5. Click Browse, and then navigate to the location of the Intercom firmware file.
6. Click Submit.
Note
Table 2-23
Web Page Item
File Upload
Firmware Version
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Figure 2-32. Upgrade Firmware Page
This starts the upgrade process. Once the Intercom has uploaded the file, the Uploading
Firmware countdown page appears, indicating that the firmware is being written to flash.
The Intercom will automatically reboot when the upload is complete. When the countdown
finishes, the Upgrade Firmware page will refresh. The uploaded firmware filename should
be displayed in the system configuration (indicating successful upload and reboot).
shows the web page items on the Upgrade Firmware page.
Table 2-23. Firmware Upgrade Parameters
930935A
Installing the VoIP Indoor Intercom with Keypad
Description
Shows the current firmware version.
Use the Choose File button to navigate to the location of
the Intercom firmware file that you want to upload.
Click on the Submit button to automatically upload the
selected firmware and reboot the system.
