SPARCserver™ 1000 System Disk Drive

Installation Manual

Warning – Procedures in this manual must be performed by qualified, service-
trained maintenance providers.
Please refer to the section entitled "Notes, Cautions, and Warnings" in the
Preface of this manual.
A Sun Microsystems, Inc. Business
2550 Garcia Avenue
Mountain View, CA 94043 U.S.A.
415 960-1300 FAX 415 969-9131
Part No.: 801-7670-11
Revision 01, July 1995

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPARCserver 1000 System and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Microsystems SPARCserver 1000 System

Summary of Contents for Sun Microsystems SPARCserver 1000 System

  • Page 1: Installation Manual

    Warning – Procedures in this manual must be performed by qualified, service- trained maintenance providers. Please refer to the section entitled “Notes, Cautions, and Warnings” in the Preface of this manual. A Sun Microsystems, Inc. Business 2550 Garcia Avenue Mountain View, CA 94043 U.S.A. 415 960-1300 FAX 415 969-9131 Part No.: 801-7670-11...
  • Page 2 Sun Microsystems, Inc. The OPEN LOOK™ and Sun™ Graphical User Interfaces were developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry.

  • Page 3: Table Of Contents

    2. Installing Drives in the SCSI Tray ..... . . Disassembling the SPARCserver 1000 System ....
  • Page 4 Bracket ......... . . A-1 SPARCserver 1000 System Disk Drive Installation Manual—July 1995...
  • Page 5 Disk Drive Unit Assembly ......Figure 1-3 SCSI Tray of the SPARCserver 1000 system ....Figure 1-4 Conner 1.05 Gbyte Disk Drive SCSI Target Address Jumpers...
  • Page 6 SPARCserver 1000 System Disk Drive Installation Manual—July 1995...
  • Page 7 Tables Table 1-1 Safety Precautions ........Table 1-2 Device Addressing for the SCSI Tray .
  • Page 8 SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 9: Preface

    Preface This manual provides installation and removal procedures for the disk drive unit (two SCSI disk drives attached to the disk drive bracket) for the SPARCserver™ 1000 system. Using UNIX Commands This manual does not include specific software commands or procedures. Instead, it names software tasks and refers you to operating system documentation or the handbook that was shipped with your new hardware.

  • Page 10: Related Documents

    Related Documents Refer to the following manuals for more information: • SPARCserver 1000 System Installation Manual, (part no. 801-2893-xx). • SPARCserver 1000 System Service Manual, (part no. 801-2895-xx). • SPARCserver Boot PROM User’s Guide, (part no. 800-4852-xx). • SPARCserver 1000 POST User’s Guide (part no. 801-2916-xx).
  • Page 11 Shell Prompts in Command Examples The following table shows the default system prompt and superuser prompt for the C shell, Bourne shell, and Korn shell. Table P-2 Shell Prompts Shell Prompt C shell machine_name% C shell superuser machine_name# Bourne shell and Korn shell Bourne shell and Korn shell superuser Notes, Cautions, and Warnings...
  • Page 12 SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 13: Preparing For Installation

    Preparing for Installation This chapter describes: • Which types of disk drive units you can install in your system • What tools you need for the installation • What safety precautions you must observe • How to unpack and inspect the new disk drive unit •...

  • Page 14: Safety Precautions

    Filler panels System damage and Install filler panels in all unused card cage slots. Unused, open slots overheating severely reduce the cooling capability of the system and can lead to equipment damage. SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 15: Tools Required

    Tools Required • Antistatic mat and wrist strap • #2 Phillips screwdriver Unpacking and Inspecting the Disk Drive Unit 1. Inspect the shipping container upon receipt of the disk drives, and look for evidence of damage. If the carrier’s agent is not present when the container is opened, and the contents are found to be damaged, keep all contents and packing materials for the agent’s inspection.

  • Page 16: Figure 1-2 Disk Drive Unit Assembly

    6. Make sure the screws that secure the disk drives to the bracket are tight. See Figure 1-2. Disk drives Disk drive bracket Phillips screws (four/disk drive) Bracket cutouts (for setting/checking drive SCSI address) Figure 1-2 Disk Drive Unit Assembly SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 17: Setting Scsi Target Addresses On The Drives

    CD-ROM drive Disk drives Figure 1-3 SCSI Tray of the SPARCserver 1000 system Table 1-2 shows the physical arrangement of the SCSI tray and the target addresses of each drive as you view the tray from the front. Note that each disk drive has a unique SCSI target address.

  • Page 18: Figure 1-4 Conner 1.05 Gbyte Disk Drive Scsi Target Address Jumpers

    SCSI ID 1 SCSI ID 2 SCSI ID 3 Figure 1-4 Conner 1.05 Gbyte Disk Drive SCSI Target Address Jumpers Note – On the Conner 1.05 Gbyte drive, E5 should remain jumpered. SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 19: Figure 1-5 Seagate 1.05 Gbyte Disk Drive Scsi Target Address Jumpers

    A2 A1 A0 SCSI ID 0 SCSI ID 1 SCSI ID 2 SCSI ID 3 SCSI target address jumpers Figure 1-5 Seagate 1.05 Gbyte Disk Drive SCSI Target Address Jumpers A2 A1 A0 SCSI ID 0 SCSI ID 1 SCSI ID 2 SCSI ID 3 SCSI target address jumpers Figure 1-6...

  • Page 20: Figure 1-7 Ibm 2.1 Gbyte Disk Drive Scsi Target Address Jumpers

    A0 A1 A2 A0 A1 A2 SCSI ID 0 SCSI ID 1 SCSI ID 2 SCSI ID 3 SCSI target address jumpers Figure 1-7 IBM 2.1 Gbyte Disk Drive SCSI Target Address Jumpers SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 21: Installing Drives In The Scsi Tray

    Switching Off System Power 1. Halt the operating system. Refer to the Solaris Handbook for SMCC Peripherals that came with your system. 2. Turn off the power to the system. Refer to the SPARCserver 1000 System Installation Manual (part no. 801-2893-xx) for instructions.

  • Page 22: Removing The Front Cover

    With your fingers, push in the latch located on the bottom of the cover. See Figure 2-1. 3. Lift and raise the cover upward so it can disengage from the keepers at the top of the chassis. Cover latch Figure 2-1 Removing the Front Cover SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 23: Removing The Electromagnetic Interference (Emi) Shield

    Removing the Electromagnetic Interference (EMI) Shield 1. Loosen the six captive screws of the shield. 2. Move the shield forward, toward you, to disengage it from the chassis. See Figure 2-2. EMI shield captive screws (6) shield captive screw (hidden) EMI shield Figure 2-2 Removing the EMI Shield...

  • Page 24: Removing The Scsi Tray

    Figure 2-3 Removing the SCSI Tray 2. Release the SCSI tray from the SPARCserver 1000 system. See Figure 2-3. a. Rotate the ejectors towards you until you feel the SCSI tray connector disconnect from the backplane connector. b. Place your hands under the SCSI tray, and slide it out carefully.

  • Page 25: Installing The Disk Drive Unit

    Installing the Disk Drive Unit 1. Face the rear of the SCSI tray, and insert the disk drive unit into the tray. See Figure 2-4. Figure 2-4 Inserting the Disk Drive Unit into the Rear of the SCSI Tray 2. Secure the disk drive unit to the tray. Use the two #2 Phillips screws that came with the unit.

  • Page 26: Reassembling The System

    1. Grasp the tray on either side, lift it, and place it in the opening to the SPARCserver 1000 system. 2. Slide the SCSI tray into the SPARCserver 1000 system. Keep the ejector tabs up until their hooks slide into place. See Figure 2-3.

  • Page 27: Checking Connections

    Attaching the Front Cover 1. Place the top of the cover on the front of the SPARCserver 1000 system and swing the bottom into place while pressing the release latch. 2. Return the key to the keyswitch.
  • Page 28 SCSI bus. Watch the monitor and verify that it displays the newly-added SCSI tray disk drives. Note – If the SPARCserver 1000 system does not recognize one or more disk drives (new or old), contact your service representative.

  • Page 29: Removing A Disk Drive From

    Removing a Disk Drive From the Bracket Caution – Use the ESD kit provided with your disk drive unit for this procedure. 1. Attach the antistatic strap to your wrist and to a ground point (the bare metal of the card cage, for instance). 2.

  • Page 30: Figure A-1 Removing The Disk Drive From The Bracket

    Disk drive Disk drive bracket Retaining screws Figure A-1 Removing the Disk Drive from the Bracket SPARCserver 1000 System Disk Drive Installation Manual—July 1995...

  • Page 31: Revision History

    Revision History Revision Date Comments 801-7670-10 May 1994 First Customer Ship 801-7670-11 July 1995 First Customer Ship...
  • Page 32 SPARCserver 1000 Sytem Disk Drive Installation Manual—July 1995...
  • Page 33 Reader Comments We welcome your comments and suggestions to help improve this manual. Please let us know what you think about the SPARCserver 1000 System Disk Drive Installation Manual, part number 801-7670-11. The procedures were well documented. Strongly Strongly Agree...
  • Page 34 IF MAILED IN THE UNITED STATES BUSINESS REPLY MAIL FIRST CLASS MAIL PERMIT NO. 1 MOUNTAIN VIEW, CA POSTAGE WILL BE PAID BY ADDRESSEE SUN MICROSYSTEMS, INC. Attn: Manager, Hardware Publications MS MPK 14-101 2550 Garcia Avenue Mt. View, CA 94043-9850...
