Iapollo SMART dvr

4/8/16 Channel Full Realtime D1

Digital Video Recorder

User's Manual

V 1.0.0 08/2013

Table of Contents

Need help?

Do you have a question about the Iapollo SMART dvr and is the answer not in the manual?

Questions and answers

Summary of Contents for Qvis Iapollo SMART dvr

Page 1 Iapollo SMART dvr 4/8/16 Channel Full Realtime D1 Digital Video Recorder User’s Manual V 1.0.0 08/2013...
Page 3: Table Of Contents
Smart Search ........................21 4.4.2 Accurate playback by time ....................21 4.4.3 Mark Playback ........................22 4.4.4 Multiple-channel Preview ..................... 24 4.5 Schedule ............................24 4.5.1 Schedule Menu ........................24 4.5.2 Snapshot ..........................27 © Copyright Qvis ®. All documentation rights reserved.
Page 4 Schedule ..........................50 5.3.4 Network ..........................50 5.3.5 Detect ........................... 69 5.3.6 Display ..........................69 5.3.7 Default ..........................71 5.4 Search ............................72 5.5 Advanced ............................ 73 5.5.1 HDD Management ....................... 73 © Copyright Qvis ®. All documentation rights reserved.
Page 5 Activate Border Function ....................100 6.2.9 Flip ............................. 100 WEB OPERATION ..................101 7.1 Network Connection......................... 101 7.2 Login ............................101 7.3 LAN Mode ..........................103 7.4 Real-time Monitor ........................106 7.5 PTZ ............................. 106 © Copyright Qvis ®. All documentation rights reserved.
Page 6 System ..........................143 7.8.6 Advanced ........................... 157 7.8.7 Information ......................... 159 7.9 Search ............................161 7.10 Alarm ............................. 164 7.11 Log out ..........................165 7.12 Un-install Web Control ......................165 FAQ ........................ 166 © Copyright Qvis ®. All documentation rights reserved.
Page 7 Here you can find information about the iApollo Mini DVR’s features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully! © Copyright Qvis ®. All documentation rights reserved.
Page 8: Important Safeguards And Warnings
 Improper battery use may result in hazardous consequences such as the start of fires, an explosion, or personal injury!  When you need to replace the battery, please make sure you replace I with the same battery model! © Copyright Qvis ®. All documentation rights reserved.
Page 9  Do not put other devices on the top of the NVR；  Be installed in well ventilated place; do not block the vent. Accessories Check the following accessories after opening the box： *Please refer to the packing list in the box* © Copyright Qvis ®. All documentation rights reserved. viii...
Page 10: Features And Specifications
 Supports each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download, and more.  Support various playback modes: slow play, fast play, backward play and frame by frame play. © Copyright Qvis ®. All documentation rights reserved.
Page 11: Specifications
P- P, 75Ω) 1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video Video monitor signal output. Video Output 1-ch VGA output. Support TV/VGA video output at the same time. Video Support PAL/NTSC. Standard © Copyright Qvis ®. All documentation rights reserved.
Page 12 When hard disk is full, system can overwrite previous video Repeat Way file. Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame Mode playback and reverse play mode. © Copyright Qvis ®. All documentation rights reserved.
Page 13 On-line user Display current on-line user User Multi-lever user management; various management modes Manageme User Integrated management for local user, serial port user and Management network user. Configurable user power. © Copyright Qvis ®. All documentation rights reserved.
Page 14 Parameter Working 0℃－＋55℃ Temperature Working 10%－90% Humidity Air Pressure 86kpa－106kpa SMART 1U case. 205(W) x205 (D) SMART 1U case. Dimension x41mm(H) 270(W) x205 (D) x41mm(H) Weight 1.0-1.5KG(Exclude HDD) Installation Desktop installation Mode © Copyright Qvis ®. All documentation rights reserved.
Page 15: Front Panel And Rear Panel
The red light turns on when the power connection Power indicator light is OK. HDD status indictor light The red light turns on when HDD is abnormal. USB port © Copyright Qvis ®. All documentation rights reserved.
Page 16: Rear Panel
Figure 2-2 Figure 2-3 Figure 2-4 Please refer to the following sheet for detailed information: Name Name Name Video input Video output VGA output USB port Network port Power socket GND port © Copyright Qvis ®. All documentation rights reserved.
Page 17: Mouse Operation
In numeral input box: Increase or decrease numeral value. button Switch the items in the check box. Page up or page down Move mouse Select current control or move control Drag mouse Select motion detection zone Select privacy mask zone. © Copyright Qvis ®. All documentation rights reserved.
Page 19: Overview Of Navigation And Controls
Username: admin. Password: admin. (administrator, local and network)  Username: 888888. Password: 888888. (administrator, local only)  Username: 666666. Password: 666666(Lower authority user who can only monitor, playback, backup and etc.)  Username: default. Password: default(hidden user) © Copyright Qvis ®. All documentation rights reserved.
Page 20: Main Menu
There are two ways for you to log out. One is from menu option: In the main menu, click shutdown button, you can see an interface is shown as below. See Figure 4-4. © Copyright Qvis ®. All documentation rights reserved.
Page 21: Auto Resume After Power Failure
If you want to change system date and time, you can refer to general settings (Main Menu->Setting->General). If you want to modify the channel name, please refer to the display settings (Main Menu->Setting->Display). Recording status Video loss Motion detection Camera lock © Copyright Qvis ®. All documentation rights reserved.
Page 22  Please go to the Main Menu->General to set real-time playback time.  System may pop up a dialogue box if there is no such record in current channel. © Copyright Qvis ®. All documentation rights reserved.
Page 23: Manual Record
Right click mouse or in the main menu, Advanced->Manual Record.  In live viewing mode, click record button in the front panel or record button in the remote control. Manual record menu is shown as in Figure 4-7. © Copyright Qvis ®. All documentation rights reserved.
Page 24: Basic Operation
Please check current channel status: ‘○’ means it is not in recording status, ‘●’ means it is in recording status. You can use mouse or direction key to highlight channel number. See Figure 4-8. Figure 4-8 © Copyright Qvis ®. All documentation rights reserved.
Page 25: Enable All Channel Recording
When system is in manual recording, all scheduled set up you have set in will be null ((Main menu->Setting->Schedule)). You can see indication light in front panel turns on, system begins manual record now. Figure 4-10 © Copyright Qvis ®. All documentation rights reserved.
Page 26: Stop All Channel Recording
Click search button in the main menu, search interface is shown as below. See Figure 4-12. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file. Figure 4-12 © Copyright Qvis ®. All documentation rights reserved.
Page 27 Click it to go to mark file list interface. You can view all mark information of current channel by time. Please refer to chapter 4.4.3 for detailed information. Mark file Please note only the product of this icon supports mark function. list button © Copyright Qvis ®. All documentation rights reserved.
Page 28 The time bar is beginning with 0 o'clock when you are setting the configuration. unit The time bar zooms in the period of the current playback time when you are playing the file. © Copyright Qvis ®. All documentation rights reserved.
Page 29 During the file playback process, you can switch to other channel via the switch dropdown list or rolling the mouse. channel This function is null if there is no record file or system is in smart search when process. playback © Copyright Qvis ®. All documentation rights reserved.
Page 30: Smart Search
Search button, you can view all the record files after 06:00.00 (The records includes current time.). Click Play button, you can see system begins play from 06:00.00. See Figure 4-14. © Copyright Qvis ®. All documentation rights reserved.
Page 31: Mark Playback
It is very easy for you to get the important video information.  Add Mark When system is playback, click Mark button , you can go to the following interface. See Figure 4-15. © Copyright Qvis ®. All documentation rights reserved.
Page 32 4-16 Manager interface. See Figure . System can manage all the record mark information of current channel by default. You can view all mark information of current channel by time. Figure 4-16 © Copyright Qvis ®. All documentation rights reserved.
Page 33: Multiple-Channel Preview
In the main menu, from setting to schedule, you can go to schedule menu. See Figure 4-18.  Channel: Please select the channel number first. You can select “all” if you want to set for the whole channels. © Copyright Qvis ®. All documentation rights reserved.
Page 34 The white means the MD and alarm record is valid. Once you have set to record when the MD and alarm occurs, system will not record neither motion detect occurs nor the alarm occurs. Figure 4-18 © Copyright Qvis ®. All documentation rights reserved.
Page 35 Click the OK button to save current copy setup. Click the OK button in the Record interface so the copy function works. Please note, if you select ALL in Figure 4-20, the record setup of all channels are the same and the Copy button becomes hidden. Figure 4-20 © Copyright Qvis ®. All documentation rights reserved.
Page 36: Snapshot
Figure 4-21. In Schedule interface, please enable snapshot function. See interface on the right of Figure 4-21. Please refer to the following figure for detailed information. See Figure 4-21: Figure 4-21 © Copyright Qvis ®. All documentation rights reserved.
Page 37 Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot. © Copyright Qvis ®. All documentation rights reserved.
Page 38: Image Ftp
Event type: From the dropdown list you can select motion detection type.  Channel: Select a channel from the dropdown list to set motion detect function.  Enable: Check the box here to enable motion detect function. © Copyright Qvis ®. All documentation rights reserved.
Page 39 Region, you can set motion detect area. The default setup is whole region. The blue zones are the selected area. Please set sensitivity and click Test button, you can see system © Copyright Qvis ®. All documentation rights reserved.
Page 40 In Figure 4-25, you can left click mouse and then drag it to set a region for motion detection. Click Fn to switch between arm/withdraw motion detection. After setting, click enter button to exit. Figure 4-24 Figure 4-25 © Copyright Qvis ®. All documentation rights reserved.
Page 42: Video Loss
You can enable preset/tour/pattern activation operation when video loss occurs.  System only enables video loss function during the period you set here. It is null for motion detect or camera masking type. © Copyright Qvis ®. All documentation rights reserved.
Page 43: Camera Masking
It is null for other detect types.  System only enables camera masking function during the period you set here. It is null for motion detect or video loss type. © Copyright Qvis ®. All documentation rights reserved.
Page 44: Backup
Click backup button, you can see an interface is shown as in Figure 4-33. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes USB burner, flash disk, SD card, and portable HDD. © Copyright Qvis ®. All documentation rights reserved.
Page 45: Backup
Figure 4-34 Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. © Copyright Qvis ®. All documentation rights reserved.
Page 46: Ptz Control And Color Setup
Please follow the procedures below to go on cable connection  Connect the dome RS485 port to DVR 485 port.  Connect dome video output cable to DVR video input port.  Connect power adapter to the dome. © Copyright Qvis ®. All documentation rights reserved.
Page 47: Ptz Setup
After completing all the setting please click save button. Right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 4-37. © Copyright Qvis ®. All documentation rights reserved.
Page 48 Please click icon to adjust zoom, focus and iris. Figure 4-38 In Figure 4-38, please click direction arrows (See Figure 4-39) to adjust PTZ position. There are total 8 direction arrows. Figure 4-39 © Copyright Qvis ®. All documentation rights reserved.
Page 49: Intelligent Positioning Key
Pattern  Border Figure 4-41 Figure 4-38, click page switch button, the interface is shown as in Figure 4-42. X 3 2 8 H 3 2 8 H 3 2 8 H © Copyright Qvis ®. All documentation rights reserved.
Page 50: 1Preset Setup
In Figure 4-38, use the eight direction arrows to adjust camera to the proper position. In Figure 4-41, click preset button and input preset number. The interface is shown as in Figure 4-43. Now you can add this preset to one tour. Figure 4-43 © Copyright Qvis ®. All documentation rights reserved.
Page 51: Activate Preset
Figure 4-45 4.9.6 Activate Pattern Function Figure 4-39, input mode value in the No. blank, and click pattern button. X 3 4 6 H 3 4 6 H 3 4 6 H © Copyright Qvis ®. All documentation rights reserved.
Page 52: Auto Scan Setup
4-47. Here you can set auxiliary function. The aux value has relation ship with the Aux button of the decoder. Click page switch button again, system goes back to Figure 4-38. Figure 4-47 © Copyright Qvis ®. All documentation rights reserved.
Page 53: Understanding Of Menu Operations And Controls
Encode Schedule RS232 Menu Network Alarm Detect Pan/ Tilt/Zoom Display Default Search Advanced HDD Management Alarm Output Abnormality Manual Record Account Auto Maintain TV Adjust Video Matrix Title Overlay Config Backup Shutdown © Copyright Qvis ®. All documentation rights reserved.
Page 54: Main Menu
You can see an interface is shown as in Figure 5-4. Here you can set start time and end time by setting corresponding week setup. In Figure 5-4, enable date button, you can © Copyright Qvis ®. All documentation rights reserved.
Page 55 Note: Since system time is very important, do not modify time casually unless you must! Before your time modification, please stop record operation first! After completing all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 57: Encode
You can see an interface is shown as in Figure 5-10. You can see current channel number is grey. Please check the number to select the channel or © Copyright Qvis ®. All documentation rights reserved.
Page 58 Audio/video enable box, overlay button and the copy button is shield. See Figure 5-11. Please highlight icon to select the corresponding function. Figure 5-8 Figure 5-9 Figure 5-10 © Copyright Qvis ®. All documentation rights reserved.
Page 59: Schedule
IP/Subnet mask/Gateway display as zero. You need to disable DHCP function to view current IP information. Besides, when PPPoE is operating, you can not modify IP/Subnet mask /Gateway.  TCP port: Default value is 37777. You can change if necessary. © Copyright Qvis ®. All documentation rights reserved.
Page 60 The eth0 and eth1 are both working now and bearing the network load. Their network load are general the same. The system is shown as offline once these two cards are both offline. Please note these two cards shall be in the same LAN. © Copyright Qvis ®. All documentation rights reserved.
Page 61 DNS, the input value shall be 128-digit. It shall not be left in blank. After completing all the setups please click save button, system goes back to the previous menu. Figure 5-12 Figure 5-13 © Copyright Qvis ®. All documentation rights reserved.
Page 62 System only checks start address if you add IP address. System check start address and end address if you add IP section and the end address shall be larger than the start © Copyright Qvis ®. All documentation rights reserved.
Page 63 If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.  System supports add MAC address. Figure 5-15 Figure 5-16 © Copyright Qvis ®. All documentation rights reserved.
Page 64 Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 © Copyright Qvis ®. All documentation rights reserved.
Page 65 -TTL=1 When sending out telegraph -For example 224.0.0.1 All systems in the sub-net 224.0.0.2 All routers in the sub-net 224.0.0.4 DVMRP router 224.0.0.5 OSPF router 224.0.0.13 PIMv2 router  Administrative scoped addressees -239.0.0.0-239.255.255.255 -Private address space © Copyright Qvis ®. All documentation rights reserved.
Page 66 DDNS setup interface is shown as in Figure 5-21. You need a PC with a fixed IP on the internet and also DDNS software running on it as well. In other words, this PC is a DNS (domain name server). © Copyright Qvis ®. All documentation rights reserved.
Page 67 Device IP is not fixed if you use ADSL to login to the network. The DDNS function allows you to access the DVR via the registered domain name. Besides the general DDNS, the Quick DDNS works with the device from the manufacturer so that it can add the extension function. © Copyright Qvis ®. All documentation rights reserved.
Page 68 : ：It shows that the function of port mapping is enabled in this port. Enable Switch  List：  Service name：Defined by user.  Protocol： Protocol type  Internal port：Port that has been mapped in the router. © Copyright Qvis ®. All documentation rights reserved.
Page 69 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission. Figure 5-22 Figure 5-23 © Copyright Qvis ®. All documentation rights reserved.
Page 70 Connect: Here you can click it to connect to the hotspot. System needs to turn off current connection and then connect to a new hotspot if there is connection of you selected one. See Figure 5-26. © Copyright Qvis ®. All documentation rights reserved.
Page 71 Figure 5-25 Figure 5-26 After successfully connecting, you can see the following interface. You can see it is connected now. See Figure 5-26. © Copyright Qvis ®. All documentation rights reserved.
Page 72 After device successfully connected to the WIFI, you can view the hotspot name, IP address, subnet mask, default gateway and etc. See Figure 5-28. Figure 5-28 © Copyright Qvis ®. All documentation rights reserved.
Page 73 This function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Figure 5-29 © Copyright Qvis ®. All documentation rights reserved.
Page 75 At the same time, you can set two periods, three record files for different channels.  Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. See Figure 5-34. Figure 5-33 © Copyright Qvis ®. All documentation rights reserved.
Page 76 Run MG-SOFT MIB Browser to load the file from the previous step to the software.  Input the device IP you want to manage in the MG-SOFT MIB Browser. Please set the corresponding version for your future reference. © Copyright Qvis ®. All documentation rights reserved.
Page 77 Please set proxy server address, port, and sub-device name at the device-end. Please enable the auto register function, the device can auto register to the proxy server. 1) The setup interface is shown as in Figure 5-37. © Copyright Qvis ®. All documentation rights reserved.
Page 78: Detect
Channel display: You can select to channel name or not when system is playback.  Resolution: There are four options: 1920×1080, 1280×1024(default),1280×720,1024× 768. Please note the system needs to reboot to activate current setup. © Copyright Qvis ®. All documentation rights reserved.
Page 79 In Figure 5-38, click modify button after channel. You can see an interface is shown as in Figure 5-39. Please note all your modification here applies to local end only. You need to refresh web or client-end to get the latest channel name. System max support 25-digital character. © Copyright Qvis ®. All documentation rights reserved.
Page 80: Default
X 3 8 1 H 3 8 1 H 3 8 1 H  Select all  General  Encode  Schedule  RS232  Network  Alarm  Detect  Pan/tilt/zoom  Display  Channel name © Copyright Qvis ®. All documentation rights reserved.
Page 81: Search
Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! Figure 5-41 5.4 Search Please refer to chapter 4.4 Search. © Copyright Qvis ®. All documentation rights reserved.
Page 82: Advanced
HDD operation: You can select HDD mode from the dropdown list such as read-only or you can erase all data in the HDD. Please note system needs to reboot to get all the modification activated. © Copyright Qvis ®. All documentation rights reserved.
Page 83 HDD Group. Important:  Current series software version can only set the HDD group operation of the read-write HDDs. It is not for the redundancy HDD or read-only HDD. © Copyright Qvis ®. All documentation rights reserved.
Page 84 When you set the channel setup, please select the corresponding channel such as 1 and 2, and then select the HDD group such as 1. Click the Save button, you can complete the setup. © Copyright Qvis ®. All documentation rights reserved.
Page 85 You can see the channel does not record and you can not search the previous record now. Figure 5-46 Channel Quota Please note only the product of the quota setup icon supports this function. Here you can set channel storage capacity. See Figure 5-47. © Copyright Qvis ®. All documentation rights reserved.
Page 86 Click Quota Setup button, you can go to Figure 5-48. Here you can set the each channel storage capacity in each HDD. Figure 5-48 Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 5-49. © Copyright Qvis ®. All documentation rights reserved.
Page 87: Abnormality
 Send email: System can send out email to alert you when alarm occurs.  Buzzer: Highlight the icon to enable this function. The buzzer beeps when alarm occurs. Figure 5-50 © Copyright Qvis ®. All documentation rights reserved.
Page 88: Alarm Output
 System account adopts two-level management: group and user. System max supports 20 user groups and 64 users.  For group or user management, there are two levels: admin and user. © Copyright Qvis ®. All documentation rights reserved.
Page 89 Please select the account from the dropdown list, input the old password and then input the new password twice. Click the Save button to confirm current modification. For the users of user account right, it can modify password of other users. © Copyright Qvis ®. All documentation rights reserved.
Page 90 PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc. The modify group interface is similar to the Figure 5-54. Figure 5-54 © Copyright Qvis ®. All documentation rights reserved.
Page 91: Auto Maintenance
Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 5-56. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 92: Tv Adjust
After all the setups please click OK button, system goes back to the previous menu. Figure 5-57 5.5.8 Video Matrix Here you can set matrix output channel and its interval. See Figure 5-58. It can support the 1/4/9/16-window sport tour and you can specify the interval. © Copyright Qvis ®. All documentation rights reserved.
Page 93: Card Overlay
Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list. Figure 5-59 © Copyright Qvis ®. All documentation rights reserved.
Page 94 Usually you do not need to set source port and target port. There are total four groups IP. The record channel applies to one group (optional) only. Six frame ID groups verification can guarantee information validity and legal. © Copyright Qvis ®. All documentation rights reserved.
Page 95: Config Backup
You need to select a folder first. You can see a dialogue box asking you to select a folder if you are selecting a file. System pops up a dialogue box if there is no configuration © Copyright Qvis ®. All documentation rights reserved.
Page 96: Information
Here is for you to view system information. There are total six items: HDD (hard disk information), BPS (data stream statistics), log, version, online user and network information. See Figure 5-64. Figure 5-64 © Copyright Qvis ®. All documentation rights reserved.
Page 97: Hdd Information
Figure 5-65 Tips: Please click Fn button or left click mouse to view HDD record time and HDD type and time. Double click the HDD information; you will see the HDD SMART information. © Copyright Qvis ®. All documentation rights reserved.
Page 98: Bps
See Figure 5-68. Here you can use rolling bar to view information, or you can use Page up/Page down to view other log information. For the alarm event log such as video loss, you can click the Playback button at the bottom right corner to playback. © Copyright Qvis ®. All documentation rights reserved.
Page 99: Version
You can also update system here. See Figure 5-69.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update. © Copyright Qvis ®. All documentation rights reserved.
Page 100: Online Users
You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System refreshes current interface every five seconds to detect there is any newly added or deleted user. Figure 5-70 © Copyright Qvis ®. All documentation rights reserved.
Page 101: Network Information
The file is named after “Network adapter name+time”. You can use software such as Wireshark to open the packets on the PC for the professional engineer to solve complicated problems. Figure 5-71 © Copyright Qvis ®. All documentation rights reserved.
Page 102 Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected. Click one network adapter, you can view the flow statistics such as send rate and receive rate at the top panel Figure 5-72 © Copyright Qvis ®. All documentation rights reserved.
Page 103: Shutdown
Restart application: reboot DVR.  Shutdown: system shuts down and turns off power.  Restart system: system begins rebooting.  Switch user: you can use another account to log in. Figure 5-73 © Copyright Qvis ®. All documentation rights reserved.
Page 104: About Auxiliary Menu
X 3 9 8 H 3 9 8 H 3 9 8 H Here you can set the following items:  Zoom  Focus  Iris Please click icon to adjust zoom, focus and Iris. Figure 6-2 © Copyright Qvis ®. All documentation rights reserved.
Page 105: Intelligent Positioning Key
The interface is shown as below: X 4 0 2 H 4 0 2 H 4 0 2 H Here you can set the following items:  Preset  Patrol  Pattern  Border © Copyright Qvis ®. All documentation rights reserved.
Page 106: Preset Setup
, click preset button and input preset number. The interface is shown as in F igure X 4 0 9 H 4 0 9 H 4 0 9 H X 4 1 0 H 4 1 0 H 4 1 0 H © Copyright Qvis ®. All documentation rights reserved.
Page 108: Activate Pattern Function
X 4 2 2 H 4 2 2 H 4 2 2 H F igure 6-10 and click left limit button. X 4 2 3 H 4 2 3 H 4 2 3 H Repeat the above procedures to set right limit. Figure 6-10 © Copyright Qvis ®. All documentation rights reserved.
Page 109: Activate Border Function
. Here you can set auxiliary function. Click page switch button again, system goes back to F igure 6-2 X 4 2 7 H 4 2 7 H 4 2 7 H Figure 6-11 © Copyright Qvis ®. All documentation rights reserved.
Page 110: Web Operation
10.10.3.16, then please input http:// 10.10.3.16 in IE address column. See Figure 7-1. Input your IP address here. Figure 7-1 System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button. © Copyright Qvis ®. All documentation rights reserved.
Page 111 Please input your user name and password. Default factory name is admin and password is admin. Then you can select the login mode: LAN and WAN. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
Page 112: Lan Mode
Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 7-4. Figure 7-4 Please refer to Figure 7-5 for main stream and extra stream switch information. © Copyright Qvis ®. All documentation rights reserved.
Page 113 Section 4: Instant record button. Click it, the button becomes yellow and system begins manual record. See Figure 7-7. Click it again, system restores previous record mode. Figure 7-7  Section 5: Local play button. © Copyright Qvis ®. All documentation rights reserved.
Page 114  Section 7: PTZ operation panel. Please refer to chapter 7.5 for detailed information.  Section 8: Image setup and alarm setup. Please refer to chapter 7.6 for detailed information. Figure 7-9 © Copyright Qvis ®. All documentation rights reserved.
Page 115: Real-Time Monitor
There are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key. Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. It can realize PTZ automatically. © Copyright Qvis ®. All documentation rights reserved.
Page 116 You can select one option and then click AUX on or AUX off button. You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 7-12 © Copyright Qvis ®. All documentation rights reserved.
Page 117: Image/Relay-Out
7.6.3 Multiple-channel preview System allows you to preview several channels on one channel. It supports 1/4/8/9-window. See Figure 7-15. Please note only the product of this icon can support current function. Figure 7-15 © Copyright Qvis ®. All documentation rights reserved.
Page 118: Wan Login
1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null. 2) You can select different channel and different monitor mode at the bottom of the interface. See Figure 7-17. © Copyright Qvis ®. All documentation rights reserved.
Page 119 For bandwidth consideration, system can not support monitor and playback at the same time. System auto closes monitor or playback interface when you are searching setup in the configuration interface. It is to enhance search speed. © Copyright Qvis ®. All documentation rights reserved.
Page 120: Setup
Please note the video may become hazy if the value is too high. The value ranges from 0 to 100.The recommended value ranges from 40 to 60. © Copyright Qvis ®. All documentation rights reserved.
Page 122 Watermark enable Here you can select watermark bit stream, watermark mode and watermark character. Default character is DigitalCCTV. The max length is 85-digit. The character can only include number, character and underline. © Copyright Qvis ®. All documentation rights reserved.
Page 123 It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Click it; you can copy current channel setup to other Copy channel(s). © Copyright Qvis ®. All documentation rights reserved.
Page 124 You can enable this function so that system overlays channel information in video window. You can use the mouse to drag the channel title position. You can view channel title on the live video of the WEB or the playback video. © Copyright Qvis ®. All documentation rights reserved.
Page 125 C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 7-22 7.8.1.2.5 Channel Name Here you can set channel name. See Figure 7-23. Figure 7-23 © Copyright Qvis ®. All documentation rights reserved.
Page 126: Network
IP Address Please use the keyboard to input the corresponding number to modify the IP address and then set the corresponding subnet mask and the default gateway. Preferred DNS DNS IP address. © Copyright Qvis ®. All documentation rights reserved.
Page 127 The default value is 37778. You can input the actual port number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. RTSP port The default value is 554. © Copyright Qvis ®. All documentation rights reserved.
Page 128 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. © Copyright Qvis ®. All documentation rights reserved.
Page 129 If the pulse interval is 0, then system does not end 3G connection after  you close the extra stream monitor.  Pulse interval here is for extra stream only. This item is null if you are using main stream to monitor. © Copyright Qvis ®. All documentation rights reserved.
Page 130 Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated. © Copyright Qvis ®. All documentation rights reserved.
Page 131 It works even your IP address has changed. Please select DDNS from the dropdown list (Multiple choices). Before you use this function, please make sure your purchased device support current function. Figure 7-31 © Copyright Qvis ®. All documentation rights reserved.
Page 132 After successful registration, you can use domain name to login installed of the device IP.  User name: It is optional. You can input your commonly used email address. © Copyright Qvis ®. All documentation rights reserved.
Page 133 After you enabled trusted sites function, only the IP listed below can access current DVR. If you enable blocked sites function, the following listed IP addresses can not access current DVR. Figure 7-32 © Copyright Qvis ®. All documentation rights reserved.
Page 134 Input receiver email address here. Max three addresses. Receiver It supports SSL,TLS email box. The send interval ranges from 0 to 3600 seconds. 0 means Interval there is no interval. © Copyright Qvis ®. All documentation rights reserved.
Page 135 “UPnP User Interface”. Please click OK to begin installation.  Enable UPnP from the Web. If your UPnP is enabled in the Windows OS, the DVR can auto detect it via the “My Network Places” Figure 7-34 © Copyright Qvis ®. All documentation rights reserved.
Page 136 The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the Trap address proxy program of the device. © Copyright Qvis ®. All documentation rights reserved.
Page 137 Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data. © Copyright Qvis ®. All documentation rights reserved.
Page 140 You need to check the box here to enable this function. System begins 1-wiindow or multiple-window tour display among the channel(s) you set to record when an alarm occurs. Please go to chapter 5.3.6 to set tour interval and tour mode. © Copyright Qvis ®. All documentation rights reserved.
Page 141 After analysis video, system can generate a camera masking alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 0 motion detect for detailed information. © Copyright Qvis ®. All documentation rights reserved.
Page 142 Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 7.8.3.1.1 Local Alarm The local alarm interface is shown as in Figure 7-44. Figure 7-44 © Copyright Qvis ®. All documentation rights reserved.
Page 143 The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to record once an alarm occurs. Please note you need to set © Copyright Qvis ®. All documentation rights reserved.
Page 144 The network alarm interface is shown as in Figure 7-47. Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type setup. For reset setups, please refer to chapter 7.8.3.1.1. © Copyright Qvis ®. All documentation rights reserved.
Page 145 Here you can set alarm output channel mode. See Figure 7-48. Figure 7-48 7.8.3.2 Abnormity It includes six statuses: No disk, disk error, net disconnection, IP conflict and MAC conflict. See Figure 7-49 through Figure 7-54. Figure 7-49 Figure 7-50 © Copyright Qvis ®. All documentation rights reserved.
Page 147: Storage
You can view the current time period setup from the color bar.  Green color stands for the general record/snapshot.  Yellow color stands for the motion detect record/snapshot..  Red color stands for the alarm record/snapshot. © Copyright Qvis ®. All documentation rights reserved.
Page 149 5/6/7. If you wan to save current setup of channel 1 to all channels, you can click the first box “ALL”. Click the OK button to save current copy setup. Click the OK button in the Encode interface, the copy function succeeded. © Copyright Qvis ®. All documentation rights reserved.
Page 150 Here is for you to set HDD group. See Figure 7-60. Figure 7-60 7.8.4.2.3 HDD Channel The HDD channel interface is shown as in Figure 7-61. Here you can set channel group. Figure 7-61 © Copyright Qvis ®. All documentation rights reserved.
Page 151 The FTP function is on if you check the Enable box here. When network is offline or malfunction, system can save record or picture to HDD. Figure 7-62 7.8.4.3 Record control The record control interface is shown as in Figure 7-63. Figure 7-63 © Copyright Qvis ®. All documentation rights reserved.
Page 152: System
Start all/ channels record. stop all 7.8.5 System 7.8.5.1 General The general interface includes General, date/time and holiday setup. 7.8.5.1.1 General The general interface is shown as in Figure 7-64. Figure 7-64 © Copyright Qvis ®. All documentation rights reserved.
Page 153 Here is for you to specify record duration. The value ranges from 1 Pack to 120 minutes. Default value is 60 minutes. duration 7.8.5.1.2 Date and time The date and time interface is shown as in Figure 7-65 Figure 7-65 © Copyright Qvis ®. All documentation rights reserved.
Page 154 It is to set the sync periods between the device and the time server. Interval 7.8.5.1.3 Holiday Setup Holiday setup interface is shown as in Figure 7-66. Here you can check the box here to enable this function and then set. Figure 7-66 © Copyright Qvis ®. All documentation rights reserved.
Page 155 Here you can input the user name and password and then select one group for current user. Please note the user rights shall not exceed the group right setup. © Copyright Qvis ®. All documentation rights reserved.
Page 156 Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit. It shall include the number only. For the user of the account rights, he can modify the password of other users. © Copyright Qvis ®. All documentation rights reserved.
Page 157 Figure 7-69 7.8.5.2.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 7-70. Figure 7-70 © Copyright Qvis ®. All documentation rights reserved.
Page 158 PTZ control and etc. Figure 7-71 Modify group Click the modify group button, you can see an interface is shown as in Figure 7-72. Here you can modify group information such as remarks and rights. © Copyright Qvis ®. All documentation rights reserved.
Page 159 Figure 7-72 7.8.5.3 Display Display interface includes GUI, TV adjust, Tour and video matrix. 7.8.5.3.1 Here you can set background color and transparency level. See Figure 7-73. Figure 7-73 © Copyright Qvis ®. All documentation rights reserved.
Page 160 Check the box; you can optimize the margin of the preview video. Image enhance 7.8.5.3.2 TV Adjust It is to set TV output region. See Figure 7-74. Figure 7-74 © Copyright Qvis ®. All documentation rights reserved.
Page 161 Here you can set window mode and channel group. System can Split support 1/4/8/9/16/25/36-window according to device channel amount. Here you can set motion detect tour/alarm tour window mode. Motion System supports 1/8-window now. tour/Alarm tour © Copyright Qvis ®. All documentation rights reserved.
Page 162 Figure 7-76 7.8.5.4 Default The default setup interface is shown as in Figure 7-77. Here you can select Channel/Network/Event/Storage/System. Or you can check the All box to select all items. Figure 7-77 © Copyright Qvis ®. All documentation rights reserved.
Page 163 Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Figure 7-79 © Copyright Qvis ®. All documentation rights reserved.
Page 164 *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device. Important: Improper upgrade program may result in device malfunction! Figure 7-80 7.8.5.8 RS232 The RS232 interface is shown as in Figure 7-81. Figure 7-81 © Copyright Qvis ®. All documentation rights reserved.
Page 165  Decoder A (B) line connects with DVR A (B) line. Click Save button after you complete setup, you can go back to the monitor interface to control speed dome. Figure 7-82 © Copyright Qvis ®. All documentation rights reserved.
Page 166: Advanced
Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list. © Copyright Qvis ®. All documentation rights reserved.
Page 167 Usually you do not need to set source port and target port. There are total four group IP. The record channel applies to one group (optional) only. Six frame ID groups verification can guarantee information validity and legal. © Copyright Qvis ®. All documentation rights reserved.
Page 168: Information
The version interface is shown as in Figure 7-86. Here you can view system hardware features, software version, release date and etc. Please note the following information is for reference only. Figure 7-86 © Copyright Qvis ®. All documentation rights reserved.
Page 169 You can click this button to delete all displayed log files. Please note system does not support clear by type. You can click this button to backup log files to current PC. Backup © Copyright Qvis ®. All documentation rights reserved.
Page 170: Search
You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files. Figure 7-89 © Copyright Qvis ®. All documentation rights reserved.
Page 171 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in Figure 7-91, then you can specify file name and path to download the file(s) to your local pc. Figure 7-91 © Copyright Qvis ®. All documentation rights reserved.
Page 172 See Figure 7-93. Please select file(s) from the list and then Click Start backup button. Please refer to chapter 7.8.1.2.4 to set device download path. Figure 7-93 © Copyright Qvis ®. All documentation rights reserved.
Page 173: Alarm
Alarm Play alarm System sends out alarm sound when an alarm Sound sound occurs. You can specify as you wish. Sound path Here you can specify alarm sound file. © Copyright Qvis ®. All documentation rights reserved.
Page 174: Log Out
7.12 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un- installation might result in error. © Copyright Qvis ®. All documentation rights reserved.
Page 175: Faq
 Brightness is 0. Please restore factory default setup.  There is no video input signal or it is too weak.  Check privacy mask setup or your screen saver.  DVR hardware malfunctions. © Copyright Qvis ®. All documentation rights reserved.
Page 176 10. Time display is not correct. There are following possibilities:  Setup is not correct  Battery contact is not correct or voltage is too low.  Crystal is broken. 11. DVR can not control PTZ. © Copyright Qvis ®. All documentation rights reserved.
Page 177  There is privacy mask or channel protection setup.  Current user has no right to monitor.  DVR local video output quality is not good. 15. Network connection is not stable. There are following possibilities: © Copyright Qvis ®. All documentation rights reserved.
Page 178  No DXB8.1 or higher graphic acceleration software.  There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player.  No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. © Copyright Qvis ®. All documentation rights reserved.
Page 179 There are following possibilities:  Close extra stream record function.  Close snapshot function.  Reduce monitor channel amount of the WEB.  Close FTP upload function. © Copyright Qvis ®. All documentation rights reserved.
Page 180  All the designs and software here are subject to change without prior written notice.  All trademarks and registered trademarks are the properties of their respective owners.  Please visit our website: www.adata.co.uk or contact your local service engineer for more information. © Copyright Qvis ®. All documentation rights reserved.
Page 181 To download these apps please scan the QR codes below with your mobile device, using the camera feature and the appropriate QR scanner app: iPad & Tablets: ANDROID APPLE Google iTunes Play Mobile Smart Phones: ANDROID APPLE Google iTunes Play WINDOWS Phone © Copyright Qvis ®. All documentation rights reserved.
