D-Link xStack Reference Manual page 203

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch WEB UI Reference Guide
Figure 6 - 87. CPU Access Profile List window for IPv6 example
To view the configurations for a previously configured entry, click on the corresponding Show Details button, which
will display the following window:
Figure 6 - 88. CPU Access Profile Detail Information window for IPv6 example
To return to the CPU Access Profile List window, click Show All Profiles. To add a rule to a previously configured
entry, click on the corresponding Add/View Rules button and then click Add Rule on the CPU Access Rule List
window, which will reveal the following window:
Figure 6 - 89. (CPU) Add Access Rule window for IPv6 example
202
