Sign In
Upload
Download
Table of Contents
Contents
Add to my manuals
Delete from my manuals
Share
URL of this page:
HTML Link:
Bookmark this page
Add
Manual will be automatically added to "My Manuals"
Print this page
×
Bookmark added
×
Added to my manuals
Manuals
Brands
Qvis Manuals
DVR
I-APOLLOS-32
User manual
Qvis I-APOLLOS-32 User Manual
Iapollo hd 32 - 32 channel 2u standalone dvr
Hide thumbs
1
2
Table Of Contents
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
page
of
168
Go
/
168
Contents
Table of Contents
Bookmarks
Table of Contents
Table of Contents
Important Safeguards and Warnings
1 Features and Specifications
Overview
Features
Specifications
2 Overview and Controls
Front Panel
Rear Panel
Connection Sample
Mouse Control
Virtual Keyboard & Front Panel
Virtual Keyboard
Front Panel
3 Installation and Connections
Check Unpacked DVR
About Front Panel and Real Panel
Connecting Power Supply
Connecting Video Input and Output Devices
Connecting Video Input
Connecting Video Output
Connecting Audio Input & Output, Bidirectional Audio
Audio Input
Audio Output
Alarm Input and Output Connection
Alarm Input and Output Details
Alarm Input Port
Alarm Output Port
Rs232
Rs485
4 Overview of Navigation and Controls
Login, Logout & Main Menu
Login
Main Menu
Logout
Auto Resume after Power Failure
Replace Button Battery
Live Viewing
Manual Record
Manual Record Menu
Basic Operation
Enable/Disable Record
Enable All Channel Recording
Stop All Channel Recording
Search & Playback
Search Menu
Basic Operation
Calendar
Schedule
Schedule Menu
Snapshot
Image FTP
Snapshot Disk (for Special Series Only)
Detect
Go to Detect Menu
Motion Detect
Video Loss
Camera Masking
Alarm Setup and Alarm Activation
Go to Alarm Setup Interface
Alarm Setup
Backup
Detect Device
Backup
PTZ Control and Color Setup
Cable Connection
PTZ Setup
Intelligent Positioning Key
Preset/ Patrol/Pattern/Scan
1Preset Setup
Activate Preset
Patrol Setup (Tour Setup)
Activate Patrol (Tour)
Pattern Setup
Activate Pattern Function
Auto Scan Setup
Activate Auto Scan
Flip
5 Understanding of Menu Operations and Controls
Menu Tree
Main Menu
Setting
General
Encode
Schedule
Rs232
Network
Alarm
Detect
Pan/Tilt/Zoom
Display
Default
Search
Advanced
HDD Management
Abnormity
Alarm Output
Manual Record
Account
Auto Maintain
TV Adjust
Video Matrix
Card Overlay
Config File Backup
Information
HDD Information
Bps
Log
Version
Online Users
Shutdown
6 Auxiliary Menu
Go to Pan/Tilt/Zoom Menu
Intelligent Positioning Key
Preset /Patrol / Pattern /Border Function
Preset Setup
Activate Preset
Patrol Setup
Activate Patrol
Pattern Setup
Activate Pattern Function
Border Setup
Activate Border Function
Flip
7 Web Operation
Network Connection
Login
LAN Mode
Real-Time Monitor
Ptz
Image/Relay-Out
Relay Output
Multiple-Channel Preview
WAN Login
Setup
Channel
Video and Audio
Video Overlay
Network
Wifi
Pppoe
IP Filter
Event
Video Detect: Motion Detect
Storage
System
Advanced
Information
Search
Alarm
Log out
Un-Install Web Control
8 Faq
Advertisement
Quick Links
1
Front Panel
2
Connecting Video Input
3
Login
Download this manual
iAPOLLO HD 32
I-APOLLOS-32
32 Channel 2U Standalone DVR
User's Manual
V1.0 09 / 2013
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for Qvis I-APOLLOS-32
DVR Qvis IAPOLLO HDRT HD User Manual
8/16/32 channel full realtime d1 professional series dvr (227 pages)
DVR Qvis Iapollo SMART dvr User Manual
4/8/16 channel full realtime d1 digital video recorder (181 pages)
DVR Qvis Izeus hdcvi dvr User Manual
4 channel high definition mini 1u digital video recorder (181 pages)
DVR Qvis I-ZEUSL-4 User Manual
4 channel 1u standalone dvr (160 pages)
DVR Qvis I-ZEUS-HYBRID1 User Manual
16 channel analogue / ip hybrid dvr (207 pages)
DVR Qvis Quattro User Manual
(112 pages)
DVR Qvis APOLLOC4-500 Quick Start Manual
4/8 channel full realtime d1 compact digital video recorder (28 pages)
DVR Qvis ZEUS LX HD User Manual
1 u 4 - 16 channel dvr (58 pages)
DVR Qvis LX Apollo series Quick User Manual
Lx apollo series (16 pages)
DVR Qvis ZEUS LITE LX 16 Ch User Manual
1 u 16 channel dvr (54 pages)
DVR Qvis Pioneer-4 User Manual
4/ 8 /16 channel hda dvr (91 pages)
DVR Qvis Qvis DVR series User Manual
1 u 4 - 8 - 16 channel dvr (58 pages)
DVR Qvis DVR User Manual
Medusa series 4/8/16 channel full realtime 960h dvr (55 pages)
DVR Qvis Apollo Pro DC LX User Manual
2 u 8-16 channel dvr (57 pages)
Summary of Contents for Qvis I-APOLLOS-32
Page 1
HD 32 I-APOLLOS-32 32 Channel 2U Standalone DVR User’s Manual V1.0 09 / 2013...
Page 2
© Copyright Qvis ®. All documentation rights reserved.
Page 3: Table Of Contents
3.6 Alarm Input and Output Connection ................... 16 3.6.1 Alarm Input and Output Details ....................16 3.6.2 Alarm Input Port ........................17 3.6.3 Alarm Output Port ........................18 3.7 RS232 ............................. 19 3.8 RS485 ............................. 19 © Copyright Qvis ®. All documentation rights reserved.
Page 4
4.7.1 Backup ............................. 42 4.8 PTZ Control and Color Setup ....................... 43 4.8.1 Cable Connection ........................43 4.8.2 PTZ Setup ..........................43 4.8.3 3D Intelligent Positioning Key ....................45 4.9 Preset/ Patrol/Pattern/Scan ......................46 © Copyright Qvis ®. All documentation rights reserved.
Page 5
5.5.9 Card Overlay ..........................74 5.5.10 Config File Backup ......................... 76 5.6 Information ............................ 77 5.6.1 HDD Information ........................77 5.6.2 BPS ............................78 5.6.3 Log ............................79 5.6.4 Version ............................. 79 © Copyright Qvis ®. All documentation rights reserved.
Page 6
7.8.1 Channel............................ 98 7.8.2 Video and Audio ........................99 7.8.3 Network ..........................104 WIFI ............................106 PPPoE ............................ 108 IP filter ............................ 110 7.8.4 Event ............................116 Video detect: Motion Detect ....................116 © Copyright Qvis ®. All documentation rights reserved.
Page 7
7.8.6 System ........................... 130 7.8.7 Advanced ..........................144 7.8.8 Information ..........................146 7.9 Search ............................148 7.10 Alarm ............................151 7.11 Log out ............................152 7.12 Un-install Web Control ......................152 FAQ ........................ 153 © Copyright Qvis ®. All documentation rights reserved.
Page 8
Here you can find information about the corresponding DVR’s features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully! © Copyright Qvis ®. All documentation rights reserved.
Page 9: Important Safeguards And Warnings
Contact your local retailer ASAP if something is broken in your package. 7. Lithium battery Improper battery use may result in fire, explosion, or personal injury! When replace the battery, please make sure you are using the same model! © Copyright Qvis ®. All documentation rights reserved. viii...
Page 10: Features And Specifications
Support specified zone enlargement. Network operation: Support network remote real-time monitor, remote record search and remote PTZ control. © Copyright Qvis ®. All documentation rights reserved.
Page 11: Specifications
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. Video 1-ch VGA output. Output 1-ch HDMI output. Support TV/VGA/HDMI video output at the same time. Video monitor Video PAL (625 line, 50f/s), NTSC (525 line, 60f/s) Standard © Copyright Qvis ®. All documentation rights reserved.
Page 12
When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame playback Mode and reverse play mode. © Copyright Qvis ®. All documentation rights reserved.
Page 13
PTZ control port RS485 Support various PTZ control protocols. Ordinary COM (Debug),keyboard connection and transparent serial RS232 port(COM input and output via network ) System Hard Disk Display HDD current status Information Information © Copyright Qvis ®. All documentation rights reserved.
Page 14
Power Power General Consumptio 13W (Exclude HDD) Parameter Working 0℃-+55℃ Temperatur Working 10%-90% Humidity 86kpa-106kpa Pressure 2U standard industrial case. 440(W) x450 (D) x89mm(H) Dimension Weight 5.8-6.8KG(Exclude HDD) Installation Desktop/rack installation Mode © Copyright Qvis ®. All documentation rights reserved.
Page 15: Overview And Controls
Right When playback, click these buttons to control playback bar. Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. ENTER Confirm current operation © Copyright Qvis ®. All documentation rights reserved.
Page 16
Up/down direction key. Playback mode, turn the inner dial to realized frame by frame Jog(inner dial) playback. (Only applies to some special versions.) USB port To connect USB storage device, USB mouse. © Copyright Qvis ®. All documentation rights reserved.
Page 17
When the light flashes fast, it means the corresponding channel of 17-32 channel is recording now. When the light becomes on, It means the corresponding 2-channel is recoding now. IR Receiver It is to receive the signal from the remote control. © Copyright Qvis ®. All documentation rights reserved.
Page 18: Rear Panel
Alarm input/alarm output/RS485 port Video CVBS output Video matrix output When connect the Ethernet port, please use crossover cable to connect the PC and use the straight cable to connect to the switcher or router. © Copyright Qvis ®. All documentation rights reserved.
Page 19: Connection Sample
2.3 Connection Sample Please refer to Figure 2-3 for connection sample. Figure 2-3 © Copyright Qvis ®. All documentation rights reserved.
Page 20: Mouse Control
Implement special control operation such as double click one item in the file list click mouse to playback the video. In multiple-window mode, double left click one channel to view in full-window. Double left click current video again to go back to previous multiple-window mode. © Copyright Qvis ®. All documentation rights reserved.
Page 21: Virtual Keyboard & Front Panel
< to shift between small character and capitalized character. 2.5.2 Front Panel Move the cursor to the text column. Click Fn key and use direction keys to select number you wanted. Please click enter button to input. © Copyright Qvis ®. All documentation rights reserved.
Page 22: Installation And Connections
The input video signal should have a high SNR, low distortion; low interference, natural color and suitable lightness. GUARANTEE THE STABILITY AND RELIABILITY OF THE CAMERA SIGNAL The camera should be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. © Copyright Qvis ®. All documentation rights reserved.
Page 23: Connecting Video Output
(see Figure 3-1). Audio transmission is similar to video transmission. Try to avoid interference, dry joint, loose contact and it shoul be kept away from high tension current. © Copyright Qvis ®. All documentation rights reserved.
Page 24: Audio Output
Reduce the volume of the sound box. Using more sound-absorbing materials in decoration can reduce voice echo and improve acoustics environment. Adjust the layout to reduce happening of the squeaking. Figure 3-2 © Copyright Qvis ®. All documentation rights reserved.
Page 25: Alarm Input And Output Connection
Please refer to the specifications for the alarm input and output channel amount. Do not merely count the alarm input and out channel amount according to the ports on the rear panel. The 16-channel interface is shown as in Figure 3-3 © Copyright Qvis ®. All documentation rights reserved.
Page 26: Alarm Input Port
Please connect the NC port of the alarm sensor to the DVR alarm input(ALARM) Use the same ground with that of DVR if you use external power to the alarm device. © Copyright Qvis ®. All documentation rights reserved.
Page 27: Alarm Output Port
Between touches with same Surge voltage 1500V (10×160us) polarity 3ms max Length of open time 3ms max Length of close time Longevity Mechanical 50×106 times (3Hz) Electrical 200×103 times (0.5Hz) Temperature -40℃ ~+70℃ © Copyright Qvis ®. All documentation rights reserved.
Page 28: Rs232
2. Connect the other end of the cable to the proper pins in the connector on the camera. 3. Please follow the instructions to configure a camera to enable each PTZ device on the DVR. Figure 3-5 485 Port © Copyright Qvis ®. All documentation rights reserved.
Page 29: Overview Of Navigation And Controls
Note: For security reason, please modify password after you first login. Failure to login in after three attempts will result in the system alarm being triggered and after five failed logins the account will be locked! Figure 4-1 © Copyright Qvis ®. All documentation rights reserved.
Page 30: Main Menu
The other ways is to press power button on the front panel for at least 3 seconds, system will stop all operations. Then you can click the power button in the rear panel to turn off the DVR. © Copyright Qvis ®. All documentation rights reserved.
Page 31: Auto Resume After Power Failure
Support drag and play function. You can use your mouse to select any playback start time. Support playback, pause and exit function. Right now, system does not support slow playback and backward playback function. Support digital zoom function. Support real-time backup function. © Copyright Qvis ®. All documentation rights reserved.
Page 32
Current selected backup channel has an icon as and the free channel is shown as an icon as Once the backup started, you can see the free channel is shown as an icon as Exit © Copyright Qvis ®. All documentation rights reserved.
Page 33: Manual Record
Schedule: Channel records as you have set in recording setup (Main Menu->Setting->Schedule) Manual: The highest priority. After manual setup, all selected channels will begin ordinary recording. Stop: All channels stop recording. © Copyright Qvis ®. All documentation rights reserved.
Page 34: Enable/Disable Record
Please highlight “ALL” after “Schedule”. See Figure 4-3. When system is in schedule recording, all the channels will record as you have previously set (Main menu->Setting->Schedule). The corresponding indication light in front panel will turn on. © Copyright Qvis ®. All documentation rights reserved.
Page 35: Stop All Channel Recording
4.3.5 Stop all channel recording Please highlight “ALL” after “Stop”. See Figure 4-5. System stops all channel recording no matter what mode you have set in the menu (Main menu- >Setting->Schedule) Figure 4-5 © Copyright Qvis ®. All documentation rights reserved.
Page 36: Search & Playback
Please refer to the following sheet for more information: Serial Number Function Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file Next channel Next file Previous channel Search Backup Clip © Copyright Qvis ®. All documentation rights reserved.
Page 37: Basic Operation
Figure 4-) at the start point (that is your new file beginning point). Drag the file to the end point (that is your new file end point) and then click the again. Click the backup button (Button 14 in Figure 4-) to save your current new file. © Copyright Qvis ®. All documentation rights reserved.
Page 38
► button to go to Manual playback Click pause button in normal playback mode, │ and │ normal playback. frame by frame. you can use to view frame by frame. © Copyright Qvis ®. All documentation rights reserved.
Page 39: Calendar
Record types: There are four types: regular, motion detection (MD), Alarm, MD & alarm. Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 40
If current channel is recording now, current setup will get activated right away, the curren t file will be packet and form a file, then system begins recording as you have just set. © Copyright Qvis ®. All documentation rights reserved.
Page 41: Snapshot
In Encode interface, click snapshot button to input snapshot mode, size, quality and frequency. In General interface please input upload interval. In Schedule interface, please enable snapshot function. Please refer to the following figure for detailed information. See Figure 4-16: © Copyright Qvis ®. All documentation rights reserved.
Page 42
In Detect interface please enable snapshot function for specified channels. Or in alarm interface please enable snapshot function for specified channels. Please refer to the following figure for detailed information. See Figure 4-17. Figure 4-17 © Copyright Qvis ®. All documentation rights reserved.
Page 43: Image Ftp
4.5.4 Snapshot Disk (For special series only) Set one disk as snapshot (Main menu->Advanced->HDD management) and then click execute button. See Figure 4-19. System needs to reboot to get current setup activated. Figure 4-19 © Copyright Qvis ®. All documentation rights reserved.
Page 44: Detect
Region: Click select button, the interface is shown as in Figure 4-22. Here you can set motion detection zone. There are 396(PAL)/330(NTSC) small zones. The green zone is current cursor position. Grey zone is the motion detection zone. Black zone is the disarmed zone. You can © Copyright Qvis ®. All documentation rights reserved.
Page 45
, you can left click mouse and then drag it to set a region for motion detection. Click Fn to switch between arm/withdraw motion detection. After setting, click enter button to exit. © Copyright Qvis ®. All documentation rights reserved.
Page 46
Figure 4-21 Figure 4-22 Figure 4-23 © Copyright Qvis ®. All documentation rights reserved.
Page 47: Video Loss
You can enable alarm output channel and then enable show message function. Tip: You can enable preset activation operation when video loss occurs. Please refer to chapter 4.5.2 motion detection for detailed information. Figure 4-26 © Copyright Qvis ®. All documentation rights reserved.
Page 48: Camera Masking
PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour& pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-. © Copyright Qvis ®. All documentation rights reserved.
Page 49
For snapshot operation, please refer to chapter 4.4.2. Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. Figure 4-28 © Copyright Qvis ®. All documentation rights reserved.
Page 50: Backup
Click backup button, you can see an interface is shown as in Figure 4-32. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes USB burner, flash disk, SD card, portable HDD and eSATA. © Copyright Qvis ®. All documentation rights reserved.
Page 51: Backup
Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. See Figure 4-34. © Copyright Qvis ®. All documentation rights reserved.
Page 52: Ptz Control And Color Setup
PTZ and decoder connection is right. Decoder address setup is right. Decoder A (B) line connects with DVR A (B) line. Boot up the DVR, input user name and password. © Copyright Qvis ®. All documentation rights reserved.
Page 53
In one window display mode, right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 4-36. Figure 4-36 Click Pan/Tilt/Zoom, the interface is shown as below. See Figure 4-37. © Copyright Qvis ®. All documentation rights reserved.
Page 54: Intelligent Positioning Key
Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ automatically. The smaller zone you dragged, the higher the speed. Figure 4-39 © Copyright Qvis ®. All documentation rights reserved.
Page 55: Preset/ Patrol/Pattern/Scan
X 3 2 8 H 3 2 8 H 3 2 8 H Here you can activate the following functions: Preset Tour Pattern Auto scan Auto pan Flip Reset Page switch © Copyright Qvis ®. All documentation rights reserved.
Page 56: 1Preset Setup
In Figure 4-38, click patrol button. The interface is shown as in Figure 4-43. Input preset number and add this preset to a patrol (tour). For each patrol (tour), you can input max 80 presets. © Copyright Qvis ®. All documentation rights reserved.
Page 57: Activate Patrol (Tour)
Then please go to Figure 4-43 and click left limit button. Repeat the above procedures to set right X 3 5 0 H 3 5 0 H 3 5 0 H limit. © Copyright Qvis ®. All documentation rights reserved.
Page 58: Activate Auto Scan
Here you can set auxiliary function. The aux value has relation ship with the Aux button of the decoder. Click page switch button again, system goes back to Figure 4-37. Figure 4-46 © Copyright Qvis ®. All documentation rights reserved.
Page 59: Understanding Of Menu Operations And Controls
Encode Schedule RS232 Menu Network Alarm Detect Pan/ Tilt/Zoom Display Default Search Advanced HDD Management Alarm Output Abnormity Manual Record Account Auto Maintain TV Adjust Video Matrix Title Overlay Config Backup Shutdown © Copyright Qvis ®. All documentation rights reserved.
Page 60: Main Menu
You can see an interface is shown as in Figure 5-4. Here you can set start time and end time by setting corresponding week setup. In Figure 5-4X, enable date button, you can © Copyright Qvis ®. All documentation rights reserved.
Page 61
Before your time modification, please stop the record operation first! After completing all the setups please click save button, system goes back to the previous menu: Figure 5-3 © Copyright Qvis ®. All documentation rights reserved.
Page 62: Encode
Video/audio: You can enable or disable the video/audio. Overlay: Click overlay button, you can see an interface is shown in Figure 5-7. Please highlight icon to select the corresponding function. © Copyright Qvis ®. All documentation rights reserved.
Page 63
Channel display: You can select system displays channel number or not when you playback. Please click set button and then drag the title to the corresponding position in the screen. © Copyright Qvis ®. All documentation rights reserved.
Page 64: Schedule
Function: Console Baud rate:115200 Data bit: 8 Stop bit:1 Parity: None After completing all the setups please click save button, system goes back to the previous menu. Figure 5-8 © Copyright Qvis ®. All documentation rights reserved.
Page 65: Network
Figure 5-9 Advanced Setup Advanced setup interface is shown as in Figure 5-10. Please draw a circle to enable corresponding function and then double click current item to go to setup interface. © Copyright Qvis ®. All documentation rights reserved.
Page 66
Please note after you enabled this function, only the IP listed below can access current DVR. If you disable this function, all IP addresses can access current DVR. Figure 5-11 Multiple Cast Setup Multiple-cast setup interface is shown as in Figure 5-12. Figure 5-12 © Copyright Qvis ®. All documentation rights reserved.
Page 67
Click save button, you need to restart to activate your configuration. After rebooting, DVR will connect to internet automatically. The IP in the PPPoE is the DVR dynamic value. You can access this IP to visit the unit. © Copyright Qvis ®. All documentation rights reserved.
Page 68
Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 © Copyright Qvis ®. All documentation rights reserved.
Page 69
Click save button, system prompts for rebooting to get all setup activated. After rebooting, open IE and input as below: http://(DDNS server IP)/(virtual directory name)/webtest.htm e.g.: http://10.6.2.85/DVR _DDNS/webtest.htm.) Now you can open DDNSServer web search page. Figure 5-15 © Copyright Qvis ®. All documentation rights reserved.
Page 70
You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify or delete folder or not. See Figure 5-17. © Copyright Qvis ®. All documentation rights reserved.
Page 71
When interval value is 0, system uploads all corresponding files. After completed channel and weekday setup, you can set two periods for one each channel. © Copyright Qvis ®. All documentation rights reserved.
Page 72: Alarm
Parity: There are three choices: none/odd/even. After completed all the setups please click save button, system goes back to the previous menu. For detailed setup, please refer to chapter 4.9 preset/patrol/pattern/scan. © Copyright Qvis ®. All documentation rights reserved.
Page 73: Display
Alarm tour type: System support 1/8-window tour. Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. © Copyright Qvis ®. All documentation rights reserved.
Page 74
In tour mode, you can see the following interface. On the right corner, right click mouse or click shift button, you can control the tour. There are two icons: stands for enabling window switch and stands for disabling window function. See Figure 5-23. Figure 5-23 © Copyright Qvis ®. All documentation rights reserved.
Page 75: Default
After all the setups please click save button, system goes back to the previous menu. Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after selecting the default operation! Figure 5-24 © Copyright Qvis ®. All documentation rights reserved.
Page 76: Search
The read-write HDD is to store recorded files. The snapshot HDD is to save the snapshot images. You can search the file in the read-only HDD and read-write HDD. The files in the snapshot HDD can only be searched in the Web. © Copyright Qvis ®. All documentation rights reserved.
Page 77: Abnormity
Show message: system can pop up the message in the local screen to alert you when alarm occurs. © Copyright Qvis ®. All documentation rights reserved.
Page 78: Alarm Output
After all the setups please click OK button, system goes back to the previous menu. See Figure 5-29. Figure 5-29 5.5.4 Manual Record Please refer to chapter 4.2.2 manual record. © Copyright Qvis ®. All documentation rights reserved.
Page 79: Account
About reusable function: this function allows multiple users use the same account to login. After all the setups please click save button, system goes back to the previous menu. Figure 5-30 © Copyright Qvis ®. All documentation rights reserved.
Page 80
PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc. The modify group interface is similar to the Figure 5-32. © Copyright Qvis ®. All documentation rights reserved.
Page 81
Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account. The modify user interface is similar to Figure 5-33. Figure 5-33 © Copyright Qvis ®. All documentation rights reserved.
Page 82: Auto Maintain
Here is for you to adjust TV output setup. See Figure 5-35. Please drag slide bar to adjust each item. After all the setups please click OK button, system goes back to the previous menu. Figure 5-35 © Copyright Qvis ®. All documentation rights reserved.
Page 83: Video Matrix
Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file. Overlay Position: Here you can select the proper overlay position from the dropdown list. © Copyright Qvis ®. All documentation rights reserved.
Page 84
For the ATM/POS without the protocol, the interface is shown as in Figure 5-39. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. © Copyright Qvis ®. All documentation rights reserved.
Page 85: Config File Backup
. Figure 5-40 5.5.10 Config File Backup The configuration file backup interface is shown as below. See Figure 5-41. This function allows you to copy current system configuration to other devices. © Copyright Qvis ®. All documentation rights reserved.
Page 86: Information
Please go to setting then general to modify system time. At last, reboot the system to solve this problem. After system booted up, if there is any confliction, system goes to HDD information interface directly. Please note, system does not ask you to deal with it forcedly. © Copyright Qvis ®. All documentation rights reserved.
Page 87: Bps
Tip: Please click Fn button or left click mouse to view HDD record time and HDD type and time. 5.6.2 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 5-44. Figure 5-44 © Copyright Qvis ®. All documentation rights reserved.
Page 88: Log
USB devices. Figure 5-45 5.6.4 Version Here is for you to view some version information. See Figure 5-46. Channel Alarm in Alarm out System version: Build Date © Copyright Qvis ®. All documentation rights reserved.
Page 89: Online Users
Logout menu user: log out menu. You need to input password when you login the next time. Restart application: reboot DVR. Shutdown: system shuts down and turns off power. Restart system: system begins rebooting. Switch user: you can use another account to log in. © Copyright Qvis ®. All documentation rights reserved.
Page 90
Figure 5-48 © Copyright Qvis ®. All documentation rights reserved.
Page 91: Auxiliary Menu
X 3 9 9 H 3 9 9 H 3 9 9 H X 4 0 0 H 4 0 0 H 4 0 0 H eight direction arrows. (Please note there are only four direction arrows in DVR front panel.) © Copyright Qvis ®. All documentation rights reserved.
Page 92: Intelligent Positioning Key
Figure 6-4 Here is a sheet for you reference. Name Function Function Shortcut Function Function Shortcut Zoom Near ► Focus Near │ │ Iris Close Open © Copyright Qvis ®. All documentation rights reserved.
Page 93: Preset /Patrol / Pattern /Border Function
X 4 0 4 H 4 0 4 H 4 0 4 H Here you can activate the following functions: Preset Tour(Patrol) Pattern Auto scan Auto pan Flip Page Switch Figure 6-6 © Copyright Qvis ®. All documentation rights reserved.
Page 94: Preset Setup
Figure 6-8 6.2.4 Activate Patrol F igure 6-6 , input patrol number in the No. blank and click patrol button X 4 1 4 H 4 1 4 H 4 1 4 H © Copyright Qvis ®. All documentation rights reserved.
Page 95: Pattern Setup
X 4 2 2 H 4 2 2 H 4 2 2 H F igure 6-10 and click left limit button. X 4 2 3 H 4 2 3 H 4 2 3 H Repeat the above procedures to set right limit. Figure 6-10 © Copyright Qvis ®. All documentation rights reserved.
Page 96: Activate Border Function
Here you can set auxiliary function. Click page switch button again, system goes back to F igure 6-2 X 4 2 7 H 4 2 7 H 4 2 7 H Figure 6-11 © Copyright Qvis ®. All documentation rights reserved.
Page 97: Web Operation
10.10.3.16 in IE address column. See Figure 7-1. Input your IP address here. Figure 7-1 System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button. © Copyright Qvis ®. All documentation rights reserved.
Page 98
Please input your user name and password. Default factory name is admin and password is admin. Then you can select the login mode: LAN and WAN. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
Page 99: Lan Mode
Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 7-4. Figure 7-4 Please refer to Figure 7-5 for main stream and extra stream switch information. © Copyright Qvis ®. All documentation rights reserved.
Page 100
See Figure 7-7. Click it again, system restores previous record mode.. Figure 7-7 Section 5: Local play button. The Web can playback the saved (Extension name is ‘.dav’) files in the PC-end. © Copyright Qvis ®. All documentation rights reserved.
Page 101
Section 7: PTZ operation panel. Please refer to chapter 7.5 for detailed information. Section 8: Image setup and alarm setup. Please refer to chapter 7.6 for detailed information. Figure 7-9 © Copyright Qvis ®. All documentation rights reserved.
Page 102: Real-Time Monitor
There are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key. Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. It can realize PTZ automatically. © Copyright Qvis ®. All documentation rights reserved.
Page 103
You can select one option and then click AUX on or AUX off button. You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 7-12 © Copyright Qvis ®. All documentation rights reserved.
Page 104: Image/Relay-Out
7.6.3 Multiple-channel preview System allows you to preview several channels on one channel. It supports 1/4/8/9-window. See Figure 7-15. Please note only the product of this icon can support current function. Figure 7-15 © Copyright Qvis ®. All documentation rights reserved.
Page 105: Wan Login
In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null. You can select different channel and different monitor mode at the bottom of the interface. See Figure 7-17. © Copyright Qvis ®. All documentation rights reserved.
Page 106
For bandwidth consideration, system can not support monitor and playback at the same time. System auto closes monitor or playback interface when you are searching setup in the configuration interface. It is to enhance search speed. © Copyright Qvis ®. All documentation rights reserved.
Page 107: Setup
Please note the video may become hazy if the value is too high. The value ranges from 0 to 100.The recommended value ranges from 40 to 60. © Copyright Qvis ®. All documentation rights reserved.
Page 108: Video And Audio
7.8.2 Video and Audio Encode The encode interface is shown as below. See Figure 7-19: Figure 7-19 © Copyright Qvis ®. All documentation rights reserved.
Page 109
Watermark enable Here you can select watermark bit stream, watermark mode and watermark character. Default character is DigitalCCTV. The max length is 85-digit. The character can only include number, character and underline. © Copyright Qvis ®. All documentation rights reserved.
Page 110
It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Click it; you can copy current channel setup to other Copy channel(s). © Copyright Qvis ®. All documentation rights reserved.
Page 111: Video Overlay
You can enable this function so that system overlays channel information in video window. You can use the mouse to drag the channel title position. You can view channel title on the live video of the WEB or the playback video. © Copyright Qvis ®. All documentation rights reserved.
Page 112
C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 7-22 Channel Name Here you can set channel name. See Figure 7-23. Figure 7-23 © Copyright Qvis ®. All documentation rights reserved.
Page 113: Network
Please use the keyboard to input the corresponding number to modify the IP address and then set the corresponding subnet mask and the default gateway. Preferred DNS DNS IP address. Alternate DNS Alternate DNS IP address. © Copyright Qvis ®. All documentation rights reserved.
Page 114
The default value is 37778. You can input the actual port UDP port number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. RTSP port The default value is 554. © Copyright Qvis ®. All documentation rights reserved.
Page 115: Wifi
Double click a name to connect to it. Click Refresh button, you can view latest connection status. 3G: CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 7-27. Figure 7-27 © Copyright Qvis ®. All documentation rights reserved.
Page 116
3G: Mobile The mobile setup interface is shown as in Figure 7-29. Here you can activate or turn off the 3G connected phone/mobile phone, or the phone you set to get alarm message. © Copyright Qvis ®. All documentation rights reserved.
Page 117: Pppoe
Note: you need to use previous IP address in the LAN to login the device. Please go to the IP address item to via the device current device information. You can access the client-end via this new address. Figure 7-30 © Copyright Qvis ®. All documentation rights reserved.
Page 118
The password you input to log in the server. Update period Device sends out alive signal to the server regularly. You can set interval value between the device and DDNS server here. © Copyright Qvis ®. All documentation rights reserved.
Page 119: Ip Filter
The IP filter interface is shown as in Figure 7-32. After you enabled trusted sites function, only the IP listed below can access current DVR. If you enable blocked sites function, the following listed IP addresses can not access current DVR. © Copyright Qvis ®. All documentation rights reserved.
Page 120
Figure 7-32 Email The email interface is shown as in Figure 7-33. Figure 7-33 © Copyright Qvis ®. All documentation rights reserved.
Page 121
UPnP It allows you to establish the mapping relationship between the LAN and the public network. Here you can also add, modify or remove UPnP item. See Figure 7-34. © Copyright Qvis ®. All documentation rights reserved.
Page 122
SNMP The SNMP interface is shown as in Figure 7-35. The SNMP allows the communication between the network management work station software and the proxy of the managed device. Figure 7-35 © Copyright Qvis ®. All documentation rights reserved.
Page 123
CPU load. The source host can just send out one data to transit. This function also depends on the relationship of the group member and group of the outer. © Copyright Qvis ®. All documentation rights reserved.
Page 124
Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data. Figure 7-37 © Copyright Qvis ®. All documentation rights reserved.
Page 125: Event
7.8.4 Event Video detect: Motion Detect The motion detect interface is shown as in Figure 7-38. Figure 7-38 Figure 7-39 © Copyright Qvis ®. All documentation rights reserved.
Page 126
There are six levels. The sixth level has the highest sensitivity. Region: If you select motion detection type, you can click this button to set motion detection zone. The interface is shown as in © Copyright Qvis ®. All documentation rights reserved.
Page 127
Video Dectect: Video Loss The video loss interface is shown as in Figure 7-42. After analysis video, system can generate a video loss alarm when the detected moving signal reached the sensitivity you set here. © Copyright Qvis ®. All documentation rights reserved.
Page 128
After analysis video, system can generate a camera masking alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter motion-detect for detailed information. Figure 7-43 © Copyright Qvis ®. All documentation rights reserved.
Page 129
Before operation, please make sure you have properly connected alarm devices such as buzz er. The input mode includes local alarm and network alarm. The local alarm interface is shown as in Figure 7-44. Figure 7-44 Figure 7-45 © Copyright Qvis ®. All documentation rights reserved.
Page 130
Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs. Alarm upload System can upload the alarm signal to the centre (Including alarm centre. © Copyright Qvis ®. All documentation rights reserved.
Page 131
The network alarm interface is shown as in Figure 7-47. Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type setup. For reset setups, please refer to chapter . Figure 7-47 © Copyright Qvis ®. All documentation rights reserved.
Page 132
Here you can set alarm output channel mode. See Figure 7-48. Figure 7-48 Abnormity It includes six statuses: No disk, disk error, net disconnection, IP conflict and MAC conflict. See Figure 7-49 through Figure 7-54. Figure 7-49 Figure 7-50 © Copyright Qvis ®. All documentation rights reserved.
Page 133
Figure 7-51 Figure 7-52 Figure 7-53 Figure 7-54 © Copyright Qvis ®. All documentation rights reserved.
Page 134: Storage
You can view the current time period setup from the color bar. Green color stands for the general record/snapshot. Yellow color stands for the motion detect record/snapshot.. Red color stands for the alarm record/snapshot. © Copyright Qvis ®. All documentation rights reserved.
Page 135
Figure 7-55 Figure 7-56 Figure 7-57 © Copyright Qvis ®. All documentation rights reserved.
Page 136
5/6/7. If you wan to save current setup of channel 1 to all channels, you can click the first box “ALL”. Click the OK button to save current copy setup. Click the OK button in the Encode interface, the copy function succeeded. © Copyright Qvis ®. All documentation rights reserved.
Page 137
Here is for you to set HDD group. See Figure 7-60. Figure 7-60 Storage: HDD Channel The HDD channel interface is shown as in Figure 7-61. Here you can set channel group. Figure 7-61 © Copyright Qvis ®. All documentation rights reserved.
Page 138
The FTP function is on if you check the Enable box here. When network is offline or malfunction, system can save record or picture to HDD. Figure 7-62 Record control The record control interface is shown as in Figure 7-63. Figure 7-63 © Copyright Qvis ®. All documentation rights reserved.
Page 139: System
Check the corresponding All button, you can enable or disable all Start all/ channels record. stop all 7.8.6 System General: General The general interface includes General, date/time and holiday setup. The general interface is shown as in Figure 7-64. Figure 7-64 © Copyright Qvis ®. All documentation rights reserved.
Page 140
Here is for you to specify record duration. The value ranges from 1 Pack to 120 minutes. Default value is 60 minutes. duration General: Date and time The date and time interface is shown as in Figure 7-65 Figure 7-65 © Copyright Qvis ®. All documentation rights reserved.
Page 141
It is to set the sync periods between the device and the time server. Interval General: Holiday Setup Holiday setup interface is shown as in Figure 7-66. Here you can check the box here to enable this function and then set. Figure 7-66 © Copyright Qvis ®. All documentation rights reserved.
Page 142
Here you can input the user name and password and then select one group for current user. Please note the user rights shall not exceed the group right setup. For convenient setup, please make sure the general user has the lower rights setup than the admin. © Copyright Qvis ®. All documentation rights reserved.
Page 143
Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit. It shall include the number only. For the user of the account rights, he can modify the password of other users. © Copyright Qvis ®. All documentation rights reserved.
Page 144
Figure 7-69 Account: Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 7-70. Figure 7-70 © Copyright Qvis ®. All documentation rights reserved.
Page 145
PTZ control and etc. Figure 7-71 Modify group Click the modify group button, you can see an interface is shown as in Figure 7-72. Here you can modify group information such as remarks and rights. © Copyright Qvis ®. All documentation rights reserved.
Page 146
Figure 7-72 Display: GUI Display interface includes GUI, TV adjust, Tour and video matrix. Here you can set background color and transparency level. See Figure 7-73. Figure 7-73 © Copyright Qvis ®. All documentation rights reserved.
Page 147
Check the box; you can optimize the margin of the preview video. Image enhance Display: TV Adjust It is to set TV output region. See Figure 7-74. Figure 7-74 © Copyright Qvis ®. All documentation rights reserved.
Page 148
Here you can set window mode and channel group. System can Split support 1/4/8/9/16/25/36-window according to device channel amount. Here you can set motion detect tour/alarm tour window mode. Motion System supports 1/8-window now. tour/Alarm tour © Copyright Qvis ®. All documentation rights reserved.
Page 149
Figure 7-76 Default The default setup interface is shown as in Figure 7-77. Here you can select Channel/Network/Event/Storage/System. Or you can check the All box to select all items. Figure 7-77 © Copyright Qvis ®. All documentation rights reserved.
Page 150
Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Figure 7-79 © Copyright Qvis ®. All documentation rights reserved.
Page 151
*.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device. Important: Improper upgrade program may result in device malfunction! Figure 7-80 RS232 The RS232 interface is shown as in Figure 7-81. Figure 7-81 © Copyright Qvis ®. All documentation rights reserved.
Page 152
Decoder A (B) line connects with DVR A (B) line. Click Save button after you complete setup, you can go back to the monitor interface to control speed dome. Figure 7-82 © Copyright Qvis ®. All documentation rights reserved.
Page 153: Advanced
Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file. Overlay Position: Here you can select the proper overlay position from the dropdown list. © Copyright Qvis ®. All documentation rights reserved.
Page 154
Usually you do not need to set source port and target port. There are total four group IP. The record channel applies to one group (optional) only. Six frame ID groups verification can guarantee information validity and legal. © Copyright Qvis ®. All documentation rights reserved.
Page 155: Information
The version interface is shown as in Figure 7-86. Here you can view system hardware features, software version, release date and etc. Please note the following information is for reference only. Figure 7-86 © Copyright Qvis ®. All documentation rights reserved.
Page 156
You can click this button to delete all displayed log files. Please note system does not support clear by type. You can click this button to backup log files to current PC. Backup © Copyright Qvis ®. All documentation rights reserved.
Page 157: Search
You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files. Figure 7-89 © Copyright Qvis ®. All documentation rights reserved.
Page 158
Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in Figure 7-91, then you can specify file name and path to download the file(s) to your local pc. Figure 7-91 © Copyright Qvis ®. All documentation rights reserved.
Page 159
See Figure 7-93. Please select file(s) from the list and then Click Start backup button. Please refer to chapter to set device download path. Figure 7-93 © Copyright Qvis ®. All documentation rights reserved.
Page 160: Alarm
Alarm Play alarm System sends out alarm sound when an alarm Sound sound occurs. You can specify as you wish. Sound path Here you can specify alarm sound file. © Copyright Qvis ®. All documentation rights reserved.
Page 161: Log Out
7.12 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un- installation might result in error. © Copyright Qvis ®. All documentation rights reserved.
Page 162: Faq
Brightness is set to 0. Please restore factory default setup. There is no video input signal or it is too weak. Check privacy mask setup or your screen saver. DVR hardware malfunctions. © Copyright Qvis ®. All documentation rights reserved.
Page 163
9. There is audio when monitor but there is no audio when system playback. These are the possiblilities: Setup is not correct. Please enable audio function Corresponding channel has no video input. Playback is not continuous when the screen is blue. © Copyright Qvis ®. All documentation rights reserved.
Page 164
No dx8.1 or higher. Please upgrade display card driver. Network connection error. Network setup error. Password or user name is invalid. Client-end is not compatible with DVR program. © Copyright Qvis ®. All documentation rights reserved.
Page 165
Alarm setup is not correct. Alarm output has been opened manually. Input device error or connection is not correct. Some program versions may have this problem. Please upgrade your system. © Copyright Qvis ®. All documentation rights reserved.
Page 166
These are the possiblilities: Close extra stream record function. Close snapshot function. Reduce monitor channel amount of the WEB. Close FTP upload function. © Copyright Qvis ®. All documentation rights reserved.
Page 167
Otherwise it may result in HDD malfunction. Please make sure the device is away from the direct sunlight or other heating sources. Please keep the sound ventilation. Please check and maintain the device regularly. © Copyright Qvis ®. All documentation rights reserved.
Page 168
Alternatively scan this QR code with your smart phone to be directed instantly to our website: Download our mobile apps to remotely operate your DVR on the move: iPhone iPad Android Android Tablet © Copyright Qvis ®. All documentation rights reserved.
Table of Contents
Print
Rename the bookmark
Delete bookmark?
Delete from my manuals?
Login
Sign In
OR
Sign in with Facebook
Sign in with Google
Upload manual
Upload from disk
Upload from URL
