A LAN Reset does not change the service name, even if it is a custom name, but it may remove the
dash and the number if a service name conflict has been removed.
To restore the factory default service name, open the LAN  Modify web page and enter a blank
for the new service name (refer to section 4.7.6.6).
4.7.5

LAN Setup

4.7.5.1

View the IP and MAC Addresses

When the power supply is operating with the LAN enabled, the IP and MAC addresses may be
viewed on the front panel. To view the IP and MAC addresses, perform the following steps:
To view the IP address:
1. Press COMM button.
2. Rotate Voltage Encoder until IP appears on the Voltage display, 1 appears on the Current
display.
3. Press Current encoder to enter IP configuration. Rotate Voltage encoder to view the IP
address.
The voltage display shows IP1-IP4 by rotating Voltage encoder. The current display shows the
corresponding IP field.
To view the MAC address:
1. Press COMM button.
2. Rotate Voltage Encoder until MAC appears on the Voltage display, 1 appears on the Current
display.
3. Press Current encoder to enter MAC configuration. Rotate Voltage encoder to view the MAC
address.
The voltage display shows MAC1-MAC6 by rotating Voltage encoder. The current display shows
the corresponding MAC field.
4.7.5.2

Change the IP Address

The power supply allows changing all four numbers (octets) of the IP address via the front panel.
The IP address has four numbers (i.e. 10.97.4.4). Each number may be set to any value from 0 to
255.
Some restrictions may apply due to subnet settings restrictions.
NOTE
