DR - Detach Board
Detaching Board: 5
Information:
Checking environment . . .
Establishing Control Board Server connection . . .
Initializing SSP SNMP MIB . . .
Establishing communication with DR daemon . . .
BOARD # : 6 7 physically present.
BOARD # : 0 2 4 5 being used by the system.
cpu memory
drain
abort
Dynamic Reconfiguration Window With the drain Button
FIGURE 3-5
6. Click the drain button.
Hostview begins draining memory. The memory information is displayed and
enables you to monitor the progress of the drain operation.
The memory drain statistics are automatically updated at periodic intervals if you
enable the Auto Update Domain Information Displays option in the DR Properties
window, as described in "Viewing Domain Information" on page 37.
If the drain operation fails, an explanatory message appears in the Information pane.
After you have determined the cause, and corrected it, you can choose drain again.
You may proceed to the next step without waiting; it does not depend on completion
of the drain.
7. To determine which devices are active on the board, click the device button.
The DR Device Configuration window is displayed and is periodically updated,
providing you with a current snapshot of device usage.
8. Terminate all usage of board-resident I/O devices.
For more information, see "Complete Detach" on page 27.
When the complete button is displayed, DR is finished draining the memory, and
you can proceed to the next step.
Dynamic Reconfiguration
Source Domain:
xf2: System Status - Summary
System Information
device
force
dismiss
xf2
obp
unsafe
properties
all
reconfig
help
Chapter 33
