xStack® DES-3200 Series Layer 2 Ethernet Managed Switch WEB UI Reference Guide
To re-configure the MEP entry, click on the Edit button.
Parameter
MEP State
CCM State
PDU Priority
Fault Alarm
Alarm Time
Alarm Reset Time
Remote MEP Table
Figure 3 - 64. CFM MEP Information window
Description
This is the MEP administrative state.
Enable - MEP is enabled.
Disable - MEP is disabled. This is the default value.
This is the CCM transmission state.
Enable - CCM transmission enabled.
Disable - CCM transmission disabled. This is the default value.
The 802.1p priority is set in the CCMs and the LTMs messages transmitted by the MEP. The
default value is 7.
This is the control types of the fault alarms sent by the MEP.
All - All types of fault alarms will be sent.
Mac Status - Only the fault alarms whose priority is equal to or higher than "Some Remote
MEP MAC Status Error" are sent.
Remote CCM - Only the fault alarms whose priority is equal to or higher than "Some Remote
MEP Down" are sent.
Errors CCM - Only the fault alarms whose priority is equal to or higher than "Error CCM
Received" are sent.
Xcon CCM - Only the fault alarms whose priority is equal to or higher than "Cross-connect
CCM Received" are sent.
None - No fault alarm is sent. This is the default value.
This is the time that a defect must exceed before the fault alarm can be sent. The unit is in
centiseconds, the range is 250-1000. The default value is 250.
This is the dormant duration time before a defect is triggered before the fault can be re-
alarmed. The unit is in centiseconds, the range is 250-1000. The default value is 1000.
Read-only information for remote MEPs is listed here. Information includes, Remote MEPID,
MAC Address, Status, RDI, Port Status, Interface Status, Last CCM Serial Number, Sender
Chassis ID, Sender Management Address, and Detect Time.
