73
Mount the Intercom
Figure A-35
shows a 1-Gang Box and a 2-Gang Box mounting option.
Figure A-35. Gang Box Mounting
Wall Cutout
121002B
Screw
Wall Cutout
Accessory Kit
Single Gang Box use two
Two Gang Box use four
Slot
Backplate
Closed
Single Gang Box or
Network
Two Gang Box
Faceplate
Cable
(Not Provided)
Assembly
to J1
Network Cable &
Ground Wire
(Not Provided)
Slot
Open
Nut
Drill Holes for Anchors &
Cutout for Single Gang Box
121001A
Screw
Accessory Kit
Mounting
Screws & Anchors
Screw (4x)
Ground Lug
Operations Guide
930935A
CyberData Corporation
