xStack® DES-3200 Series Layer 2 Ethernet Managed Switch WEB UI Reference Guide
The following parameters may be configured or viewed:
Parameter Description
Interface Name Enter the name of the IPv6 neighbor. To search for all the current interfaces on the Switch, go to
the second Interface Name field in the middle part of the window, tick the All check box, and then
click the Find button.
Neighbor IPv6 Enter the neighbor IPv6 address.
Address
Link Layer MAC Enter the link layer MAC address.
Address
State Use the drop-down menu to select All, Address, Static, or Dynamic.

Port Configuration

This section contains information for configuring various attributes and properties for individual physical ports,
including port speed and flow control.

Port Settings

Various port settings, including State, Speed/Duplex, Flow Control, Address Learning, Medium Type, and MDIX can
be configured on the Switch.
To view the following window, click Configuration > Port Configuration > Port Settings:
To configure switch ports, choose the port or sequential range of ports using the From Port and To Port pull-down
menus. Use the remaining pull-down menus to configure the parameters described below:
Figure 2 - 8. Port Settings window
19
