The DR Memory Configuration window is divided into three panels:
TABLE 3-3
System Memory Sizes (Domain Memory Information)
Current Domain
Attach Capacity
dr-max-mem
Memory Configuration for Board 0 (Board-Level Information)
Memory Size (MB)
Interleave Board
Physical Pages
Status/State (the display depends on the status/state of the operation)
Unavailable
Estimated
In Progress
Complete
Memory Drain Information
Reduction
Remaining in
Domain
42 Sun Enterprise 10000 Dynamic Reconfiguration User Guide • February 2000
DR Memory Configuration Information
Total size of memory in the domain from all boards
Amount of memory that can be added by using the DR Attach
operation
Current value of the OBP variable dr-max-mem (for more
information, see "dr-max-mem Variable" on page 3)
Amount of memory on the selected board
Board that the selected board is interleaved with
Highest and lowest physical pages that are occupied by the memory
on this board (Small memory areas in the middle of this range may
not be used by this board. Note that DR is not able to detach boards
that have interleaved memory.)
A suitable target memory area is not currently available.
The estimated values are displayed prior to starting the drain
operation. The values displayed reflect the memory configuration
that would result if the drain operation were started at this point.
Note that the estimated values may differ from the in-progress
values depending on the domain memory usage at the time drain
was started.
The drain operation is in progress.
The drain operation is finished.
Amount of memory to be removed from domain usage when the
board is detached
Domain memory size after the board is detached
