2. On the Button Configuration page, you may enter values for the parameters indicated in
Table
Web Page Item
Telephone Dial Mode
Enable Telephone Operation
Cellphone Dial Mode
Enable Cellphone Operation
Speed Dial Mode
Enable Speed Dial
Speed Dial Timeout (in seconds)
Keypad (0 through 9, *, and #)
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
2-10.
Table 2-10. Button Configuration Parameters
930935A
Installing the VoIP Indoor Intercom with Keypad
Description
Select Enable Telephone Operation to put the Intercom
into Telephone Dial Mode. In Telephone Dial Mode, the
Intercom will operate like a telephone:
• To make a call in this mode, press the Call Button to go
'off-hook'. The unit will begin playing a dial tone and will
wait for keypad input.
• Dial the extension you want to reach and wait.
• Pressing the Call Button at any time in this process will
hang up the call (put it back 'on-hook').
• During a call, you can use the keypad to send DTMF
tones to the remote extension.
Select Enable Cellphone Operation to put the Intercom
into Cellphone Dial Mode. In Cellphone Dial Mode, the
Intercom will operate like a cellular phone:
• This mode is similar to the telephone operation but you
dial in an extension differently.
• To make a call in this mode, dial the extension and then
press the call button to 'send' or initiate the call.
• Pressing the call button at any time in this process will
hang up the call (put it back 'on-hook').
• During a call you can use the keypad to send DTMF
tones to the remote extension.
Select Enable Speed Dial to put the Intercom into Speed
Dial Mode. In this mode the user sets up extensions to
dial when a button is pressed.
The Speed Dial Timeout (in seconds) setting is the
number of seconds you need to hold the button before it
will place a call. If this value is 0, it will place a call as soon
as the button is released.
The speed dial fields in this mode will accept delayed
DTMF tones when a comma ',' is in the dial-out field.
Type the desired time (in seconds) that you want a button
held before it will initiate a call.
Note: A Speed Dial Timeout setting of 0 will start a call
as soon as the button is released.
Enter the desired dial-out extension number (64 character
limit).
Note: For information about dial-out extension strings and
DTMF tones, see Section 2.4.7.1, "Dial Out Extension
Strings and DTMF Tones (using
35
Intercom Setup
rfc2833)".
