- Page 1 Enterprise 10000 ™ ™ System 336-Mhz Processor Upgrade Instructions A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650 960-1300 fax 650 969-9131 Part No.: 805-4500-11 Revision A, July 1998 Send comments about this document to:...
- Page 2 Etats-Unis et dans d’autres pays et licenciée exclusivement par X/Open Company, Ltd. Sun, Sun Microsystems, le logo Sun, AnswerBook, SunDocs, et Solaris sont des marques de fabrique ou des marques déposées, ou marques de service, de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc.
- Page 3 Because of processor modules must be the same speed, all domains must be power off. Additionally, the clock multiplier must be changed via the SSP. This document contains the following sections to assist you with installing processor modules on your Enterprise 10000 system. Powering off a system board Removing a system board...
- Page 4 Shut Down all Domains The following procedure is for halting the operating system on a domain. 1. Log in to the SSP as user ssp. 2. When prompted for the SUNW_HOSTNAME, use either the platform name or the name of an existing domain. 3.
-
Page 5: Removing A System Board
1. Unscrew the five 3/32-inch hex-head screws located on the compression connector. 2. To remove the processor module, lift up and away from obstructions and place on a flat, ESD-protected surface with the connector side up( FIGURE 1 Installing 336-Mhz Processor Modules into a Enterprise 10000 System... - Page 6 Processor 3 Processor 2 Processor 1 Processor 0 Replacing System Board Processor Module FIGURE 1 Sun Enterprise 10000 336-Mhz Processor Module Upgrade Instructions • July 1998...
-
Page 7: Installing A Processor Module
7. Engage all captive connector screws clockwise using a #4-40 hex-head driver. 8. Tighten the captive connector screws to a low torque of 0.34 Nm (3.0 inch pounds) in the pattern noted in FIGURE 2 Installing 336-Mhz Processor Modules into a Enterprise 10000 System... - Page 8 Tightening Pattern for the Processor Module FIGURE 2 9. Tighten the captive connector screws to a final torque of 0.68 Nm (6.0 inch pounds) in the pattern noted in FIGURE 2 10. Replace the system board cover and secure with Phillips screws tightening to a torque of 1.0 Nm (8.9 inch pounds), 11.
-
Page 9: Installing A System Board
4. Apply firm pressure to the face plate to engage the board with the centerplane connector. 5. Use the insertion handles to fully seat the board. 6. Lock the handles by sliding the locking levers into position until they are fully nested with the handles. Installing 336-Mhz Processor Modules into a Enterprise 10000 System... - Page 10 Powering On a System Board 1. Determine the amount of system power available by typing power. to confirm the amount of available power is sufficient for the amount of TABLE 1 system boards to be installed. Power Redundancy TABLE 1 Number of System Required Power Supplies for N+ 2 Power Supply Required 200V, 30 A...
- Page 11 Failure to execute this procedure in these cases will prevent the SSP software from correctly monitoring the system's temperature. 1. Type: % edd_cmd -x stop This stops the edd daemon monitoring scripts. Installing 336-Mhz Processor Modules into a Enterprise 10000 System...
- Page 12 2. Type: % thermcal_config The thermcal_config(1M) command requires approximately 10 minutes to complete on a system containing 16 system boards. The thermcal_config(1M) command reads thermal data on every system board as well as the centerplane configured in the system, and creates a file (thermcaldata.tcl). It is important to note any errors that the thermcal_config(1M) command encounters when performing this operation.
- Page 13 This will update the ssp_resource file. Caution – Do not run the sys_clock command with any of its command-line options on a running system. 2. To check the multiplier value, type: ssp% sys_clock Installing 336-Mhz Processor Modules into a Enterprise 10000 System...
- Page 14 Sun Enterprise 10000 336-Mhz Processor Module Upgrade Instructions • July 1998...
