Wave Mode - TDK-Lambda GH10-100 User Manual

0.01s ec
Tri gger Ini ti a ted
Tri gger Wa i t
Tri gger Event
Tri gger Del a y
Dwel l
OUTPUT
VOLTAGE
5.1.2

WAVE Mode

Output value change in slopes is determined by parameters in the WAVE. Output change is
activated by the input trigger (refer to section 5.2.2). Program WAVE parameters are activated by
the Program subsystem. For WAVE related commands, refer to section 4.14.7.
Set the operation mode by [SOURce]:CURRent:MODE <DSC> and/or [SOURce]:VOLTage:MODE
<DSC> command/s.
0.02s
0.05s
STEP AUTO
Figure 5–2: LIST Mode Sequence Example
ABORT
*RST
NO
YES
INIT:CONT INITIATE STATE
TRIGGERED EVENT
0
>0
OUTPUT CHANGE
PROG:COUN
(LINEAR STEP)
YES
Figure 5–3: Simplified WAVE Mode Model
0.06s 0.03s
IDLE STATE
INIT[:IMM]
TRIG[:IMM]
DELAY STATE
STATE
NO
WAVE STEP
COMPLETE
NO
PROG:STEP
AUTO
131
INIT:IMM
TRIG:DEL 0.02
LIST:DWELL 0.05,0.06,0.03
LIST:VOLT 5,10,0
YES
