CyberData 011307 Operation Manual page 60

Web Page Item
Remote Event Server Port
Remote Event Server URL
Events
Enable Button Events
Enable Call Active Events
Enable Call Terminated Events
Enable Relay Activated Events
Enable Relay Deactivated Events
Enable Ring Events
Enable Night Ring Events
Enable Multicast Start Events
Enable Multicast Stop Events
Enable Power On Events
Enable Sensor Events
Enable Security Events
Enable 60 Second Heartbeat Events
Note
2.4.12.1 Example Packets for Events
The server and port are used to point to the listening server and the 'Remote Event Server URL' is
the destination URL (typically the script running on the remote server that's used to parse and
process the POST events).
Note
Here are example packets for every event:
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Table 2-17. Event Configuration (continued)
You must click on the Save button and then the Reboot button for the changes to take
effect.
The XML is URL-encoded before transmission so the following examples are not completely
accurate.
930935A
Installing the VoIP Indoor Intercom with Keypad
Description
Type the Remote Event Server port number.
(8 character limit)
Type the Remote Event Server URL.
(127 character limit)
When selected, Button Events are enabled.
When selected, Call Active Events are enabled.
When selected, Call Terminated Events are enabled.
When selected, Relay Activated Events are enabled.
When selected, Relay Deactivated Events are enabled.
When selected, Ring Events are enabled.
When selected, there is a notification when the device
receives a night ring.
When selected, Multicast Start Events are enabled.
When selected, Multicast Stop Events are enabled.
When selected, Power On Events are enabled.
When selected, Sensor Events are enabled.
When selected, an event is sent every time a security
code is entered on the keypad.
When selected, 60 Second Heartbeat Events are
enabled.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Test Event button to test an event.
Click on the Reboot button to reboot the system.
53
Intercom Setup
CyberData Corporation
