Cleaning The Printer Rollers - DataCard ImageCard Select User Manual

4-6
2
3
4

Cleaning the printer rollers

The rollers in the printer move the card into position to begin operations, such as
printing, and move the card during operations. Clean the rollers once a week or when
problems occur, such as repeated card jams or cards not being picked.
To clean rollers, use the cleaning pen.
Clean printer rollers
1
2
!
Do not peel off the blue stripe on the back of the card.
Open the Status Monitor by double-clicking the icon.
Click the Mag Stripe button in the Clean area.
The printer automatically runs the magnetic stripe cleaning process and ejects the
card in the output stacker when it is complete.
Remove the used magnetic stripe cleaning card. The card can be used again.
Open the Status Monitor by double-clicking the printer icon.
i
Make sure that printing of cards is complete before cleaning the rollers.
Clean the two pick rollers:
E
If the printer has a locking card cartridge, unlock the cartridge before
removing it.
a Remove the card cartridge.
b Remove the cap from the cleaning pen. Hold the end of the cleaning pen
against the first pick roller (step 1 in Figure 4-7).
User's Guide for ImageCard® Select™ and UltraGrafix® Select™
Maintaining the printer
