16.0 Testing

There are five functions for testing that your system
operates correctly.
16.1

Horn Speaker Test

Press and hold [1] until two beeps sound.
The horn speaker sounds for 2 sec.
16.2

Bell Test

Press and hold [2] until two beeps sound.
The bell output turns on for 2 sec.
16.3

Strobe Test

1. Press and hold [3] until three beeps sound.
The strobe flashes.
2. Press and hold [3] until two beeps sound.
The strobe stops flashing.
16.4

Walk Test Mode

Use Walk Test Mode to test the proper operation of
detection devices. Every time you test a zone, the
codepad sounds one long beep and the horn speaker
sounds one short beep to indicate the zone was
activated when testing.
1. Enter your four-character Master Code and press
[7 #] (for example, [2 5 8 0 7 #]).
Three beeps sound, and the STAY and AWAY
indicators flash. The codepad beeps once per sec
while the system is in Walk Test Mode.
2. Activate the zones you want to test.
The codepad sounds one long beep and the horn
speaker sounds one short beep each time a zone
is faulted (unsealed) and restored.
3. When you finish testing the zones, press [#] to
exit from this mode.
Two beeps sound, and the STAY and AWAY
indicators turn off. The system returns to the
disarmed state.
16.5

Test Report

This feature only applies if your system reports by
telephone. Press and hold [9] until two beeps sound.
The system sends a Test Report without sounding
the sirens.

17.0 Event Memory Recall

Use this function to replay the last 40 system events
that occurred. The event memory history replays all
alarms, and arming and disarming of the system in
AWAY Mode, STAY Mode 1, and STAY Mode 2.
The system cannot differentiate between
arming the system in STAY Mode 1 or
STAY Mode 2.
To enter Event Memory:
Bosch Security Systems, Inc. | 10/08 | F01U089400-01
Testing
Enter your four-character Master Code and press
[8 #] (for example, [2 5 8 0 8 #]).
Three beeps sound. The last 40 events appear one at
a time by the codepad indicators, starting from the
most recent event. A beep sounds as each event
appears.

18.0 Day Alarm

Day alarm allows the system to monitor a
combination of zones when the system is disarmed
by beeping the codepad buzzer. Only your installer
can program Zones 1 to 4 to operate for day alarm.
Example
You can set up a day alarm at the front door of a
shop with a pressure mat or electronic beam that
customers activate as they enter and exit from the
shop. As the customers walk onto the pressure mat
or break the electronic beam, the codepad buzzer
beeps.
To turn day alarm on:
Hold down [4] until three beeps sound.
Day alarm turns on. If a zone programmed for day
alarm operation is activated when the system is
disarmed, the codepad beeps.
To turn day alarm off
Hold down [4] until two beeps sound.
Day alarm turns off.
19.0 Remote Arming By
Telephone
Use this feature to arm your system by telephone
from any remote location. For security reasons, you
cannot disarm the system using this method. This
feature requires a touch-tone telephone. Remote
arming works only if your installer programmed this
feature.
To arm your system remotely by telephone:
1. Call the telephone number connected to your
control panel.
When the control panel answers the incoming
call, a short jingle sounds.
2. To arm the system, press [*] on the touch-tone
telephone for 1 to 3 sec.
If you hear modem tones when the control panel
answers the incoming call, the system is
programmed for remote programming functions
by your installer. Wait for a pause between the
tones before you press [*].
After you release [*] on the touch-tone
telephone, two beeps sound. The system is
armed in AWAY Mode.
3. Hang up the telephone.
The system remains armed.
