rights reserved.
Page 200 You need to implement server certificate again if you have changed device IP.  You need to download root certificate if it is your first time to use HTTPS on current PC. © Copyright Qvis ®. All documentation rights reserved.
Page 201 Note: Please make sure the IP or domain information is the same as your device IP or domain name. Figure 8-2 You can see the corresponding prompt. See Figure 8-3. Now the server certificate is successfully created. © Copyright Qvis ®. All documentation rights reserved.
Page 202 The following instructions will show you how to download a root certificate: In Figure 8-3, click button, system pops up a dialogue box. See Figure 8-4. Figure 8-4 Click Open button, you will go to the following interface. See Figure 8-5 © Copyright Qvis ®. All documentation rights reserved.
Page 203 Click Install certificate button, you can go to certificate wizard. See Figure 8-6. Figure 8-6 Click Next button to continue. Now you can select a location for the certificate. See Figure 8-7. © Copyright Qvis ®. All documentation rights reserved.
Page 204 Click Next button, you can see the certificate import process is complete. See Figure 8-8 Figure 8-8 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 8-9. © Copyright Qvis ®. All documentation rights reserved.
Page 205 Figure 8-10 25. When I login via HTTPS, a dialogue says the certificate has expired or is not valid yet. Please make sure your PC time is the same as the device time. © Copyright Qvis ®. All documentation rights reserved.
Page 206 Otherwise it may result in HDD malfunction.  Please make sure the device is away from the direct sunlight or other heating sources. Please keep the sound ventilation.  Please check and maintain the device regularly. © Copyright Qvis ®. All documentation rights reserved.
Page 207 Alternatively scan this QR code with your smart phone to be directed instantly to our website: Download our mobile apps to remotely operate your DVR on the move: iPhone iPad Android Android Tablet © Copyright Qvis ®. All documentation rights reserved.

Qvis I-ZEUS-HYBRID1 User Manual

1 Features and Specifications

2 Overview and Controls

3 Installation and Connections

4 Overview of Navigation and Controls

5 Understanding of Menu Operations and Controls

6 Auxiliary Menu

7 Web Operation

8 Faq

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Qvis I-ZEUS-HYBRID1

Summary of Contents for Qvis I-ZEUS-HYBRID1

Table of Contents
