Figure A-2. PCB Dimensions and Intrusion Sensor Range
0.118 [3.00]
ø0.138 [ø3.51]
Fits #6-32 Machine Screw
0.551 [14.00]
(4 Places)
Effective Range for
Instrusion
1.083 [27.52]
Intrusion Sensor to Function
Sensor
JP10
TOP SIDE
from 3 mm to 14 mm
BOTTOM SIDE
J10
JP1
J12
J8
J1
J5
J2
J3
J4
SW1
J7
J9
J6
4.200 [106.68]
2.300 [58.42]
DIMENSIONS ARE IN INCHES [MILLIMETER]
0.501 [12.73]
PROJECTION: THIRD ANGLE PROJECTION
0.532 [13.53]
