Cable Diagnostics
This window displays the details of copper cables attached to specific ports on the Switch. If there is an error in the
cable this feature can determine the type of error and the position where the error has occurred.
To view this window, click Monitoring > Cable Diagnostics:
Enter the range of ports to test and click Test. The results will be displayed in the table on the lower half of the
window.
NOTE: If the Link Status field for an interface displays "Link Up", the value displayed in the
Cable Length field may not be accurate for the interface.
Figure 7 - 1. Cable Diagnostics window
