Sun Fire
™
A211 Power Supply Unit
This document contains the procedures for upgrading the power modules and power supply units on the
following Sun Fire™ system cabinets:
E20K-BASE
■
E25K-BASE
■
E20K-BASE-2
■
E25K-BASE-2
■
E20K-BASE-2-Z
■
E25K-BASE-2-Z
■
All F12K cabinets
■
All F15K cabinets
■
The systems have two power modules, each holding three hot-swappable power supplies. One module is on
the front of the system and the other module is on the rear. Both must be replaced to accommodate the A211
power supply units. The A211 power supplies and power module are keyed to prevent intermixing with older
power supplies and power modules.
Caution –
The A211 power supplies require System Management Software (SMS) 1.6 with patches
124319-02 (or higher) and 123300-05 (or higher) or subsequent compatible versions.
For the latest patch information go to http://sunsolve.sun.com. Installation information and
README files are included in the patch download.
E25K/E20K/15K/12K Systems
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sun Microsystems Sun Fire E25K
Summary of Contents for Sun Microsystems Sun Fire E25K
- Page 1 Sun Fire E25K/E20K/15K/12K Systems ™ A211 Power Supply Unit This document contains the procedures for upgrading the power modules and power supply units on the following Sun Fire™ system cabinets: E20K-BASE ■ E25K-BASE ■ E20K-BASE-2 ■ E25K-BASE-2 ■ E20K-BASE-2-Z ■ E25K-BASE-2-Z ■...
- Page 2 For your protection, observe the following safety precautions: Follow all cautions and instructions marked on the equipment. ■ Always use proper ESD equipment and procedures when handling boards and components. ■ Never push objects of any kind through openings in the equipment. They might touch dangerous voltage ■...
-
Page 3: Removing A Power Module
c. As a superuser on the main SC, shutdown the main SC by typing: sc# shutdown -y -g seconds -i 0 where seconds is the amount of time before shutdown. 4. Open the cabinet doors. 5. Power off the AC0 and AC1 circuit breakers for all power supplies in the system. 6. - Page 4 5. Remove the air plenum cover, air-inlet EMI honeycomb panel, and air filter from the system and place them on a flat sturdy surface. 6. Loosen the jackscrews on the seven (7) 8W8 Combo-D 8-pin DC power connectors (on the left side) and the two (2) DB-25 control connectors (on the right side).
-
Page 5: Installing A Power Module
Installing a Power Module 1. Secure the power module end of the seven (7) 8W8 Combo-D 8-pin DC power connectors and two (2) DB-25 control connectors to the new power module. The cables were disconnected from the previous power module during removal. Note –... -
Page 6: Contacting Sun Technical Support
Copyright 2007 Sun Microsystems, Inc. All rights reserved. Use is subject to license terms. Third-party software, including font technology, is copyrighted and licensed from Sun suppliers. Portions may be derived from Berkeley BSD systems, licensed from U. of CA. Sun, Sun Microsystems, the Sun logo, Java, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc.
