Page 1: Quick Start Guide
APOLLOC4-500 APOLLOC8-500 4/8 Channel Full Realtime D1 Compact Digital Video Recorder Quick Start Guide V 1.0.0 11/2013 Copyright Qvis ®. All documentation rights reserved. - Page 2 Copyright Qvis ®. All documentation rights reserved.
-
Page 3: Table Of Contents
Pan/Tilt/Zoom................... 23 2.8.1 PTZ Setup ..................23 2.8.2 PTZ Operation ................24 2.8.3 3D Intelligent Positioning Key ............25 Web Operation ....................26 Network Connection ................. 26 Login ......................26 Main Window ................... 27 Copyright Qvis ®. All documentation rights reserved. - Page 4 Here you can find information about the Apollo Compact DVR’s features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully! Copyright Qvis ®. All documentation rights reserved.
-
Page 5: Important Safeguards And Warnings
Contact your local retailer ASAP if something is broken in your package. 7. Lithium battery Improper battery use may result in fire, explosion, or personal injury! When replacing the battery, please make sure you are using the same model! Copyright Qvis ®. All documentation rights reserved. -
Page 6: Hardware Installation And Connection
Then you can use the Ping command to test the network cable connection status. You need to check the cable connection if the request time is out. Copyright Qvis ®. All documentation rights reserved. -
Page 7: Hdd Installation
Please follow the instructions below to install the HDD. 2. Line up the HDD to the HDD slot and then . Turn the screw of the HDD cover and install then remove the HDD cover Copyright Qvis ®. All documentation rights reserved. - Page 8 3. Fix the HDD 4. Install the HDD cover. 5. Secure the screw of the HDD cover. Now the installation completed Copyright Qvis ®. All documentation rights reserved.
-
Page 9: Dimensions
You can refer to the following two figures for dimension information (see Figure 1-3 & Figure 1-4). Figure 1-3 Figure 1-4 1.6 Front Panel, Side Panel and Rear Panel The front panel and side panel is shown as in Figure 1-5. Figure 1-5 Copyright Qvis ®. All documentation rights reserved. - Page 10 Power socket port Connect to DC 12V power Cable port Video CVBS input, audio CVBS input, video CVBS output, audio CVBS output, RJ45 port. Power socket Alarm input, alarm output, RJ-45 port, RS-232 port. Copyright Qvis ®. All documentation rights reserved.
-
Page 11: Connection Sample
1.8 Alarm Input and Output Connection There are two alarm input types for you to select: normal open (NO) and normal close (NC). 1.8.1 Alarm Input and Output Details AB Connection port Figure 1-8 Copyright Qvis ®. All documentation rights reserved. -
Page 12: Alarm Input Port
1-channel relay alarm output (NO contact). Provide external power to external alarm device. To avoid overloading, please read relay parameters sheet in the User’s Manual carefully. RS485 A/B cable is for the A/B cable of the PTZ decoder. Copyright Qvis ®. All documentation rights reserved. -
Page 13: Overview Of Navigation And Controls
After you logged in, the system main menu is shown as below. See Figure 2-2. There are total six icons: search, information, setting, backup, advanced and shutdown. You can move the cursor to highlight the icon, and then double click mouse to enter the sub- menu. Copyright Qvis ®. All documentation rights reserved. -
Page 14: Shutdown
The other way is to press power button on the side panel to turn off the device. 2.1.4 Auto Resume after Power Failure The system can automatically backup video and resume previous working status after power failure. Copyright Qvis ®. All documentation rights reserved. -
Page 15: Replace Button Battery
This function is for 4-channel series only. The 8-channel series product does not support the schedule snapshot function.) Record types: There are four types: regular, motion detection (MD), Alarm, MD & alarm. Copyright Qvis ®. All documentation rights reserved. -
Page 16: Manual Record
Manual: The highest priority. After manual setup, all selected channels will begin ordinary recording. Schedule: Channel records as you have set in recording setup (Main Menu->Setting- >Schedule) Stop: All channels stop recording. Copyright Qvis ®. All documentation rights reserved. -
Page 17: Encode
Snapshot: Click snapshot button, you can see it contains the four items: mode/image size/image quality/snapshot frequency. Please refer to chapter 2.5.1 for detail information. Please highlight icon to select the corresponding function. Figure 2-7 Copyright Qvis ®. All documentation rights reserved. -
Page 18: Snapshot
In Detect interface please enable snapshot function for specified channels. Or in Alarm interface please enable snapshot function for specified channels. Please refer to the following figure for detail information. See Figure 2-9. Figure 2-9 Copyright Qvis ®. All documentation rights reserved. -
Page 19: Image Ftp
Click search button in the main menu, search interface is shown as below. See Figure 2-11. Usually there are three file types: R: Regular recording file. A: External alarm recording file. M: Motion detection recording file Copyright Qvis ®. All documentation rights reserved. -
Page 20: Basic Operation
128 files in one screen. You can use page up/down button to view if there are more than one page. Select the file name and double click mouse (or click enter button), you can view file content. Copyright Qvis ®. All documentation rights reserved. - Page 21 The highlighted date means there are record files in that day. You can click blue date to view file list. In the following interface you can see, there are video files in June 13 and 14 . Double click the date to view file list. Figure 2-12 Copyright Qvis ®. All documentation rights reserved.
-
Page 22: Network Setup
HTTP port: Default value is 80. Max connection: system support maximal 10 users. 0 means there is no connection limit. Transfer mode: Here you can select the priority between fluency/video qualities. Copyright Qvis ®. All documentation rights reserved. -
Page 23: Pan/Tilt/Zoom
Baud rate: Select baud rate. Data bit: Select data bit. Default value is 8. Stop bit: Select stop bit. Default value is 1. Parity: There are three choices: none/odd/even. Default value is none. Copyright Qvis ®. All documentation rights reserved. -
Page 24: Ptz Operation
Click Pan/Tilt/Zoom, the interface is shown as below. See Figure 2-16. Here you can set the following items: Step: value ranges from 1 to 8. Zoom Focus Iris Click icon to adjust zoom, focus and iris. Copyright Qvis ®. All documentation rights reserved. -
Page 25: Intelligent Positioning Key
You can click set button in Figure 2-16 (or click REC button in the front panel) to set preset, tour, and pattern. You can click page switch button in Figure 2-16 (or click Fn button in the front panel) to call main function. Copyright Qvis ®. All documentation rights reserved. -
Page 26: Web Operation
After installation, the interface is shown as below. See Figure 3-1. Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. Figure 3-1 Copyright Qvis ®. All documentation rights reserved. -
Page 27: Main Window
Click the channel name on the left side; you can view the real-time video. Figure 3-2 Note Slight difference may be found in user interface. All the designs and software here are subject to change without prior written notice. Copyright Qvis ®. All documentation rights reserved. - Page 28 For more information about our DVRs and available cameras & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: Copyright Qvis ®. All documentation rights reserved.
