Figure 3-1 Attach Board And Domain Selection Window - Sun Microsystems Sun Enterprise 10000 Dynamic Reconfiguration User Manual

Select board in main window. Then click "Select".
Domain
Select domain in main window. Then click "Select".
Target domain
FIGURE 3-1
4. Click the top select button.
The Board field is automatically filled in for you. If the board is part of a domain, the
Domain field is also filled in for you. (You can also manually edit these fields.)
5. In the main Hostview window, use the View menu to select the domain to which
you want to attach the board.
6. Click the bottom Select button.
The Target Domain field is automatically filled in for you. (You can also manually
edit that field.)
7. Click the execute button.
If any errors occur, the error messages appear in the main Hostview window.
Otherwise, the Dynamic Reconfiguration window is displayed with the init attach
button visible (
20 Sun Enterprise 10000 Dynamic Reconfiguration User Guide • February 2000
attach - Board and Domain Selection
Board
execute dismiss
Attach Board and Domain Selection Window
on page 21).
FIGURE 3-2
select
select
help
